1970 Pontiac GTO
The big news for 1970 was a special Hurst SSJ version, a semi-custom conversion with an electric sunroof, gold-colored wheels, and a Hurst shifter.

1970 Pontiac GTO

In the GTO continued and once again received styling changes . Restyled with a new front end with four exposed headlamps wrapped in an Endura bumper, new body creases, and a redesigned rear end. A new 455 engine was added as well as the rare Vacuum Operated Exhaust option. The VOE option was an attempt to simplify the old rodding trick of opening up the exhaust system for more power. With the VOE option, the driver could pull the knob under the dash and engine vacuum was routed to a diaphragm on each muffler where it opened an internal baffle and gave the exhaust an express route through the muffler, reducing backpressure and increasing power. The 1970 GTO with the 400-cid 366-hp V-8 was capable of 0-60 in 6 seconds and 14.6 seconds in the quarter mile. The 455-cid 360-hp GTO hardtop registered 6.6 seconds 0-60 and a 14.8 second quarter mile.

GTO shared Tempest sheet metal combined with a standard Endura rubber nose. Recessed grilles were housed in two oval cavities and the letters "GTO" were in the drivers side insert. Also there was GTO lettering behind the front wheel openings and flared, crease sculptured fenders were used. Standard equipment included bucket seats, twin air scoops, sports type springs and shocks, glove box, dual exhaust, 3-spd manual floor shift, vinyl trimmed padded dashboard, heavy duty clutch, carpeting, ashtray and panel courtesy lamps, deluxe steering wheel, and G78 x 14 black sidewall fiberglass tires. A Code 332-WT1 "The Judge" option was available again. It had a 400-cid Ram-Air V-8, G70 x 14 fiberglass black sidewall tires, side stripes, black textured grilles, T-handle shifters on manual floor shift, Rally II wheels less trim rings, rear deck air foil, and Judge stripes and decals.

1970 Pontiac GTO Production Numbers and Specifications

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
GTO Series 242
242 37 2d Hardtop - 5P $3,267 3,641 lbs 32,737
242 67 2d Convertible - 5P $3,492 3,691 lbs 3,615
GTO Series 242 w/ WT-1 "The Judge" Option
242 37 2d Hardtop - 5P $3,604 3,506 lbs 3,629

Notes

  1. 40,149 GTOs and Judges were built in 1970
  2. 16,033 GTOs and Judges had synchromesh and 24,116 had automatic

Model Series Identification

GTO 2d Hardtop - 5P - 24237 GTO 2d Convertible - 5P - 24267

Chassis Data

Model Wheelbase Overall Length Front Tread Rear Tread Tires
GTO 112 in 201.5 in 60 in 60 in G78 x 14
GTO "The Judge" 112 in 201.5 in 60 in 60 in G70 x 14

VIN Decoding

First Symbol - Manufacturer
2 = Pontiac
Second & Third Symbol - Series
23 = Firebird 39 = Safari
24 = Firebird Espirit 42 = GTO
26 = Firebird Formula 400 52 = Catalina & Ventura
28 = Trans Am 56 = Executive
33 = Standard Tempest 62 = Bonneville
35 = Custom "S" 76 = Grand Prix
37 = LeMans
Fourth & Fifth Symbol - Body Style
27 = two-door sedan 46 = station wagon three seat
35 = station wagon two seat single action tailgate 57 = two-door hardtop (Grand Prix)
36 = station wagon two seat dual action tailgate 67 = convertible
37 = two-door hardtop (exc. Firebird, Grand Prix) 69 = four-door sedan
39 = four-door hardtop 87 = two-door hardtop (Firebird)
Sixth Symbol - Last Digit Of The Model Year
0 = 1970
Seventh Symbol - Assembly Plant
(A) Atlanta, Georgia (P) Pontiac, Michigan
(B) Baltimore, Maryland (R) Arlington, Texas
(C) Southgate, California (X) Kansas City, Kansas
(E) Linden, New Jersey (Z) Fremont, California
(G) Framingham, Massachusetts (1) Oshawa, Ontario, Canada
(L) Van Nuys, California (2) St. Therese, Quebec, Canada
(N) Norwood, Ohio
Last Six Symbols - Production Sequence
Started at 100001

1970 Pontiac GTO Options & Accessories

Group # Part # Code Description Suggested List Price
12.181 988806 AF Air Foil, Deck Lid Not Available
4.898 988808 AM Power Brakes $46.15
9.772 988727 AM Electric Clock w/o Tachometer $17.95
8.873 988679 AM Compass $6.95
7.629 988707 AM Spare Wheel & Tire Cover $4.35
3.880 988810 AM Cruise Control 8-Cyl Automatic $49.95
9.778 988720 AM Rear Window Defogger $24.75
8.891 988761 AM Tissue & Litter Container/Dispenser $5.95
9.990 985592 AM Fire Extinguisher (2 3/4 lbs.) $14.95
9.990 985593 AM Fire Extinguisher Re-Charge Kit $2.15
7.800 988700 AM Front License Plate Frame $1.75
7.800 988699 AM Rear License Plate Frame $1.75
10.352 988724 AM Door Edge Guard - 2-Door $6.15
2.485 988818 AM Headlamp Control $24.50
0.034 984642 SPA Engine Block Heater $10.25
8.083 988595 AM Hood Retainer $14.95
4.006 988605 AM Gear Shift Knob - 4-Speed Manual $6.15
4.006 984848 AM Gear Shift Knob (Walnut) - 3-Speed Manual $5.95
9.988 988730 AM Luggage Compartment Lamp $2.95
8.890 988681 AM Underhood Lamp $3.95
8.083 988817 AM Hood Lock $9.95
15.294 984826 AM Trunk Mat $9.95
15.286 984661 AM Front Mat Full (Ivory) $9.95
15.286 984655 AM Front Mat Pair (Ivory) $7.95
15.306 984114 AM Rear Mat Pair (Ivory) $7.65
15.286 984659 AM Front Mat Full (Black) $9.95
15.286 984653 AM Front Mat Pair (Black) $7.95
15.306 984512 AM Rear Mat Pair (Black) $7.65
15.286 988776 AM Front Mat Full (Red) $9.95
15.286 988789 AM Front Mat Pair (Red) $7.95
15.306 988796 AM Rear Mat Pair (Red) $7.65
15.286 988770 AM Front Mat Full (Dark Blue) $9.95
15.286 988783 AM Front Mat Pair (Dark Blue) $7.95
15.306 988790 AM Rear Mat Pair (Dark Blue) $7.65
15.286 988771 AM Front Mat Full (Dark Gold) $9.95
15.286 988784 AM Front Mat Pair (Dark Gold) $7.95
15.306 988791 AM Rear Mat Pair (Dark Gold) $7.65
15.286 988772 AM Front Mat Full (Dark Green) $9.95
15.286 988785 AM Front Mat Pair (Dark Green) $7.95
15.306 988792 AM Rear Mat Pair (Dark Green) $7.65
15.286 988773 AM Front Mat Full (Dark Sandlewood) $9.95
15.286 988786 AM Front Mat Pair (Dark Sandlewood) $7.95
15.306 988793 AM Rear Mat Pair (Dark Sandlewood) $7.65
15.286 988774 AM Front Mat Full (Dark Saddle) $9.95
15.286 988787 AM Front Mat Pair (Dark Saddle) $7.95
15.306 988794 AM Rear Mat Pair (Dark Saddle) $7.65
15.286 988775 AM Front Mat Full (Dark Brown) $9.95
15.286 988788 AM Front Mat Pair (Dark Brown) $7.95
15.306 988795 AM Rear Mat Pair (Dark Brown) $7.65
10.185 988596 AM Outside Rearview Mirror (Right) $4.85
10.185 988653 AM Remote Control Mirror (Left) $12.15
9.790 988757 AF Power Flow Ventilation w/o Air Conditioning $54.75
9.650 988742 AM Push Button Radio $53.55
9.650 988740 AM AM-FM Radio $125.00
9.650 988741 AM AM-FM Stereo Radio $225.00
12.242 988693 AM Deck Lid Release $12.95
9.675 993502 A Child Safety Seat - Standard $8.95
9.675 987499 A Child Safety Seat - Deluxe $18.95
9.679 993970 A Infant Safety Carrier Seat $9.95
9.665 988578 AM Rear Speaker $13.25
9.665 984985 AM Rear Speaker Adapter $0.80
6.508 988803 AM Power Steering $95.15
6.508 988804 AM Adapter Package - Use w/ All 8-Cyl Air Cond. $3.96
9.670 988752 AM Stereo Tape Player w/ Console $125.00
9.670 988754 AM Stereo Tape Player w/o Console $125.00
9.750 988748 AM Hood Tachometer $75.00
5.880 984922 AM Tire Inflator - Fire Extinguisher (CO-2) - S/S Spare $7.95
2.694 988758 AMF Trailer Wire Harness $13.15
5.858 988607 AM Custom Wheel Discs $54.00
5.858 988609 AM Deluxe Wheel Discs $30.00
5.858 984528 AM Wire Wheel Discs $69.15
10.146 988698 SAS Windshield Blade - Arctic Blade 16" $9.40
7.345 3192704 MF Rear Superlift Shock Absorbers $49.30

1970 Engine Options

Letter Code Engine Horsepower Torque Transmission Carburetor
WA 8-455 370 445 Manual 4 BC
WS 8-400 366 445 Manual 4 BC
WT 8-400 350 445 Manual 4 BC
WW 8-400 370 445 Manual 4 BC
XP 8-400 370 445 Auto 4 BC
XV 8-400 330 430 Auto 4 BC
XX 8-400 265 397 Auto 2 BC
YA 8-455 370 445 Auto 4 BC
YS 8-400 350 445 Auto 4 BC
YZ 8-400 366 445 Auto 4 BC

Transmission Codes

Transmission Location
Turbo Hydra-Matic 350 Stamped on servo cover on right side of transmission.
Turbo Hydra-Matic 400 On metal tag fastened to right side of transmission case & on some models on the left side of converter housing.
3-Speed Painted or stamped on the transmission case.
4-Speed Painted or stamped on the transmission case.
Plant and Type Designation Prefix Transmission Type
DC 3-Speed (column)
DE 3-Speed
DG 3-Speed
DG 4-Speed (close-ratio)
DJ 4-Speed (wide-ratio)
DP 4-Speed (close-ratio)
DL 4-Speed (close-ratio)
R3 3-Speed
R4 3-Speed
WB 4-Speed (wide-ratio)
JE Turbo Hydra-Matic 350
JF Turbo Hydra-Matic 350
JU Turbo Hydra-Matic 350
PA Turbo Hydra-Matic 400
PB Turbo Hydra-Matic 400
PC Turbo Hydra-Matic 400
PD Turbo Hydra-Matic 400
PF Turbo Hydra-Matic 400
PH Turbo Hydra-Matic 400
PR Turbo Hydra-Matic 400
PT Turbo Hydra-Matic 400
PW Turbo Hydra-Matic 400
PX Turbo Hydra-Matic 400
PY Turbo Hydra-Matic 400

Axle Codes

Location Of Axle Codes: Letter codes are on axle tube near carrier

Codes - Non-Locking Codes - Locking Ratio
WB XB 2.56
WC XC 2.78
WT XT 3.07
WE XE 3.08
WF XF 3.23
WU XU 3.31
WH, WV XH, XV 3.55
WK XK 3.90
  XM, 7N 4.33

Paint Codes - Exterior Colors

Color Name / Code Color Image Color Name / Code Color Image

10 - Polar White
Lucite® Code - 5040L
Dulux® Code - 5040D

48 - Pepper Green Metallic
Lucite® Code - 5116L
Dulux® Code - 5116D

14 - Palladium Silver Metallic
Lucite® Code - 5032L
Dulux® Code - 5032D

50 - Sierra Yellow
Lucite® Code - 5121L
Dulux® Code - 5121D

19 - Starlight Black
Lucite® Code - 99L
Dulux® Code - 93-005

53 - Coronado Gold Metallic
Lucite® Code - 5073LH
Dulux® Code - 5073D

25 - Bermuda Blue Metallic
Lucite® Code - 5123L
Dulux® Code - 5123D

55 - Baja Gold Metallic
Lucite® Code - 5120L
Dulux® Code - 5120D

26 - Lucerne Blue Metallic
Lucite® Code - 5190L
Dulux® Code - 5190D

58 - Granada Gold Metallic
Lucite® Code - 5117L
Dulux® Code - 5117D

28 - Atoll Blue Metallic
Lucite® Code - 5124L
Dulux® Code - 5124D

63 - Palomino Copper Metallic
Lucite® Code - 5125L
Dulux® Code - 5125D

34 - Mint Turquoise Metallic
Lucite® Code - 5119L
Dulux® Code - 5119D

67 - Castillian Bronze Metallic
Lucite® Code - 5076LH
Dulux® Code - 5076DH
43 - Keylime Green Metallic
Lucite® Code - 5126L
Dulux® Code - 5126D
75 - Cardinal Red
Lucite® Code - 5118LH
Dulux® Code - 5118DM
45 - Palisade Green Metallic
Lucite® Code - 5122L
Dulux® Code - 5122D
78 - Burgundy Metallic
Lucite® Code - 5063LH
Dulux® Code - 5063DH

47 - Verdoro Green Metallic
Lucite® Code - 5195L
Dulux® Code - 5195D


NOTES: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination 28-10 on a Pontiac would indicate the body finished in Atoll Blue Metallic and the roof area in Polar White.) General Motors paint code plate for all models is located on the "horizontal" or "vertical" surface of the shroud upper panel on the left side of the body.


Paint Codes - Interior Colors

Color Name / Code Color Image Color Name / Code Color Image

Ivory
Lucite® Code - 9715L (semi-gloss)

Dark Green Metallic
Lucite® Code - 9708LH (semi-gloss)
Lucite® Code - 9697LH (flat)

Medium Gold Metallic
Lucite® Code - 9707LH (semi-gloss)

Midnight Green Metallic
Lucite® Code - 9593LH (semi-gloss)
Lucite® Code - 9582LH (flat)

Dark Gold Metallic
Lucite® Code - 9698LH (flat)

Medium Bright Blue Metallic
Lucite® Code - 9540L (semi-gloss)
Lucite® Code - 9696L (flat)

Medium Sandlewood
Lucite® Code - 9716L (semi-gloss)

Medium Blue Metallic
Lucite® Code - 9711L (semi-gloss)

Dark Sandlewood
Lucite® Code - 9727L (semi-gloss)
Lucite® Code - 9704L (flat)

Dark Blue Metallic
Lucite® Code - 9712LH (semi-gloss)
Lucite® Code - 9701LH (flat

Medium Saddle
Lucite® Code - 9714L (semi-gloss)

Medium Red
Lucite® Code - 9709LH (semi-gloss)

Dark Saddle
Lucite® Code - 9703L (flat)

Dark Red
Lucite® Code - 9699LH (flat)

Dark Brown
Lucite® Code - 9713L (semi-gloss)
Lucite® Code - 9702L (flat)

Black
Lucite® Code - 4428L (semi-gloss)
Lucite® Code -

Lime Gold Metallic
Lucite® Code - 9718LH (semi-gloss)



NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use 1/2 oz. DuPont #4528S flattening compound to a pint of unreduced color.

Trunk Colors (spatter finish)

Black - Gray - Aqua 389 - 259
