1970 Chevrolet Camaro


1970 Chevrolet Camaro

The start of production of the all new 1970 Camaro model was delayed until January 5, 1970. As a result, the second generation F-cars were not introduced to the public until February 26, 1970. However, a gorgeous design inspired by european sports cars gave the new Camaro immediate appeal. The sleak long hood, short deck fastback body was longer, lower, and wider than the first generation Camaro.











1970 Chevrolet Camaro Specifications

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
Camaro Sport Coupe Series 23 - Six-Cyl
23 87 2d Cpe $2,759 3,058 lbs Note 2
Camaro Sport Coupe Series 24 - V-8
24 87 2d Cpe $2,839 3,172 lbs Note 2
Camaro Rally Sport Coupe Series 23 + Z22 - Six-Cyl
23 87 2d Cpe $2,918 Not Available Note 3
Camaro Rally Sport Coupe Series 24 + Z22 - V-8
24 87 2d Cpe $3,008 Not Available Note 3
Camaro SS Series 24 + Z27 - RPO L48 "Turbo-Fire 350" V-8/4-Speed Manual Transmission
24 87 2d Cpe $3,336 Not Available Note 4
Camaro SS Series 24 + Z27 - RPO L34 "Turbo-Jet 396" V-8/4-Speed Manual Transmission
24 87 2d Cpe $3,491 Not Available Note 4
Camaro SS Series 24 + Z27 - RPO L78"Turbo-Jet 396" V-8/4-Speed Manual Transmission
24 87 2d Cpe $3,724 Not Available Note 4
Camaro Z/28 Sport Coupe - Series 24 + Z/28 - V-8/4-Speed Manual Transmission
24 87 2d Conv $3,794 Not Available Note 5
Camaro Z/28 Sport Coupe - Series 24 + Z/28 - V-8/Turbo Hydra-Matic Transmission
24 87 2d Cpe $3,878 Not Available Note 5

NOTES:

  1. Total Production = 152,037
  2. Base Coupe = 100,967
  3. Rally Sport = 27,136
  4. SS = 15,201
  5. Z/28 = 8,733

Model Series Identification

Camaro - 12387, 12487

Chassis Specifications

Model Wheelbase Overall Length Width Front Tread Rear Tread Tires
Camaro 108 in 188 in 75 in 59 in 58 in E78 x 14B
Camaro SS 350 108 in 188 in 75 in 59 in 58 in F70 x 14
Camaro Z/28 108 in 188 in 75 in 59 in 58 in F60 x 15

VIN Numbers

Serial Numbers were stamped on a plate on the left front door hinge pillar (center pillar on Corvair). The Fisher Body number plate on the right-hand side of the cowl gives additional information such as the body style number, the production sequence number, the trim (upholstery) number code and the paint number code. Also the serial number was on the top of the dash, left side, visible thru windshield.
First Symbol - Manufacturer
1 = Chevrolet
Second & Third Symbol - Series
01 = Corvair 500 six-cylinder 35 = Chevelle Malibu/Concours six-cylinder
05 = Corvair Monza six-cylinder 36 = Chevelle Malibu/Concours V-8
11 = Nova four-cylinder 38 = Chevelle Concours Estate V-8
13 = Nova six-cylinder 53 = Biscayne/Brookwood six-cylinder
14 = Nova V-8 54 = Biscayne/Brookwood V-8
23 = Camaro six-cylinder 55 = Bel Air/Townsman six cylinder
24 = Camaro V-8 56 = Bel Air/Townsman V-8
31 = Chevelle Nomad six-cylinder 63 = Impala six-cylinder
32 = Chevelle Nomad V-8 64 = Impala/Kingswood V-8
33 = Chevelle/Greenbriar 300 Deluxe six-cylinder 66 = Caprice/Kingswood Estate V-8
34 = Chevelle/Greenbriar 300 Deluxe V-8 94 = Corvette
Fourth & Fifth Symbol - Body Style
11 = two-door sedan 45 = four-door nine-passenger station wagon
27 = two-door pillared sport coupe 46 = four-door three-seat station wagon
35 = four-door six-passenger station wagon 47 = Impala Custom or Caprice sport coupe
36 = four-door two-seat station wagon with dual -action tailgate 67 = two-door convertible
37 = two-door hardtop or sport coupe 69 = four-door sedan
39 = four-door hardtop or sport sedan 87 = Impala two-door sport coupe
Sixth Symbol - Last Digit Of The Model Year
0 = 1970
Seventh Symbol - Assembly Plant
(A) Atlanta, Georgia (N) Norwood, Ohio
(B) Baltimore, Maryland (R) Arlington, Texas
(C) Southgate, California (S) St. Louis, Missouri
(D) Doraville, Wisconsin (T) Tarrytown, New York
(F) Flint, Michigan (U) Lordstown, Ohio
(G) Framingham, Massachusetts (W) Willow Run, Michigan
(J) Janesville, Wisconsin (Y) Wilmington, Delaware
(K) Kansas City, Missouri (Z) Fremont, California
(L) Los Angeles, California (2) St. Therese, Quebec, Canada
Last Six Symbols - Production Sequence
Started at 100001

1970 Chevrolet Camaro Options

Code Description Price
AK1 Color Keyed Seat & Shoulder Belts $12.15
AS4 Custom Deluxe Rear Shoulder Belts $26.35
A01 Soft-Ray All Tinted Glass $37.95
B37 Floor Mats $11.60
B93 Door Edge Guards $5.30
C08 Vinyl Roof Cover (Sport Coupe) $89.55
C24 Hide-A-Way Windshield Wipers $19.00
C50 Rear Window Defroster $26.35
C60 Air Conditioning $380.25
D34 Visor-Vanity Mirror $3.20
D35 Sport Mirrors $26.35
D55 Center Console $59.00
D80 Rear Deck Lid Spoiler (1 Piece) $32.65
COPO Rear Deck Lid Spoiler (3 Piece) $Not Available
F41 Heavy-Duty Sport Suspension $30.55
G80 Positraction Rear Axle $44.25
Not Available Optional Rear Axle Ratios $Not Available
J50 Power Brakes $47.40
L34 396 cid/350-hp V-8 $152.75
L65 350 cid/250-hp V-8 $31.60
L78 396 cid/375-hp V-8 $385.50
M20 Wide-Ratio 4-Speed Manual Transmission (Muncie & Saginaw) $205.95
M21 Close-Ratio 4-Speed Manual Transmission $205.95
M22 4-Speed Manual Transmission "Rock Crusher" $232.35
M35 Powerglide Automatic Transmission w/ Six-Cylinder Engine $174.25
M38 Turbo Hydra-Matic Transmission 350 $200.65
M40 Turbo Hydra-Matic Transmission 400 $200.65
NA9 California Emissions Controls $36.90
N33 Comfortilt Steering Wheel $45.30
N40 Power Steering $105.35
PL3 E78-14 White Sidewall Tires $26.05
PL4 F70-14 White Letter Tires $65.35
PX6 F78-14 White Sidewall Tires $43.30
PY4 F70-14 Fiberglass-Belted White Stripe Tires $65.70
P01 Bright Metal Wheel Covers $26.35
P02 Custom Wheel Covers $79.00
T60 Heavy-Duty Battery $15.18
U14 Special Instrumentation $84.30
U35 Electric Clock $15.80
U63 AM Radio $61.10
U69 AM/FM Radio $133.80
U80 Rear Seat Speaker $14.75
VF3 Deluxe Front & Rear Bumpers $36.90
V01 Heavy-Duty Radiator $14.75
YD1 Trailering Axle Ratio $12.65
ZJ7 Rally Wheels & Trim Rings $42.15
ZJ9 Auxiliary Lighting $13.70
ZQ9 Performance Axle Ratio $12.65
Z21 Style Trim $52.70
Z22 Rally Sport Package $168.55
Z23 Special Interior Group $21.10
Z27 Camaro Super Sport Package $289.65
Z28 Special Performance Package $572.95
Z87 Custom Interior $115.90

Engine Codes

Location Of Engine Code: 6-Cyl-- Stamped on a pad behind the distributor on right side of block. 8-Cyl-- Stamped on the block in front of the right hand cylinder head.
Letter Code Engine Horsepower Torque Transmission Carburetor
CCG 6-250 155 235 Manual 3-Speed 1 BC
CCK (p) (t) 6-250 155 235 Turbo Hydra-Matic 350 1 BC
CCL (p) (t) 6-250 155 235 Manual 3-Speed 1 BC
CCM (p) (t) 6-250 155 235 Powerglide 1 BC
CCZ 6-250 155 235 Manual 3-Speed 1 BC
CJF 8-396 350 + 415 Manual Transmission 4 BC
CJH 8-396 375 # 415 Manual Transmission 4 BC
CJI 8-396 350 + 415 Turbo Hydra-Matic 400 4 BC
CJL 8-396 375 # 415 Turbo Hydra-Matic 400 4 BC
CKO 8-396 375 # 415 Manual 4-Speed 4 BC
CNC 8-307 200 300 Manual 3-Speed 2 BC
CND 8-307 200 300 Manual 4-Speed 2 BC
CNE 8-307 200 300 Powerglide 2 BC
CNF 8-307 200 300 Turbo Hydra-Matic 350 2 BC
CNI 8-350 250 345 Manual 4-Speed 2 BC
CNJ 8-350 300 380 Manual 4-Speed 4 BC
CNK 8-350 300 380 Powerglide 4 BC
CNM 8-350 250 345 Powerglide 2 BC
CNN 8-350 250 345 Turbo Hydra-Matic 350 2 BC
CRE 8-350 300 380 Turbo Hydra-Matic 350 4 BC
CRF 6-250 155 235 Manual 3-Speed 1 BC
CRG 6-250 155 235 Manual 3-Speed 1 BC
CTB 8-350 360 # 415 Manual 4-Speed 4 BC
CTC 8-350 360 # 415 Turbo Hydra-Matic 400 4 BC
CTW 8-396 350 + 415 Turbo Hydra-Matic 400 4 BC
CTX 8-396 350 + 415 Manual 4-Speed 4 BC
CTY 8-396 375 # 415 Turbo Hydra-Matic 400 4 BC


Notes:

  • (p) Police
  • (t) Taxi
  • + High Performance
  • # Special High Performance

Transmission Codes

Transmission Location
Powerglide (Corvair) On top of the case in the rear at 11 o'clock.
Powerglide Passenger (exc. Corvair) Immediately behind right hand machining lug with the bottom of the sticker parallel to mold flash.
Powerglide All models stamped on the right side of transmission oil pan.
Turbo Hydra-Matic Right hand vertical surface of transmission case
3-Speed Corvair and fully synchronized Passenger (exc. Warner Gear) transmissions stamped on square boss on left side below and rear of cover
4-Speed Passenger models (exc. Corvair) stamped on right side of case ahead of the extension.
4-Speed (Corvair) Stamped on boss on lower left side of case just below side cover.

Plant and Type Designation Prefix Plant Transmission Type
N Muncie 4-Speed
W Warner Gear 3 and 4-Speed
P Muncie 4-Speed
R Saginaw 4-Speed
S Saginaw 3-Speed
M Muncie 3-Speed, Overdrive*
C Cleveland Powerglide
T Toledo Powerglide
CA Hydra-Matic 3-Speed, Automatic Turbo Hydra-Matic
D Saginaw Overdrive
K McKinnon 3-Speed
E McKinnon Powerglide
O Saginaw Overdrive
X Cleveland Turbo Hydra-Matic 350
B Cleveland Turbo Hydra-Matic 350
Y Toledo Turbo Hydra-Matic 350
A Cleveland 2-Speed, Manual Powerglide


*Overdrive distinguished from 3-Speed by physical appearance only. The above transmissions (exc. Warner Gear) will carry a production code number such as: C1116N (C = Cleveland Powerglide, 11 = November, 16 = 16th, N = Night Shift). The Warner Gear transmissions will carry a production code number such as: WG1031 (W = Warner Gear 4-Spd., G = July, 10 = 10th, 7 = 1967, 1 = First Shift).

Axle Codes

Location Of Axle Codes: The axles for Chevrolet will be built by Chevrolet Buffalo, Chevrolet Gear and Axle, Buick, Oldsmobile, and McKinnon. Divisional Manufacturer code letters will be metal stamped on the axle tube adjacent to the carrier for identification. Metal stamp on left rear axle tube on the rear side, letters and numerals 3/16 in. high, 3 in. outboard of carrier.
Codes - Non-Locking Codes - Locking Ratio Inspection Cover
COC,CRX COD,CRY 2.73 10 Bolt & 12 Bolt
COS COT 3.07 12 Bolt
COE COF,CRI 3.08 10 Bolt
COU COV 3.31 12 Bolt
  COX 3.55 12 Bolt
  COZ 3.73 12 Bolt
COO   4.10 12 Bolt

Manufacturer Identity
B - Buick C - Chevrolet Buffalo
O - Oldsmobile K - GM of Canada, St. Catharines
P - Pontiac M - GM of Canada
G - Chevrolet Gear & Axle

Paint Codes - Exterior Colors

Color Name / Code Color Image Color Name / Code Color Image

10 - Classic White
Lucite® Code - 5040L
Dulux® Code - 5040D

48 - Forest Green Metallic
Lucite® Code - 5116L
Dulux® Code - 5116D

14 - Cortez Silver Metallic
Lucite® Code - 5032L
Dulux® Code - 5032D

50 - Gobi Beige
Lucite® Code - 5121L
Dulux® Code - 5121D

17 - Shadow Gray Metallic
Lucite® Code - 5113L
Dulux® Code - 5113D

53 - Camaro Gold Metallic
Lucite® Code - 5073LH
Dulux® Code - 5073D

19 - Tuxedo Black
Lucite® Code - 99L
Dulux® Code - 93-005

55 - Champagne Gold Metallic
Lucite® Code - 5120L
Dulux® Code - 5120D

25 - Astro Blue Metallic
Lucite® Code - 5123L
Dulux® Code - 5123D

58 - Autumn Gold Metallic
Lucite® Code - 5117L
Dulux® Code - 5117D

26 - Mulsanne Blue Metallic
Lucite® Code - 5190L
Dulux® Code - 5190D

63 - Desert Sand Metallic
Lucite® Code - 5125L
Dulux® Code - 5125D

28 - Fathom Blue Metallic
Lucite® Code - 5124L
Dulux® Code - 5124D

67 - Classic Copper Metallic
Lucite® Code - 5076LH
Dulux® Code - 5076DH

34 - Misty Turquoise Metallic
Lucite® Code - 5119L
Dulux® Code - 5119D

75 - Cranberry Red
Lucite® Code - 5118LH
Dulux® Code - 5118DM
43 - Citrus Green Metallic
Lucite® Code - 5126L
Dulux® Code - 5126D
78 - Black Cherry Metallic
Lucite® Code - 5063LH
Dulux® Code - 5063DH
45 - Green Mist Metallic
Lucite® Code - 5122L
Dulux® Code - 5122D

NOTES: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination 51-50 on a Chevrolet would indicate the body finished in Dusk Blue and the roof area in Dover White.) General Motors paint code plate for all models except Corvair and Corvette is located under the hood at the top of the firewall on the left or right of the upper shroud. Corvair paint code plate is on the left cross-rail in the engine compartment. Corvette paint code plate is on the instrument panel brace, below the glove compartment.


Paint Codes - Interior Colors

Color Name / Code Color Image Color Name / Code Color Image

Ivory
Lucite® Code - 9715L (semi-gloss)

Dark Green Metallic
Lucite® Code - 9708LH (semi-gloss)
Lucite® Code - 9697LH (flat)

Medium Gold Metallic
Lucite® Code - 9707LH (semi-gloss)

Midnight Green Metallic
Lucite® Code - 9593LH (semi-gloss)
Lucite® Code - 9582LH (flat)

Dark Gold Metallic
Lucite® Code - 9705LH (semi-gloss)
Lucite® Code - 9698LH (flat)

Dark Turquoise Metallic
Lucite® Code - 9719LH (semi-gloss)
Lucite® Code - 9700LH (flat)

Medium Sandlewood
Lucite® Code - 9716L (semi-gloss)

Medium Bright Blue Metallic
Lucite® Code - 9540L (semi-gloss)
Lucite® Code - 9696L (flat)

Dark Sandlewood
Lucite® Code - 9727L (semi-gloss)
Lucite® Code - 9704L (flat)

Medium Blue Metallic
Lucite® Code - 9711L (semi-gloss)

Medium Saddle
Lucite® Code - 9714L (semi-gloss)

Dark Blue Metallic
Lucite® Code - 9712LH (semi-gloss)
Lucite® Code - 9701LH (flat)

Dark Saddle
Lucite® Code - 9726L (semi-gloss)
Lucite® Code - 9703L (flat)

Medium Red
Lucite® Code - 9709LH (semi-gloss)

Dark Brown
Lucite® Code - 9713L (semi-gloss)
Lucite® Code - 9702L (flat)

Dark Red
Lucite® Code - 9706LH (semi-gloss)
Lucite® Code - 9699LH (flat)

Lime Gold Metallic
Lucite® Code - 9718LH (semi-gloss)

Black
Lucite® Code - 4428L (semi-gloss)
Lucite® Code -

NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use 1/2 oz. DuPont #4528 flattening compound to a pint of unreduced color.



Trunk Colors (spatter finish)

Black - Gray - Aqua 389 - 259

Top of page




Note: Information, Specifications, Resources & Photos found in the Research Library
should only be used as general guidelines. OldRide LLC makes no warranty as to the
authenticity and accuracy of the information contained hereon.


Home | Classifieds: Vehicles / Parts | Sell on OldRide | Rusty Rides | OldRide Answers | Events | Clubs

Library | Car & Truck Resources | MyOldRide Account | Support | OldRide Banners | Car Photos


Copyright © 2014 Internet Brands, Inc. All rights reserved | OldRide Support | Terms of Use | Classified Guidelines | Privacy Policy | Cookies
