1967 Dodge Coronet

Many Mopar fans were weekend racers in the 1960's and the Coronet R/T was a popular choice both on the
road and track. The R/T package included non-functional hood scoops and simulated rear fender air vents,
stiffer suspension, heavy duty brakes, and red streak tires. Production was 10,181, including 628 Convertibles.

The standard engine option was the Magnum 440 w/ 375 horsepower that was hooked to a four-speed or TorqueFlite transmission. One recorded '67 Coronet R/T finished 0-60 mph in 7.2 seconds, and the quarter mile in 15.4 seconds. However the Hemi option was available on special order and for just under $1000.00 more you could add this to your package. Only 238 Coronet R/T's were optioned with the Hemi engine.

1967 Dodge Coronet Factory Specifications & Production

Model Number	Body/Style Number	Body Type & Seating	Factory Price (6-cyl)	Factory Price (V8)	Shipping Weight (6-cyl)	Shipping Weight (V8)	Total Production
Coronet Deluxe Series
CW1/2L	41	4 dr Sedan - 6P	$2,397	$2,491	3,070 lbs	3,235 lbs	Note 1
CW1/2L	21	2 dr Sedan - 6P	$2,359	$2,453	3,045 lbs	3,210 lbs	Note 1
CW1/2L	45	4 dr Station Wagon - 6P	$2,693	$2,787	3,495 lbs	3,625 lbs	Note 2
Coronet 400 Series
CW1/2H	41	4 dr Sedan - 6P	$2,475	$2,569	3,060 lbs	3,225 lbs	Note 3
CW1/2H	23	2 dr Hardtop Coupe - 6P	$2,500	$2,594	3,065 lbs	3,235 lbs	Note 3
CW1/2H	27	2 dr Convertible - 6P	$2,740	$2,634	3,140 lbs	3,305 lbs	Note 3
CW1/2H	45	4 dr Station Wagon - 6P	$2,771	$2,865	3,495 lbs	3,605 lbs	Note 2
CW2H	46	4 dr Station Wagon - 9P	-	$2,975	-	3,705 lbs	Note 2
Coronet 500 Series
CW1/2P	41	4 dr Sedan - 6P	$2,654	$2,748	3,075 lbs	3,235 lbs	Note 4
CW1/2P	23	2 dr Hardtop Coupe - 6P	$2,679	$2,773	3,115 lbs	3,280 lbs	Note 4
CW1/2P	27	2 dr Convertible - 6P	$2,919	$3,013	3,190 lbs	3,335 lbs	Note 4
Coronet R/T Series
CW2P	23	2 Dr Hardtop Coupe - 6P	-	$3,128	-	3,565 lbs	9,553
CW2P	27	2 dr Convertible - 6P	-	$3,438	-	3,640 lbs	628

Notes:

1. 27,800 Coronet Deluxe's were built; 14,100 were 6-cylinders and 13,700 were V8's (totals are rounded off to the nearst 100).
2. 24,200 Station wagons were built in both Deluxe and 440 trim lines; 3,300 were 6-cylinders and 20,900 were V8's (totals are rounded off to the nearst 100).
3. 92,500 Coronet 440 cars were built; 8,600 were 6-cylinders and 83,900 were V8's (totals are rounded off to the nearst 100).
4. 29,300 Doronet 500 cars were built; 400 were 6-cylinders and 28,900 were V8's (totals are rounded off to the nearst 100).

Chassis Specifications

Model	Wheelbase	Overall Length	Width	Front Track	Rear Track	Tires ( 6-cylinder)	Tires (V8)
Coronet	117 in	203 in	Not Available	Not Available	Not Available	7.35 x 14	7.35 x 14
Coronet Station Wagons	117 in	207.9 in	Not Available	Not Available	Not Available	7.75 x 14	8.25 x 14

VIN Decoding

Serial Numbers were on the instrument panel, visible thru the windshield, and on the bottom line of a separate plate(fender tag) under the hood.

First Symbol - Car Line D - Dodge 122" W - Dodge 117/118" L - Dart W - Charger/Coronet J - Challenger X - Charger

Second Symbol - Price Class E - Economy S - Special L - Low X - Fast Top M - Medium K - Police H - High O - Superstock P - Premium T - Taxi Third & Fourth Symbol - Body Type 21 - 2 Dr. Sedan 41 - 4 Dr. Sedan 23 - 2 Dr. Hardtop 43 - 4 Dr. Hardtop 27 - 2 Dr. Convertible 45 - Station Wagon 2-Seat 29 - 2 Dr. Sports Hardtop 46 - Station Wagon 3-Seat

Fifth Symbol - Engine (B) 6-198 (N) 8-383 (C) 6-225 (N) 8-383 (E) 6-Special Order (R) 8-426 HEMI (G) 8-318 (T) 8-440 (H) 8-340 (U) 8-440 (J) 8-340 (V) 8-440 (L) 8-383 (Z) 8-Special Order

Sixth Symbol - Model Year 6 - 1966 1 - 1971 7 - 1967 2 - 1972 8 - 1968 3 - 1973 9 - 1969 4 - 1974 0 - 1970 5 - 1975 Seventh Symbol - Assembly Plant (A) Lynch Road, Michigan (E) Los Angeles, California (B) Hamtramck, Michigan (F) Newark, Deleware (C) Jefferson, Michigan (G) St. Louis, Missouri (D) Belvedere, Illinois (R) Windsor, Ontario, Canada Last Six Symbols - Production Sequence Started at 100001



Letter Code	Engine	Horsepower	Torque	Transmission	Carburetor
A	6-170	115	155	TorqueFlite, 3-Speed Manual	1 BC
B	6-225	145	215	TorqueFlite, 3-Speed Manual	1 BC
C	6-Special Order	Not Available	Not Available	TorqueFlite, 3-Speed Manual	Not Available
D	8-273	180	260	TorqueFlite, 3 & 4-Speed Manual	2 BC
E	8-273	235	260	TorqueFlite, 3 & 4-Speed Manual	4 BC
F	8-318	230	340	TorqueFlite, 3 & 4-Speed Manual	2 BC
G	8-383	270	390	TorqueFlite, 3 & 4-Speed Manual	2 BC
G	8-383	280	410	TorqueFlite, 3 & 4-Speed Manual	4 BC
H	8-383	325 *	425	TorqueFlite, 3 & 4-Speed Manual	4 BC
J	8-426 HEMI	425	490	TorqueFlite, 3 & 4-Speed Manual	4 BC
K	8-440	350	480	TorqueFlite, 3 & 4-Speed Manual	4 BC
L	8-440 *	375	480	TorqueFlite, 3 & 4-Speed Manual	4 BC
M	8-Special Order	Not Available	Not Available	TorqueFlite, 3 & 4-Speed Manual	Not Available

Available Transmissions

Transmission	Location
TorqueFlite	Stamped on the transmission oil pan rail.
3-Speed Manual	Not Available
4-Speed Manual	Not Available

Identification Number	Transmission Type
2801532	TorqueFlite
2801533	TorqueFlite
2801534	TorqueFlite
2801535	TorqueFlite
2801536	TorqueFlite
2801539	TorqueFlite
2801540	TorqueFlite
2801541	TorqueFlite
2801542	TorqueFlite
2801543	TorqueFlite
2801544	TorqueFlite



Interior and Exterior Paint Chips

• 1967 Dodge Exterior Paint Codes.

  The first letter or number identifies the roof or accent color. The second letter or number identifies the body color. (For example, the combination WC on a Dodge would indicate the roof or accent area is in White and the body is finished in Medium Blue Metallic.) Paint code plates are located in the engine compartment on the left wheel housing or the left fender side shield.

Color Name / Code	Color Image	Color Name / Code	Color Image
A - Silver Metallic Lucite® Code - 4656L Duco® Code - 4656 Dulux® Code - 181-97397		P - Red Lucite® Code - 4770LH Duco® Code - 4770H Dulux® Code - 93-97813M
B - Black Lucite® Code - 88L Duco® Code - 44 Dulux® Code - 93-005		Q - Dark Red Lucite® Code - 4810LM Duco® Code - 4810M Dulux® Code - 4810DM
C - Medium Blue Metallic Lucite® Code - 4797L Duco® Code - 4797 Dulux® Code - 4797D		R - Yellow Lucite® Code - 4698L Duco® Code - 4698 Dulux® Code - 93-97768
D - Light Blue Metallic Lucite® Code - 4758L Duco® Code - Not Available Dulux® Code - 181-97801		S - Cream Lucite® Code - 4764L Duco® Code - 4764 Dulux® Code - 93-97807
E - Dark Blue Metallic Lucite® Code - 4757LH Duco® Code - Not Available Dulux® Code - 181-97800H		T - Medium Copper Metallic Lucite® Code - 4808L Duco® Code - 4808 Dulux® Code - 4808D
F - Light Green Metallic Lucite® Code - 4801L Duco® Code - 4801 Dulux® Code - 4801D		W - White Lucite® Code - 4559L Duco® Code - 4559 Dulux® Code - 93-97054
G - Dark Green Metallic Lucite® Code - 4800L Duco® Code - 4800 Dulux® Code - 4800DH		X - Light Tan Lucite® Code - 4806L Duco® Code - 4806 Dulux® Code - 4806D
H - Dark Copper Metallic Lucite® Code - 4807LH Duco® Code - 4807H Dulux® Code - 4807DM		Y - Medium Tan Metallic Lucite® Code - 4805L Duco® Code - 4805 Dulux® Code - 4805D
J - Chestnut Metallic Lucite® Code - 4804LH Duco® Code - 4804H Dulux® Code - 4804DH		Z - Gold Metallic Lucite® Code - 4802L Duco® Code - 4802 Dulux® Code - 4802D
K - Medium Turquoise Metallic Lucite® Code - 4799L Duco® Code - 4799 Dulux® Code - 4799D		6 - Mauve Metallic Lucite® Code - 4809L Duco® Code - 4809 Dulux® Code - 4809D
L - Dark Turquoise Metallic Lucite® Code - 4798L Duco® Code - 4798 Dulux® Code - 4798D		8 - Bright Blue Metallic Lucite® Code - 4812L Duco® Code - 4812 Dulux® Code - 4812D
M - Bronze Metallic Lucite® Code - 4761LH Duco® Code - Not Available Dulux® Code - 181-98406H

• 1967 Dodge Interior Paint Codes


Color Name / Code	Color Image	Color Name / Code	Color Image
GLOSS COLORS (note 2)
White	See Code W	Academy Blue Metallic	See Code E
Copper Dust Metallic	See Code T	Cardinal Red Metallic	See Code Q
Desert Tan Metallic	See Code Y	Raven Black	See Code B
Indian Turquoise Metallic	See Code L
LOW GLOSS COLORS (note 3)
Dove White Lucite® Code - 9130L	Not Available / See Note 1	Copper Brown Metallic (Dark) Lucite® Code - 9341LM	Not Available / See Note 1
White Lucite® Code - 9070L	Not Available / See Note 1	French Turquoise Metallic (Pale) Lucite® Code - 9646LH	Not Available / See Note 1
Doric Gold Metallic Lucite® Code - 9338L	Not Available / See Note 1	Indian Turquoise Metallic (Dark) Lucite® Code - 9334LH	Not Available / See Note 1
Aztec Gold Metallic (Dark) Lucite® Code - 9337LH	Not Available / See Note 1	Saxon Blue Metallic (Pale) Lucite® Code - 9352LH	Not Available / See Note 1
Desert Tan (Pale) Lucite® Code - 9340LH	Not Available / See Note 1	Academy Blue Metallic (Dark) Lucite® Code - 9232LH	Not Available / See Note 1
Chestnut Metallic Lucite® Code - 9339LH	Not Available / See Note 1	Medium Red Metallic Lucite® Code - 9238LM	Not Available / See Note 1
Copper Dust Metallic (Pale) Lucite® Code - 9342LM	Not Available / See Note 1	Jewel Black Lucite® Code - 88L	Not Available / See Note 1
FLAT COLORS
Aztec Gold Metallic Lucite® Code - 9350L		Ensign Blue Metallic Lucite® Code - 9242LH
Chestnut Metallic Lucite® Code - 9351L		Derby Red Lucite® Code - 4588LH
Copper Brown Metallic Lucite® Code - 9349LH		Satin Black Lucite® Code - 4428L
Indian Turquoise Metallic Lucite® Code - 9348LH

Trunk Colors (spatter finish)

Three-Tone Black & Gray = 389-2076



Interior Paint Notes:

1. Low Gloss Colors require 2 ounces of DuPont 4528S Flattening Compound to a pint of unreduced color.
2. Gloss Colors Usage - Quarter Panel Upper Garnish Moulding, Quarter Garnish Extension & Lock Pillar Upper, "A & B" Pillars and "B" Pillar Cap, Door & Quarter Upper Inner Frame and Upper & Lower Garnish, Miscellaneous Suburban Parts. * Suburban Bow Clips ONLY.
3. Low Gloss Colors Usage - Roof Rails, Backlite Mouldings, "A" Pillar Cover, Console, Manual Seat Adjuster, Windshield Garnish Mouldings, Convertible Top Mechanism, and Miscellaneous Suburban Parts.
