1971 Dodge Coronet
1971 Dodge Coronet

1971 Dodge Coronet

Coronet and Charger lines were separated and now Coronet's were only offered as 4 door sedans or station wagons with an increased wheelbase totaling 118 inches. The modestly styled rear end gave a "Coke bottle" appearance with 2 large rectangular taillights located in the rear bumper. Standard features on the base models included color coordinated floor mats, rear ashtray, and a 2-spoke steering wheel. Station wagon models came with heavy duty brakes and 2-way tailgate. New for 1971 was the Brougham and Crestwood series. The Brougham was the top trim line of the Coronet while the Crestwood was the top of the line in Station Wagons. Features on the Brougham included cloth and vinyl interior, split-back seats, center fold down armrests, hound's tooth upholstery, and a Charger instrument cluster. A standard V8 engine rated at 300 hp with 410-ft.-lbs of torque with 8.5 to 1 compression ratio was available on the Brougham and no option of a 6-cylinder.




1971 Dodge Coronet Factory Specifications & Production

Model Number Body/Style Number Body Type & Seating

Factory Price
(6-cyl)

Factory Price
(V8)
Shipping Weight
(6-cyl)
Shipping Weight
(V8)
Total Production
Coronet Series
WL41 41 4 dr Sedan - 6P $2,777 $2,872 3,245 lbs 3,360 lbs 11,794
WL45 45 4 dr Station Wagon - 6P $3,101 $3,196 3,745 lbs 3,810 lbs 5,470
Coronet Custom Series
WM41 41 4 dr Sedan - 6P $2,951 $3,046 3,250 lbs 3,365 lbs 37,817
WM45 45 4 dr Station Wagon - 6P $3,278 $3,373 3,750 lbs 3,815 lbs 5,365
WM46 46 4 dr Station Wagon - 9P - $3,454 - 3,890 lbs 5,717
Coronet Brougham/Crestwood Series
WH41 41 4 dr Sedan - 6P - $3,332 - 3,375 lbs 4,700
WH45 45 4 dr Station Wagon - 6P - $3,601 - 3,845 lbs 2,884
WH46 46 4 dr Station Wagon - 9P - $3,682 - 3,900 lbs 3,981

Chassis Specifications

Model Wheelbase Overall Length Width Front Track Rear Track Tires
Coronet 118 in 207 in 78.6 in 59.7 in 62 in E78 x 14
Coronet Station Wagon 118 in 214 in 78.6 in 59.7 in 62 in H78 x 14

VIN Decoding

Serial Numbers were on the instrument panel, visible thru the windshield, and on the bottom line of a separate plate(fender tag) under the hood.

Dodge Fender Tag
First Symbol - Car Line
D - Dodge 122" W - Dodge 117/118"
L - Dart W - Charger/Coronet
J - Challenger X - Charger
Second Symbol - Price Class
E - Economy S - Special
L - Low X - Fast Top
M - Medium K - Police
H - High O - Superstock
P - Premium T - Taxi
Third & Fourth Symbol - Body Type
21 - 2 Dr. Sedan 41 - 4 Dr. Sedan
23 - 2 Dr. Hardtop 43 - 4 Dr. Hardtop
27 - 2 Dr. Convertible 45 - Station Wagon 2-Seat
29 - 2 Dr. Sports Hardtop 46 - Station Wagon 3-Seat
Fifth Symbol - Engine
(B) 6-198 (N) 8-383
(C) 6-225 (N) 8-383
(E) 6-Special Order (R) 8-426 HEMI
(G) 8-318 (T) 8-440
(H) 8-340 (U) 8-440
(J) 8-340 (V) 8-440
(L) 8-383 (Z) 8-Special Order
Sixth Symbol - Model Year
6 - 1966 1 - 1971
7 - 1967 2 - 1972
8 - 1968 3 - 1973
9 - 1969 4 - 1974
0 - 1970 5 - 1975
Seventh Symbol - Assembly Plant
(A) Lynch Road, Michigan (E) Los Angeles, California
(B) Hamtramck, Michigan (F) Newark, Deleware
(C) Jefferson, Michigan (G) St. Louis, Missouri
(D) Belvedere, Illinois (R) Windsor, Ontario, Canada
Last Six Symbols - Production Sequence
Started at 100001



Available Transmissions

Transmission Location
TorqueFlite Stamped on the transmission oil pan rail.
3-Speed Manual Not Available
4-Speed Manual Not Available

Identification Number Transmission Type
3535804 TorqueFlite
3515806 TorqueFlite
3515841 TorqueFlite
3515842 TorqueFlite
3515843 TorqueFlite
3515844 TorqueFlite
3515845 TorqueFlite
3515846 TorqueFlite
3515847 TorqueFlite
3515848 TorqueFlite
3515849 TorqueFlite
3515850 TorqueFlite
3515851 TorqueFlite
3515852 TorqueFlite



Interior and Exterior Paint Chips

  • 1971 Dodge Exterior Paint Codes.

    The first Paint Code identifies the roof or accent color. The second Paint Code identifies the body color. (For example, the combination X9-B2 on a Dodge would indicate the roof or accent area is in Black and the body is finished in Light Blue Metallic.) Paint code plates are located in the engine compartment on the left wheel housing, the fender side shield, or the radiator yoke.

Color Name / Code Color Image Color Name / Code Color Image

A4 - Light Gunmetal Metallic
Lucite® Code - 5245L
"Centari" Code - 5245A
Dulux® Code - 5245D

K6 - Dark Bronze Metallic
Lucite® Code - 5257LM
"Centari" Code - 5257AW
Dulux® Code - 5257DH

A8 - Dark Gray Metallic
Lucite® Code - 5246L
"Centari" Code - 5246A
Dulux® Code - 5246D

L5 - Butterscotch
Lucite® Code - 5267L
"Centari" Code - 5267A
Dulux® Code - 5267D
B2 - Light Blue Metallic
Lucite® Code - 5247L
"Centari" Code - 5247A
Dulux® Code - 5247D
Q5 - Turquoise Metallic
Lucite® Code - 5268LH
"Centari" Code - 5268A
Dulux® Code - 5268D

B5 - Bright Blue Metallic
Lucite® Code - 5251L
"Centari" Code - 5251A
Dulux® Code - 5251D

T2 - Tan Metallic
Lucite® Code - 5259L
"Centari" Code - 5259A
Dulux® Code - 5259D

B7 - Dark Blue Metallic
Lucite® Code - 5249L
"Centari" Code - 5249A
Dulux® Code - 5249D

T8 - Dark Tan Metallic
Lucite® Code - 5260LH
"Centari" Code - 5260A
Dulux® Code - 5260D

C7 - Plum Metallic
Lucite® Code - 5182LM
"Centari" Code - 5182AW
Dulux® Code - 5182DH

V2 - Hemi Orange
Lucite® Code - 5067LH
"Centari" Code - 5067A
Dulux® Code - 5067DH

C8 - Indigo Metallic
Lucite® Code - 5265LH
"Centari" Code - 5265AM
Dulux® Code - 5265DH

W1 - White
Lucite® Code - 4996L
"Centari" Code - 4996A
Dulux® Code - 4996D

E5 - Bright Red
Lucite® Code - 5092LM
"Centari" Code - 5092AW
Dulux® Code - 5092DM

W3 - Brite White
Lucite® Code - 5265L
"Centari" Code - 5265A
Dulux® Code - 5265D
E7 - Burgundy Metallic
Lucite® Code - 5253LM
"Centari" Code - 5253AW
Dulux® Code - 5253DH
X9 - Black
Lucite® Code - 99L
"Centari" Code - 99A
Dulux® Code - 93-005
F3 - Medium Green Metallic
Lucite® Code - 5254L
"Centari" Code - 5254A
Dulux® Code - 5254D
Y3 - Citron Yella
Lucite® Code - 5308LH
"Centari" Code - 5308AH
Dulux® Code - 5308DH
F7 - Dark Green Metallic
Lucite® Code - 5255L
"Centari" Code - 5255A
Dulux® Code - 5255D
Y4 - Gold
Lucite® Code - 5263L
"Centari" Code - 5263A
Dulux® Code - 5263D
J4 - Moss Green Metallic
Lucite® Code - 5307LM
"Centari" Code - 5307AW
Dulux® Code - 5307DH
Y8 - Gold Metallic
Lucite® Code - 5309LH
"Centari" Code - 5309AM
Dulux® Code - 5309DH
J6 - Green Go
Lucite® Code - 5127L
"Centari" Code - 5127A
Dulux® Code - 5127D
Y9 - Dark Gold Metallic
Lucite® Code - 5266LH
"Centari" Code - 5266AM
Dulux® Code - 5266DM

  • 1971 Dodge Interior Paint Codes

Color Name / Code Color Image Color Name / Code Color Image
White
Lucite® Code - 9845L
Dark Green Metallic
Lucite® Code - 9836LH
Light Gold
Lucite® Code - 9847L
Light Blue Metallic
Lucite® Code - 9832L
Light Gold Metallic
Lucite® Code - 9837L
Medium Blue Metallic
Lucite® Code - 9834L
Medium Gold Metallic
Lucite® Code - 9846LH
Bright Blue Metallic
Lucite® Code - 9833L
Medium Dark Saddle
Lucite® Code - 9839L
Medium Blue Gray Metallic
Lucite® Code - 9843L
Medium Russet
Lucite® Code - 9840L
Black
Lucite® Code - 9844

Trunk Colors (spatter finish)

Three-Tone Black & Gray = 389-2076
