1969 CHEVROLET CAMARO Information Specifications Resources Pictures

the 1969 Chevrolet Camaro SS. Note the unique Hideaway Headlamps.

1969 Chevrolet Camaro

The 1969 Chevrolet Camaro was changed to look more aggressive. The heavily restyled body looked longer and lower. The wheel wells were flattened with sculptured feature lines flowing off the towards the rear of the car and rear-slanting air slots ahead of the rear wheel. At the front of the standard Camaros was a grille with 13 slender vertical moldings and five horizontal moldings forming a grid surrounded by a bright molding. A badge with the Chevrolet bow-tie emblem was in the center. There were single round headlights at the ends of the grille. The full width bumper integrated with the body color outer grille surround and there was a license plate holder in the center of the valance panel. Round parking lights were positioned on either side of the license plate. At the rear were wider taillight bezels with triple segment lenses.

The 1969 Chevrolet Z28 Camaro remains one of Americas most desirable Muscle Cars of all. With just $458 added to the base price of $2,726 of a Camaro coupe, the Z28 included twin rally stripes, quicker steering and the F41 handling suspension with E70x15 raised-letter tires on seven-inch wide rims.

With a solid-lifter 302 V-8 and four-barrel carburetor the 1969 Z28 wasn't the fastest but definitely packed plenty of power for most performance seekers. Another option unique to the 1969 Z28 was the cowl-induction hood with a valve that opened to draw in cool air from the base of the windshield. The Hurst-shifted close-ratio four-speed was standard.

1969 Chevrolet Camaro Specifications

Model Number	Body/Style Number	Body Type & Seating	Factory Price	Shipping Weight	Total Production
Camaro Series 23 - Six-Cyl
23	37	2d Cpe	$2,621	3,005 lbs	Note 2
23	67	2d Conv	$2,835	3,255 lbs	Note 3
Camaro Series 24 - V-8
24	37	2d Cpe	$2,727	3,135 lbs	Note 2
24	67	2d Conv	$2,940	3,385 lbs	Note 3
Camaro Rally Sport Series 23 + Z22 - Six-Cyl
23	37	2d Cpe	$2,753	Not Available	Note 4
23	67	2d Conv	$2,967	Not Available	Note 4
Camaro Rally Sport Series 24 + Z22 - V-8
24	37	2d Cpe	$2,859	Not Available	Note 4
24	67	2d Conv	$3,072	Not Available	Note 4
Camaro SS Series 24 + Z27 - RPO L48 "Turbo-Fire 350" V-8/3-Speed Manual Transmission
24	37	2d Cpe	$3,023	Not Available	Note 5
24	67	2d Conv	$3,236	Not Available	Note 5
Camaro SS Series 24 + Z27 - RPO L34 "Turbo-Jet 396" V-8/3-Speed Manual Transmission
24	37	2d Cpe	$3,207	Not Available	Note 5
24	67	2d Conv	$3,420	Not Available	Note 5
Camaro SS Series 24 + Z27 - RPO L35 "Turbo-Jet 396" V-8/3-Speed Manual Transmission
24	37	2d Cpe	$3,086	Not Available	Note 5
24	67	2d Conv	$3,299	Not Available	Note 5
Camaro SS Series 24 + Z27 - RPO L89 "Turbo-Jet 396" V-8/3-Speed Manual Transmission
24	37	2d Cpe	$3,734	Not Available	Note 5
24	67	2d Conv	$3,947	Not Available	Note 5
Camaro Indy Sport Convertible (Indy 500 Pace Car Replica) Model 2467 + Z11 (350-cid V-8)
24	67	2d Conv	$3,405	Not Available	3,675
Camaro Indy Sport Coupe Model 12437 + Z10 (350-cid V-8)
24	37	2d Cpe	$3,192	Not Available	200 - 300
Camaro Z/28 Sport Coupe - Series 24 + Z/28 - V-8/4-Speed Manual Transmission
24	37	2d Cpe	$3,588	Not Available	20,302

NOTES:

Total Production = 243,085
Base Coupe = 165,226
Base Convertible = 17,573
Rally Sport = 37,773
SS = 36,309

Model Series Identification

Camaro - 12300, 12400, 12500, 12600	Camaro Std. Sport Coupe - 12337, 12437
Camaro Std. - 12300, 12400	Camaro Std. Convertible - 12367, 12467
Camaro Deluxe - 12500, 12600	Camaro Deluxe Sport Coupe - 12537, 12637
Camaro Sport Coupe - 12337, 12437, 12537, 12637	Camaro Deluxe Convertible - 12567, 12667
Camaro Convertible - 12367, 12467, 12567, 12667

Chassis Specifications

Model	Wheelbase	Overall Length	Width	Front Tread	Rear Tread	Tires
Camaro	108 in	188 in	74 in	59 in	58 in	E78 x 14B
Camaro SS 350	108 in	188 in	74 in	59 in	58 in	F70 x 14
Camaro Z/28	108 in	188 in	74 in	59 in	58 in	E70 x 15

VIN Numbers

Serial Numbers were stamped on a plate on the left front door hinge pillar (center pillar on Corvair). The Fisher Body number plate on the right-hand side of the cowl gives additional information such as the body style number, the production sequence number, the trim (upholstery) number code and the paint number code. Also the serial number was on the top of the dash, left side, visible thru windshield.

First Symbol - Manufacturer

1 = Chevrolet

Second & Third Symbol - Series
01 = Corvair 500 six-cylinder	35 = Chevelle Malibu/Concours six-cylinder
05 = Corvair Monza six-cylinder	36 = Chevelle Malibu/Concours V-8
11 = Nova four-cylinder	38 = Chevelle Concours Estate V-8
13 = Nova six-cylinder	53 = Biscayne/Brookwood six-cylinder
14 = Nova V-8	54 = Biscayne/Brookwood V-8
23 = Camaro six-cylinder	55 = Bel Air/Townsman six cylinder
24 = Camaro V-8	56 = Bel Air/Townsman V-8
31 = Chevelle Nomad six-cylinder	63 = Impala six-cylinder
32 = Chevelle Nomad V-8	64 = Impala/Kingswood V-8
33 = Chevelle/Greenbriar 300 Deluxe six-cylinder	66 = Caprice/Kingswood Estate V-8
34 = Chevelle/Greenbriar 300 Deluxe V-8	94 = Corvette

Fourth & Fifth Symbol - Body Style
11 = two-door sedan	45 = four-door nine-passenger station wagon
27 = two-door pillared sport coupe	46 = four-door three-seat station wagon
35 = four-door six-passenger station wagon	47 = Impala Custom or Caprice sport coupe
36 = four-door two-seat station wagon with dual -action tailgate	67 = two-door convertible
37 = two-door hardtop or sport coupe	69 = four-door sedan
39 = four-door hardtop or sport sedan	87 = Impala two-door sport coupe

Sixth Symbol - Last Digit Of The Model Year

9 = 1969

Seventh Symbol - Assembly Plant
(A) Atlanta, Georgia	(N) Norwood, Ohio
(B) Baltimore, Maryland	(R) Arlington, Texas
(C) Southgate, California	(S) St. Louis, Missouri
(D) Doraville, Wisconsin	(T) Tarrytown, New York
(F) Flint, Michigan	(U) Lordstown, Ohio
(G) Framingham, Massachusetts	(W) Willow Run, Michigan
(J) Janesville, Wisconsin	(Y) Wilmington, Delaware
(K) Kansas City, Missouri	(Z) Fremont, California
(L) Los Angeles, California	(2) St. Therese, Quebec, Canada

Last Six Symbols - Production Sequence

Started at 100001

1969 Chevrolet Camaro Options

Code	Description	Price
AS1	Front Shoulder Belts	$23.20
AS4	Custom Deluxe Rear Shoulder Belts	$26.35
AS5	Standard Rear Shoulder Belts	$23.20
A01	Soft-Ray All Tinted Glass	$32.65
A31	Power Windows	$105.35
A39	Custom Deluxe Front and Rear Shoulder Belts	$9.00
A67	Rear Folding Seat	$42.15
A85	Custom Deluxe Front Shoulder Belts	$26.35
B37	Color Keyed Floor Mats	$11.60
B93	Door Edge Guards	$4.25
CE1	Headlight Flasher	$15.80
C06	Power Convertible Top (Convertible)	$52.70
C08	Vinyl Roof Cover (Sport Coupe)	$84.30
C50	Rear Window Defroster	$22.15
C60	Air Conditioning	$376.00
DX1	Front Accent Striping	$25.30
D33	Left-Hand Remote Controlled Outside Rearview Mirror	$10.55
D34	Visor-Vanity Mirror	$3.20
D55	Center Front Seat Console	$53.75
D80	Spoiler	$32.65
D90	Sport Striping	$25.30
D96	Fender Striping	$15.80
F41	Heavy-Duty Sport Suspension	$10.55
GT1	Optional Rear Axle Ratio 2.56	$2.15
G31	Special Heavy-Duty Rear Springs	$20.05
G76	Optional Rear Axle Ratio 3.36	$2.15
G80	Positraction Rear Axle	$41.15
G92	Optional Rear Axle Ratio 3.08 (Performance / High Altitude)	$2.15
G96	Optional Rear Axle Ratio 3.55	$2.15
G97	Optional Rear Axle Ratio 2.73	$2.15
H01	Optional Rear Axle Ratio 3.07	$2.15
JL8	Power Four-Wheel Disc Brakes	$500.30
J50	Power Brakes	$42.15
J52	Power Front Disc Brakes	$64.25
KD5	Positive Crankcase Ventilation	$6.35
K02	Temperature Controlled Fan	$15.80
K05	Engine Block Heater	$10.55
K79	42-Amp Delcotron Alternator	$10.55
K85	63-Amp Delcotron Alternator	$26.35
LM1	350 cid/255-hp V-8	$52.70
L22	250 cid/155-hp Six Cylinder	$26.35
L34	396 cid/350-hp V-8 (SS Only)	$184.35
L35	396 cid/325-hp V-8 (SS Only)	$63.20
L48	350-cid/300-hp V-8 (Base SS)	Included in SS Package
L65	350 cid/250-hp V-8	$21.10
L78	396 cid/375-hp V-8	$316.00
L78/L89	396 cid/375-hp V-8 w/ Aluminum Heads (SS Only)	$710.95
MB1	Torque Drive Transmission (6-Cyl only)	$68.65
MC1	Special 3-Speed Manual Transmission	$79.00
M11	Floor Mounted Gearshift Lever	$10.55
M20	Wide-Ratio 4-Speed Manual Transmission	$195.40
M21	Close-Ratio 4-Speed Manual Transmission	$195.40
M22	Close-Ratio Heavy-Duty 4-Speed Manual Transmission	$322.10
M35	Powerglide Automatic Transmission w/ Six-Cylinder Engine	$163.70
M40	Turbo Hydra-Matic Transmission	$190.10
NC8	Chambered Dual Exhaust System	$15.80
N10	Dual Exhaust System	$30.55
N33	Comfortilt Steering Wheel	$45.30
N34	Walnut- Grained Steering Wheel	$34.80
N40	Power Steering	$94.80
N44	"Quick-Response" Variable-Ratio Steering	$5.80
N65	Spacesaver Spare Tire	$19.00
N66	Chevelle SS Type Wheel	$75.00
N95	Simulated Wire Wheel Covers	$73.75
N96	Mag-Style Wheel Covers	$73.75
PA2	Mag-Spoke Wheel Covers	$73.75
PK8	E78-14 White Sidewall Tires	$32.10
PL5	F70-14 White Letter Tires	$63.05
PW7	F70-14 White Stripe Tires	$62.60
PW8	F70-14 Red Stripe Tires	$62.60
PY4	F70-14 Fiberglass-Belted White Stripe Tires	$88.60
PY5	F70-14 Fiberglass-Belted Red Stripe Tires	$88.60
P01	Bright Metal Wheel Covers	$21.10
P06	Wheel Trim Rings	$21.10
T60	Heavy-Duty Battery	$8.45
U15	Speed Warning Indicator	$11.60
U16	Tachometer	$52.70
U17	Special Instrumentation	$94.80
U35	Electric Clock	$15.80
U46	Light Monitoring System	$26.35
U57	Stereo Tape Player	$133.80
U63	AM Radio	$61.10
U69	AM/FM Radio	$133.80
U73	Manual Rear-Mounted Radio Antenna	$9.50
U79	Push Button AM/FM Stereo Radio	$239.10
U80	Rear Seat Speaker	$13.20
VE3	Special Body Color Front Bumper	$42.15
V01	Heavy-Duty Radiator	$14.75
V31	Front Bumper Guard	$12.65
V32	Rear Bumper Guard	$12.65
V75	Liquid Tire Chain	$23.25
ZJ7	Rally Wheels	$35.85
ZJ9	Auxiliary Lighting	$13.70
ZK3	Custom Deluxe Seat and Shoulder Belts	$12.10
ZL2	Special Cold Air Induction Hood (SS or Z/28 Only)	$79.00
Z11	Special Indy 500 Convertible Package	$36.90
Z21	Style Trim	$47.40
Z22	Rally Sport Package	$131.65
Z23	Special Interior Group	$17.95
Z27	Camaro Super Sport Package	$295.95
Z28	Special Performance Package	$458.15
Z87	Custom Interior / Two Tone Paint	$142.20

1969 Chevrolet Camaro Engine Options

Location Of Engine Code: 6-Cyl-- Stamped on a pad behind the distributor on right side of block. 8-Cyl-- Stamped on the block in front of the right hand cylinder head.

Letter Code	Engine	Horsepower	Torque	Transmission	Carburetor
AM	6-230	140	220	Manual 3 & 4-Speed	1 BC
AN	6-230	140	220	Powerglide & Torque Drive	1 BC
AO	6-230	140	220	Turbo Hydra-Matic 350	1 BC
AP %	6-230	140	220	Manual 3 & 4-Speed	1 BC
AQ %	6-230	140	220	Powerglide & Torque Drive	1 BC
AR %	6-230	140	220	Turbo Hydra-Matic 350	1 BC
BB	6-250	155	235	Powerglide & Torque Drive	1 BC
BC %	6-250	155	235	Powerglide & Torque Drive	1 BC
BD	6-250	155	235	Turbo Hydra-Matic 350	1 BC
BE	6-250	155	235	Manual 3 & 4-Speed	1 BC
BF %	6-250	155	235	Manual 3 & 4-Speed	1 BC
BH %	6-250	155	235	Turbo Hydra-Matic 350	1 BC
DA	8-307	200	300	Manual 3-Speed	2 BC
DC	8-307	200	300	Powerglide	2 BC
DD	8-307	200	300	Turbo Hydra-Matic 350	2 BC
DE	8-307	200	300	Manual 4-Speed	2 BC
DZ	8-302	290	290	Manual 4-Speed	4 BC
FJ	8-327	210	320	Manual 3 & 4-Speed	2 BC
FK	8-327	210	320	Powerglide	2 BC
FL	8-327	210	320	Turbo Hydra-Matic 350	2 BC
HA	8-350	300	380	Manual 3 & 4-Speed	4 BC
HB	8-350	300	380	Turbo Hydra-Matic 350	4 BC
HC	8-350	250	345	Manual 3 & 4-Speed	2 BC
HD	8-350	250	345	Turbo Hydra-Matic 350	2 BC
HE	8-350	300	380	Powerglide	4 BC
HF	8-350	250	345	Powerglide	2 BC
HP	8-350	300	380	Manual (Heavy Duty Clutch)	4 BC
HQ	8-350	255	365	Manual 3 & 4-Speed	4 BC
HR	8-350	255	365	Powerglide	4 BC
HS	8-350	255	365	Turbo Hydra-Matic 350	4 BC
JB	8-396 (E)	325	410	Powerglide	4 BC
JF	8-396 (E)	350 +	415	Manual 4-Speed	4 BC
JG	8-396 (E)	325	410	Turbo Hydra-Matic 400	4 BC
JH	8-396 (E)	375 #	415	Manual 4-Speed	4 BC
JI	8-396 (E)	350 +	415	Turbo Hydra-Matic 400	4 BC
JJ	8-396	(A.H.)	415	Manual 4-Speed	4 BC
JL	8-396 (E)	375 #	415	Turbo Hydra-Matic 400	4 BC
JM	8-396	(A.H.)	415	Turbo Hydra-Matic 400	4 BC
JU	8-396 (E)	325	410	Manual 3 & 4-Speed	4 BC
KA	8-396 (E)	350 +	415	Manual (Heavy Duty Clutch)	4 BC
KC	8-396 (E)	375 #	415	Manual (Heavy Duty Clutch)	4 BC
KE	8-396	(A.H.)	415	Manual (Heavy Duty Clutch)	4 BC
KL	8-396	375	415	Not Available	4 BC
ME	8-427	430 (A.H.)	460	Manual (Heavy Duty Clutch)	4 BC
MG	8-427	430 (A.H.)	460	Manual (Heavy Duty Clutch)	4 BC
CJB	8-396 (L)	325	410	Powerglide	4 BC
CJF	8-396 (L)	350 +	415	Manual 4-Speed	4 BC
CJG	8-396 (L)	325	410	Turbo-Hydramatic 400	4 BC
CJH	8-396 (L)	375 #	415	Manual 4-Speed	4 BC
CJI	8-396 (L)	350 +	415	Turbo-Hydramatic 400	4 BC
CJL	8-396 (L)	375 #	415	Turbo Hydra-Matic 400	4 BC
CJU	8-396 (L)	325	410	Manual 3 & 4-Speed	4 BC

Notes:

(p) Police
(t) Taxi
(A.H.) Aluminum Heads
(E) 1st design; 396 cu. in.
(L) 2nd design; 402 cu. in.
+ High Performance
# Special High Performance
% Used w/ Air Conditioning

Transmission Codes

Transmission	Location
Powerglide (Corvair)	On top of the case in the rear at 11 o'clock.
Powerglide Passenger (exc. Corvair)	Immediately behind right hand machining lug with the bottom of the sticker parallel to mold flash.
Powerglide	All models stamped on the right side of transmission oil pan.
Turbo Hydra-Matic	Right hand vertical surface of transmission case
3-Speed	Corvair and fully synchronized Passenger (exc. Warner Gear) transmissions stamped on square boss on left side below and rear of cover
4-Speed	Passenger models (exc. Corvair) stamped on right side of case ahead of the extension.
4-Speed (Corvair)	Stamped on boss on lower left side of case just below side cover.

Plant and Type Designation Prefix	Plant	Transmission Type
N	Muncie	4-Speed
W	Warner Gear	3 and 4-Speed
P	Muncie	4-Speed
R	Saginaw	4-Speed
S	Saginaw	3-Speed
M	Muncie	3-Speed, Overdrive*
C	Cleveland	Powerglide
T	Toledo	Powerglide
CA	Hydra-Matic	3-Speed, Automatic Turbo Hydra-Matic
D	Saginaw	Overdrive
K	McKinnon	3-Speed
E	McKinnon	Powerglide
O	Saginaw	Overdrive
X	Cleveland	Turbo Hydra-Matic 350
B	Cleveland	Turbo Hydra-Matic 350
Y	Toledo	Turbo Hydra-Matic 350
A	Cleveland	2-Speed, Manual Powerglide

*Overdrive distinguished from 3-Speed by physical appearance only. The above transmissions (exc. Warner Gear) will carry a production code number such as: C1116N (C = Cleveland Powerglide, 11 = November, 16 = 16th, N = Night Shift). The Warner Gear transmissions will carry a production code number such as: WG1031 (W = Warner Gear 4-Spd., G = July, 10 = 10th, 7 = 1967, 1 = First Shift).

Axle Codes

Location Of Axle Codes: The axles for Chevrolet will be built by Chevrolet Buffalo, Chevrolet Gear and Axle, Buick, Oldsmobile, and McKinnon. Divisional Manufacturer code letters will be metal stamped on the axle tube adjacent to the carrier for identification. Metal stamp on left rear axle tube on the rear side, letters and numerals 3/16 in. high, 3 in. outboard of carrier.

Codes - Non-Locking	Codes - Locking	Ratio	Inspection Cover
BA, PB, PY	BB, PC, PZ, QS	2.56	10 Bolt, 12 Bolt
BC	BD	3.36	10 Bolt
BI, BP	BQ, PX, QT	2.73	10 Bolt, 12 Bolt
BL	BR, QU	3.07	12 Bolt
BM	BS, QV	3.31	12 Bolt
BN	BT, QW	3.55	12 Bolt
BO	BU, QX	3.73	12 Bolt
	BV, QY	4.10	12 Bolt
	BW, QZ	4.56	12 Bolt
	BX, QN	4.88	12 Bolt
PA	PE	3.08	10 Bolt

Manufacturer Identity
B - Buick	C - Chevrolet Buffalo
O - Oldsmobile	K - GM of Canada, St. Catharines
P - Pontiac	M - GM of Canada
G - Chevrolet Gear & Axle

Paint Codes - Exterior Colors

Color Name / Code	Color Image	Color Name / Code	Color Image
10 - Tuxedo Black Lucite® Code - 88L Dulux® Code - 93-005		61 - Burnished Brown (metallic) Lucite® Code - 5011L Dulux® Code - 5011D
40 - Butternut Yellow Lucite® Code - 5036L Dulux® Code - 5036D		63 - Champagne (metallic) Lucite® Code - 5046L Dulux® Code - 5046D
50 - Dover White Lucite® Code - 5033L Dulux® Code - 5033D		65 - Olympic Gold (metallic) Lucite® Code - 5010L Dulux® Code - 5010D
51 - Dusk Blue (metallic) Lucite® Code - 5016L Dulux® Code - 5016D		67 - Burgundy (metallic) Lucite® Code - 5036LH Dulux® Code - 5036DH
52 - Garnet Red Lucite® Code - 5009LH Dulux® Code - 5009DM		69 - Cortez Silver (metallic) Lucite® Code - 5032L Dulux® Code - 5032D
53 - Glacier Blue (metallic) Lucite® Code - 5015L Dulux® Code - 5015D		71 - LeMans Blue (metallic) Lucite® Code - 5030L Dulux® Code - 5030D
55 - Azure Turquoise (metallic) Lucite® Code - 5014L Dulux® Code - 5014D		72 - Hugger Orange Lucite® Code - 5021LM Dulux® Code - 5021DH
57 - Fathom Green (metallic) Lucite® Code - 5013L Dulux® Code - 5013D		76 - Daytona Yellow Lucite® Code - 5026LH Dulux® Code - 5026D
59 - Frost Green (metallic) Lucite® Code - 5012L Dulux® Code - 5012D		79 - Rallye Green (metallic) Lucite® Code - 5070L Dulux® Code - 5070DH
NOTES: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination 51-50 on a Chevrolet would indicate the body finished in Dusk Blue and the roof area in Dover White.) General Motors paint code plate for all models except Corvair and Corvette is located under the hood at the top of the firewall on the left or right of the upper shroud. Corvair paint code plate is on the left cross-rail in the engine compartment. Corvette paint code plate is on the instrument panel brace, below the glove compartment.

Paint Codes - Interior Colors

Color Name / Code	Color Image	Color Name / Code	Color Image
Medium Gold (semi-gloss) Lucite® Code - 9594L		Medium Turquoise (metallic) (semi-gloss) Lucite® Code - 9587LH
Dark Gold Lucite® Code - 9590L (semi-gloss) Lucite® Code - 9583L (flat)		Dark Turquoise (metallic) Lucite® Code - 9588LH (semi-gloss) Lucite® Code - 9579LH (flat)
Saddle (semi-gloss) Lucite® Code - 9475L		Medium Blue (metallic) (semi-gloss) Lucite® Code - 9585LH
Dark Saddle (metallic) Lucite® Code - 9488L (semi-gloss) Lucite® Code - 9458L (flat)		Dark Blue (metallic) Lucite® Code - 9586LH (semi-gloss) Lucite® Code - 9578LH (flat)
Medium Green (metallic) (semi-gloss) Lucite® Code - 9591LH		Medium Red (semi-gloss) Lucite® Code - 9528LH
Dark Green (metallic) Lucite® Code - 9592LH (semi-gloss) Lucite® Code - 9581LH (flat)		Dark Red Lucite® Code - 9429LM (semi-gloss) Lucite® Code - 9580LM (flat)
Midnight Green (metallic) Lucite® Code - 9593LH (semi-gloss) Lucite® Code - 9582LH (flat)		Black Lucite® Code - 88L (semi-gloss) Lucite® Code - 4428L (flat)
NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use 1/2 oz. DuPont #4528 flattening compound to a pint of unreduced color.

Striping Colors

Black Lucite® Code - 88L	Red Lucite® Code - 5027LH	White Lucite® Code - 5033L	Gold Lucite® Code - 9669L
Light Blue Lucite® Code - 9670L	Light Green Lucite® Code - 9671L	Bright Blue Lucite® Code - 9672L

Trunk Colors (spatter finish)

Black - Gray - Aqua 389 - 259

GM Roof Moldings Colors (Matched To Vinyl Roof Colors)

Fisher W Code	Roof Color Code	Color	Lucite® Code	Aprox. Amount Of 5528S To Be Added For Correct Gloss
848	B	Black	9333L	2 oz.
3943	E	Parchment	9680L	1 oz.
