1969 Dodge Coronet
1969 Dodge Coronet

1969 Dodge Coronet

The Super Bee which was introduced mid-1968 now became a model in the Coronet Deluxe line up and is equipped with a 383 Magnum engine, 4-speed manual transmission and bumble bee stripes.

The middle of the line for Coronet was the 440 which included all of the same options as the Deluxe plus polished aluminum wheel lip moldings and carpet.  For the top of the line, the Coronet 500 came with a wood-grained instrument panel as well as map, ashtray and glovebox light.

The Coronet R/T came as a two-door hardtop or convertible and features a 440-cu.in. V8 engine with dual exhausts and a choice between a 4-speed manual transmission or 3-speed TorqueFlite automatic.

A trailer towing package was available on models with a 225 Six or Hemi V8 and can haul loads with a grossweight of 2,000lbs.



1969 Dodge Coronet Factory Specifications & Production

Model Number Body/Style Number Body Type & Seating

Factory Price
(6-cyl)

Factory Price
(V8)
Shipping Weight
(6-cyl)
Shipping Weight
(V8)
Total Production
Coronet Deluxe Series
WL41 Not Available 4 dr Sedan - 6P $2,589 $2,692 3,018 lbs 3,176 lbs Note 1
WL21 Not Available 2 dr Sedan - 6P $2,554 $2,657 2,988 lbs 3,146 lbs Note 1
WL45 Not Available 4 dr Station Wagon - 6P $2,992 $3,095 3,498 lbs 3,606 lbs Note 1
Coronet Deluxe Series - Super Bee
WM21 Not Available 2 dr Coupe - 6P - $3,076 - 3,440 lbs Note 2
WM23 Not Available 2 dr Hardtop Coupe - 6P - $3,138 - 3,470 lbs Note 2
Coronet 400 Series
WH41 Not Available 4 dr Sedan - 6P $2,670 $2,773 3,023 lbs 3,181 lbs Note 3
WH21 Not Available 2 dr Coupe - 6P $2,630 $2,733 2,983 lbs 3,151 lbs Note 3
WH23 Not Available 2 dr Hardtop Coupe - 6P $2,692 $2,795 3,018 lbs 3,176 lbs Note 3
WH45 Not Available 4 dr Station Wagon - 6P $3,033 $3,136 3,503 lbs 3,606 lbs Note 3
WH46 Not Available 4 dr Station Wagon - 9P - $3,246 - 3,676 lbs Note 3
Coronet 500 Series
WP41 Not Available 4 dr Sedan - 6P - $2,963 - 3,206 lbs Note 4
WP23 Not Available 2 dr Hardtop Coupe - 6P - $2,929 - 3,171 lbs Note 4
WP27 Not Available 2 dr Convertible - 6P - $3,069 - 3,306 lbs Note 4
WP45 Not Available 4 dr Station Wagon - 6P - $3,280 - 3,611 lbs Note 4
WP46 Not Available 4 dr Station Wagon - 9P - $3,392 - 3,676 lbs Note 4
Coronet R/T Series
WS23 Not Available 2 Dr Hardtop Coupe - 6P - $3,442 - 3,601 lbs Note 5
WS27 Not Available 2 dr Convertible - 6P - $3,660 - 3,721 lbs Note 5

Notes:

  1. 30,400 Coronet Deluxe's were built including Deluxe Station Wagons; 12,500 were 6-cylinders and 17,900 were V8's (totals are rounded off to the nearst 100).
  2. 27,800 Super Bees were built; ALL were V8's (totals are rounded off to the nearst 100).
  3. 105,900 Coronet 440 cars were built including Station Wagons; 4,700 were 6-cylinders and 101,200 were V8's (totals are rounded off to the nearst 100).
  4. 32,100 Coronet 500 cars were built including Station Wagons; ALL were V8's (totals are rounded off to the nearst 100).
  5. 7,200 Coronet R/T car were built; ALL were V8's (totals are rounded off to the nearst 100).

Chassis Specifications

Model Wheelbase Overall Length Width Front Track Rear Track Tires
Coronet 117 in 206.6 in 76.7 in Not Available Not Available 7.75 x 14
Coronet R/T 117 in 206.6 in 76.7 in Not Available Not Available F70 x 14
Coronet Station Wagon 117 in 210 in 76.7 in Not Available Not Available 8.25 x 14

VIN Decoding

Serial Numbers were on the instrument panel, visible thru the windshield, and on the bottom line of a separate plate(fender tag) under the hood.

Dodge Fender Tag
First Symbol - Car Line
D - Dodge 122" W - Dodge 117/118"
L - Dart W - Charger/Coronet
J - Challenger X - Charger
Second Symbol - Price Class
E - Economy S - Special
L - Low X - Fast Top
M - Medium K - Police
H - High O - Superstock
P - Premium T - Taxi
Third & Fourth Symbol - Body Type
21 - 2 Dr. Sedan 41 - 4 Dr. Sedan
23 - 2 Dr. Hardtop 43 - 4 Dr. Hardtop
27 - 2 Dr. Convertible 45 - Station Wagon 2-Seat
29 - 2 Dr. Sports Hardtop 46 - Station Wagon 3-Seat
Fifth Symbol - Engine
(B) 6-198 (N) 8-383
(C) 6-225 (N) 8-383
(E) 6-Special Order (R) 8-426 HEMI
(G) 8-318 (T) 8-440
(H) 8-340 (U) 8-440
(J) 8-340 (V) 8-440
(L) 8-383 (Z) 8-Special Order
Sixth Symbol - Model Year
6 - 1966 1 - 1971
7 - 1967 2 - 1972
8 - 1968 3 - 1973
9 - 1969 4 - 1974
0 - 1970 5 - 1975
Seventh Symbol - Assembly Plant
(A) Lynch Road, Michigan (E) Los Angeles, California
(B) Hamtramck, Michigan (F) Newark, Deleware
(C) Jefferson, Michigan (G) St. Louis, Missouri
(D) Belvedere, Illinois (R) Windsor, Ontario, Canada
Last Six Symbols - Production Sequence
Started at 100001



Available Transmissions

Transmission Location
TorqueFlite Stamped on the transmission oil pan rail.
3-Speed Manual Not Available
4-Speed Manual Not Available

Identification Number Transmission Type
2892076 TorqueFlite
2892077 TorqueFlite
2892079 TorqueFlite
2892080 TorqueFlite
2892086 TorqueFlite
2892087 TorqueFlite
2892089 TorqueFlite
2892090 TorqueFlite
2892091 TorqueFlite
2892092 TorqueFlite
2892093 TorqueFlite
2892094 TorqueFlite

Interior and Exterior Paint Chips

  • 1969 Dodge Exterior Paint Codes.

    The first Paint Code identifies the roof or accent color. The second Paint Code identifies the body color. (For example, the combination W1-B3 on a Dodge would indicate the roof or accent area is in White and the body is finished in Light Blue Metallic.) Paint code plates are located in the engine compartment on the left wheel housing or the left fender side shield.

Color Name / Code Color Image Color Name / Code Color Image

A4 - Silver Metallic
Lucite® Code - 4979L
Dulux® Code - 4979D

Q5 - Bright Turquoise Metallic
Lucite® Code - 4960L
Dulux® Code - 4960D
B3 - Light Blue Metallic
Lucite® Code - 4981L
Dulux® Code - 4981D

R4 - Bright Red
Lucite® Code - 4959LH
Dulux® Code - 4959DH

B5 - Bright Blue Metallic
Lucite® Code - 4982L
Dulux® Code - 4982D

R6 - Red
Lucite® Code - 4992LM
Dulux® Code - 4992DH

B7 - Medium Blue Metallic
Lucite® Code - 4983L
Dulux® Code - 4983D

T3 - Light Bronze Metallic
Lucite® Code - 4993L
Dulux® Code - 4993D

B9 - Dark Blue Metallic
Lucite® Code - 4983L
Dulux® Code - 4983D

T5 - Copper Metallic
Lucite® Code - 4994LH
Dulux® Code - 4994DH

E7 - Cordovan Metallic
Lucite® Code - 4985LM
Dulux® Code - 4985DM

T7 - Dark Bronze Metallic
Lucite® Code - 4995LH
Dulux® Code - 4995DH

F3 - Light Green Metallic
Lucite® Code - 4986L
Dulux® Code - 4986D

V2 - Hemi Orange
Lucite® Code - 5067LH
Dulux® Code - 5067DH

F5 - Medium Green Metallic
Lucite® Code - 4987L
Dulux® Code - 4987D

W1 - White
Lucite® Code - 4996L
Dulux® Code - 4996D
F6 - Bright Green Metallic
Lucite® Code - 5078LH
Dulux® Code - 5078DH

Lighter & Brighter than F8

X9 - Black
Lucite® Code - 88L
Dulux® Code - 93-005
F8 - Dark Green Metallic
Lucite® Code - 4988L
Dulux® Code - 4988D
Y2 - Yellow
Lucite® Code - 4887L
Dulux® Code - 4887D
L1 - Beige
Lucite® Code - 4998L
Dulux® Code - 4998D
Y3 - Cream
Lucite® Code - 4888L
Dulux® Code - 4888D
Q4 - Light Turquoise Metallic
Lucite® Code - 4991L
Dulux® Code - 4991D
Y6 - Gold Metallic
Lucite® Code - 4997L
Dulux® Code - 4997D
Image Not Available

  • 1969 Dodge Interior Paint Codes

    1. Low Gloss Colors require 2 ounces of DuPont 4528S Flattening Compound to a pint of unreduced color.
    2. Gloss Colors Usage - Windshield Mouldings, Backlite Mouldings, Roof Rails, Quarter Panel Upper Garnish Moulding, Quarter Garnish Extension & Lock Pillar Upper, "A & B" Pillars and "B" Pillar Cap, Door & Quarter Upper Inner Frame and Upper & Lower Garnish, and Miscellaneous Suburban Parts.
    3. Low Gloss Colors Usage - Roof Rails, Backlite Mouldings, "C" Pillar Cover, Console, Manual Seat Adjuster, Windshield Garnish Mouldings, Convertible Top Mechanism, Miscellaneous Suburban Parts.
Color Name / Code Color Image Color Name / Code Color Image
GLOSS COLORS (note 2)
Dove White
See Code W1 Bayou Green Metallic (Medium)
See Code F8
Giallo Gold Metallic See Code Y4 Sierra Blue Metallic (Light) See Code B3
Saturn Beige See Code L1 Baltic Blue Metallic (Medium) See Code B7
Gold Tan Metallic (Light) See Code T3 Rally Red See Code R6
Tweak Tan Metallic (Dark) See Code T7 Jewel Black
See Code X9
Everglade Green Metallic (Light)
See Code F3
LOW GLOSS COLORS (note 3)
Dove White
Lucite® Code - 9608L
Not Available / See Note 1 Saber Silver Metallic
Lucite® Code - 9641L
Not Available / See Note 1
Ivory
Lucite® Code - 9070L
Not Available / See Note 1 Everglade Green Metallic (Light)
Lucite® Code - 9646L
Not Available / See Note 1
Amarillo Gold (Yellow)
Lucite® Code - 9609L
Not Available / See Note 1 Bayou Green Metallic (Medium)
Lucite® Code - 9601L
Not Available / See Note 1
Saturn Beige
Lucite® Code - 9602L
Not Available / See Note 1 Sierra Blue Metallic (Light)
Lucite® Code - 9642L
Not Available / See Note 1
Desert Tan (Light)
Lucite® Code - 9605L
Not Available / See Note 1 Baltic Blue Metallic (Medium)
Lucite® Code - 9643LH
Not Available / See Note 1
Oasis Tan (Medium)
Lucite® Code - 9606L
Not Available / See Note 1 Rally Red
Lucite® Code - 9604LH
Not Available / See Note 1
Buckskin Tan (Dark)
Lucite® Code - 9607LH
Not Available / See Note 1 Jewel Black
Lucite® Code - 88L
Not Available / See Note 1
