The 1967 Stingray was regarded as one of the best selling Corvettes of all time. |
|
1967 Chevrolet Corvette
Still regarded by many as one of the best selling Corvettes of all time, the 1967 Corvette Stingray was restyled with five smaller front fender vents, new rocker panel trim, slotted Rally wheels, and slight interior changes, including a parking brake moved to the center console. The 427s got a different "power bulge" hood with a forward facing air scoop and more top horsepower.
The standard engine was a 327 V8 rated at 300 hp, and performance seekers, the 427 available was offered in 4 combinations. The first version, the L36, cost just $200 more and featured a single four barrel carb, 10.25:1 compression and hydraulic lifters with 390 hp. Next up was the L68 for $305 which featured triple two-barrel Holley carburetors (a first for Corvette) and produced 400 hp., followed by the L71 with triple two-barrel Holley carburetors, solid lifters, special performance cams, and 11:1 compression, conservatively rated at 435 hp.
Extremely rare with only 20 built was the top of the line L88 for $948 more and featured new aluminum heads, 12.5:1 compression, and a single Holley four barrel carb rated at 850 cfm that sat on an aluminum intake manifold with a special raised plenum chamber.
Chevrolet was reluctant about revealing the L88 engine options true potential and officially rated it at just 430 hp, while most experts believed that it in fact had up to almost 600 horsepower! In all, 9,707 big-blocks were built. Transmission options included the L36 and L68, with buyers able to choose between the wide-ratio or close-ratio four-speed manuals, or Powerglide automatic transmission. The L71 came only with the close-ratio four-speed. Rear end gear ratios ranged from 3.08 to 4.11.
1967 Chevrolet Corvette Production Numbers
Model Number |
Body/Style Number |
Body Type & Seating |
Factory Price |
Shipping Weight |
Total Production |
Corvette |
94 |
37 |
2 Dr Fastback Coupe |
$4,353 |
3,000 lbs |
8,504 |
94 |
67 |
2 Dr Convertible |
$4,141 |
3,020 lbs |
14,436 |
Notes: A total of 216 Corvettes with the L88 (427-cid/560-hp) option were sold in 1967-1969 models. Of these, 20 were 1967 models.
Chassis Data
Model |
Wheelbase |
Overall Lenght |
Width |
Front Tread |
Rear Tread |
Tires |
Corvette |
98 in |
175.2 in |
69.6 in |
57.6 in |
58.3 in |
7.75 x 15 |
VIN Numbers |
Serial Numbers were stamped on a plate
on the left front door hinge pillar (center pillar on Corvair). The Fisher
Body number plate on the right-hand side of the cowl gives additional
information such as the body style number, the production sequence number,
the trim (upholstery) number code and the paint number code. |
|
First Symbol - Manufacturer |
1 = Chevrolet |
|
Second & Third Symbol - Series |
01 = Corvair 500 six-cylinder |
33 = Chevelle 300 Deluxe/Std. El Camino six-cylinder |
05 = Corvair Monza six-cylinder |
34 = Chevelle 300 Deluxe/Std. El Camino V-8 |
07 = Corvair Corsa six-cylinder |
35 = Chevelle Malibu/Custom El Camino six-cylinder |
11 = Chevy II 100 four-cylinder |
36 = Chevelle Malibu/Custom El Camino V-8 |
R12 = Corvir Forward Control six-cylinder |
37 = Chevelle Concours six-cylinder |
13 = Chevy II 100 six-cylinder |
38 = Chevelle Concours/Super Sport V-8 |
14 = Chevy II 100 V-8 |
53 = Biscayne six-cylinder |
15 = Chevy II Nova exc. Super Sport six-cylinder |
54 = Biscayne V-8 |
16 = Chevy II Nova exc. Super Sport V-8 |
55 = Bel Air six cylinder |
17 = Chevy II Nova Super Sport |
56 = Bel Air V-8 |
18 = Chevy II Nova Super Sport |
63 = Impala six-cylinder |
23 = Camaro six-cylinder |
64 = Impala V-8 |
24 = Camaro V-8 |
66 = Caprice |
25 = Deluxe Camaro six-cylinder |
67 = Impala Super Sport six-cylinder |
26 = Deluxe Camaro V-8 |
68 = Impala Super Sport V-8 |
31 = Chevelle 300 six-cylinder |
94 = Corvette |
32 = Chevelle 300 V-8 |
|
|
Fourth & Fifth Symbol
- Body Style |
11 = two-door sedan |
39 = four-door hardtop or sport sedan |
15 = two-door station wagon 6p |
45 = four-door station wagon 9p |
17 = two-door hardtop |
47 = two-door hardtop |
27 = two-door sedan |
67 = convertible |
35 = four-door station wagon 6p |
69 = four-door sedan |
37 = two-door hardtop or sport coupe |
87 = two-door hardtop |
|
Sixth Symbol - Last Digit Of The Model Year |
7 = 1967 |
|
Seventh Symbol - Assembly Plant |
(A) Atlanta, Georgia |
(P) Pontiac, Michigan |
(B) Baltimore, Maryland |
(R) Arlington, Texas |
(C) Southgate, California |
(S) St. Louis, Missouri |
(D) Doraville, Wisconsin |
(T) Tarrytown, New York |
(F) Flint, Michigan |
(U) Lordstown, Ohio |
(G) Framingham, Massachusetts |
(W) Willow Run, Michigan |
(J) Janesville, Wisconsin |
(Y) Wilmington, Delaware |
(K) Kansas City, Missouri |
(Z) Fremont, California |
(L) Los Angeles, California |
(1) Oshawa, Ontario, Canada |
(N) Norwood, Ohio |
(2) St. Therese, Quebec, Canada |
|
Last Six Symbols - Production Sequence |
Started at 100001 |
|
|
1967 Chevrolet Corvette Options
Code |
Description |
Price |
898 |
Genuine Leather Seats |
$79.00 |
A01 |
Soft-Ray Tinted Windows (all glass) |
$15.80 |
A02 |
Soft-Ray Tinted Windshield |
$10.55 |
A31 |
Power Windows |
$57.95 |
A82 |
Headrests |
$42.15 |
A85 |
Shoulder Belts |
$26.35 |
C07 |
Auxiliary Hardtop |
$231.75 |
C08 |
Vinyl Covering |
$52.70 |
C48 |
Heater & Defroster Deletion (credit) |
$97.85 |
C60 |
Air Conditioning |
$412.90 |
F41 |
Special Front & Rear Suspension |
$36.90 |
G80 |
Positraction Rear Axle |
$42.15 |
J50 |
Power Brakes |
$42.15 |
J56 |
Special Heavy-Duty Brakes |
$342.30 |
K19 |
Air Injection Reactor |
$45.00 |
K66 |
Transistor Ignition System |
$73.75 |
L36 |
427-cid/390-hp V8 |
$200.15 |
L68 |
427-cid/400-hp V8 |
$305.50 |
L71 |
427-cid/435-hp V8 |
$437.10 |
L79 |
327-cid/350-hp V8 |
$105.35 |
L88 |
427-cid/430-hp V8 (560-hp actual) |
$947.90 |
L89 |
Aluminum Cylinder Heads for Engine Option L71 |
$368.65 |
M20 |
4-Speed Manual Transmission |
$184.30 |
M21 |
4-Speed Close-Ratio Manual Transmission |
$184.30 |
M22 |
Heavy-Duty 4-Speed Close-Ratio Manual Transmission |
$236.95 |
M35 |
Powerglide Automatic Transmission |
$194.85 |
N03 |
36-Gallon Fuel Tank |
$198.05 |
N11 |
Off Road Exhaust System |
$36.90 |
N14 |
Side Mount Exhaust System |
$131.65 |
N36 |
Telescopic Steering Column |
$42.15 |
N40 |
Power Steering |
$94.80 |
N89 |
Cast Aluminum Bolt-On Wheels |
$263.30 |
P92 |
7.75 x 15 White Sidewall Tires |
$31.35 |
QB1 |
7.75 x 15 Redline Tires |
$46.55 |
U15 |
Speed Warning Indicator |
$10.55 |
U69 |
AM-FM Radio |
$199.10 |
1967 Chevrolet Corvette Engine Options
Location Of Engine Code: Stamped on the block in front of the right hand cylinder head.
Letter Code |
Engine |
Horsepower |
Torque |
Transmission |
Carburetor |
HD |
8-327 # |
350 |
360 |
4-Speed Manual |
4 BC |
HE |
8-327 |
300 |
360 |
3 & 4-Speed Manual |
4 BC |
HH |
8-327 |
300 |
360 |
3 & 4-Speed Manual |
4 BC |
HO |
8-327 |
300 |
360 |
Powerglide |
4 BC |
HP |
8-327 # |
350 |
360 |
4-Speed Manual |
4 BC |
HR |
8-327 |
300 |
360 |
Powerglide |
4 BC |
HT |
8-327 # |
350 |
360 |
4-Speed Manual |
4 BC |
IL |
8-427 |
390 |
460 |
4-Speed Manual |
4 BC |
IM |
8-427 |
390 |
460 |
3 & 4-Speed Manual |
4 BC |
IQ |
8-427 |
390 |
460 |
Powerglide |
4 BC |
IR |
8-427 |
390 |
460 |
Powerglide |
4 BC |
IT |
8-427 # |
435 |
460 |
4-Speed Manual |
3 - 2 BC |
IU |
8-427 # |
435 |
460 |
4-Speed Manual |
3 - 2 BC |
JA |
8-427 # |
435 |
460 |
4-Speed Manual |
3 - 2 BC |
JC |
8-427 |
400 |
460 |
4-Speed Manual |
3 - 2 BC |
JD |
8-427 |
400 |
460 |
Powerglide |
3 - 2 BC |
JE |
8-427 # |
435 |
460 |
4-Speed Manual |
3 - 2 BC |
JF |
8-427 |
400 |
460 |
4-Speed Manual |
3 - 2 BC |
JG |
8-427 |
400 |
460 |
Powerglide |
3 - 2 BC |
JH |
8-427 # |
435 |
460 |
4-Speed Manual |
3 - 2 BC |
KH |
8-327 # |
350 |
360 |
4-Speed Manual |
4 BC |
# Special High Performance
Transmission Codes
Transmission |
Location |
Powerglide |
All models stamped on the right side of transmission oil pan. |
Turbo Hydra-Matic |
Right hand vertical surface of transmission case |
3-Speed |
Corvair and fully synchronized Passenger (exc. Warner Gear) transmissions stamped on square boss on left side below and rear of cover |
4-Speed |
Passenger models (exc. Corvair) stamped on right side of case ahead of the extension. |
Plant and Type Designation Prefix |
Plant |
Transmission Type |
N |
Muncie |
4-Speed |
W |
Warner Gear |
3 and 4-Speed |
P |
Muncie |
4-Speed |
R |
Saginaw |
4-Speed |
S |
Saginaw |
3-Speed |
M |
Muncie |
3-Speed, Overdrive* |
C |
Cleveland |
Powerglide |
T |
Toledo |
Powerglide |
CA |
Hydra-Matic |
3-Speed, Automatic Turbo Hydra-Matic |
D |
Saginaw |
Overdrive |
K |
McKinnon |
3-Speed |
E |
McKinnon |
Powerglide |
O |
Saginaw |
Overdrive |
X |
Cleveland |
Turbo Hydra-Matic 350 |
B |
Cleveland |
Turbo Hydra-Matic 350 |
Y |
Toledo |
Turbo Hydra-Matic 350 |
A |
Cleveland |
2-Speed, Manual Powerglide |
*Overdrive distinguished from 3-Speed by physical appearance only. The above transmissions (exc. Warner Gear) will carry a production code number such as: C1116N (C = Cleveland Powerglide, 11 = November, 16 = 16th, N = Night Shift). The Warner Gear transmissions will carry a production code number such as: WG1031 (W = Warner Gear 4-Spd., G = July, 10 = 10th, 7 = 1967, 1 = First Shift).
1967 Chevrolet Corvette Exterior Paint Codes
1967 Chevrolet Corvette Interior Paint Codes
Color Name / Code |
Color Image |
Color Name / Code |
Color Image |
White
Lucite® Code - 9184L (flat) |
 |
Dark Bright Blue Metallic
Lucite® Code - 9272LH (semi-gloss) |
 |
Medium Saddle
Lucite® Code - 9370L (semi-gloss) |
 |
Dark Bright Blue Metallic
Lucite® Code - 9282LH (flat) |
 |
Medium Saddle
Lucite® Code - 9381L (flat) |
 |
Dark Teal Blue Metallic
Lucite® Code - 9369LH (semi-gloss) |
 |
Dark Green Metallic
Lucite® Code - 9371LH (semi-gloss) |
 |
Dark Teal Blue Metallic
Lucite® Code - 9308LH (flat) |
 |
Dark Green Metallic
Lucite® Code - 9382LH (flat) |
 |
Red
Lucite® Code - 4688LH (semi-gloss) |
 |
Bright Blue Metallic
Lucite® Code - 9223LH (flat) |
 |
Red
Lucite® Code - 9188LM (flat) |
 |
Medium Bright Blue Metallic
Lucite® Code - 9271LH (semi-gloss) |
 |
Black
Lucite® Code - 4466L (flat) |
 |
NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use 1/2 oz. DuPont #4528 flattening compound to a pint of unreduced color. |
Trunk Colors (spatter finish) |
Black - Gray - Aqua 389 - 259 |
Axle Codes
Location Of Axle Codes: The axles for Chevrolet will be built by Chevrolet Buffalo, Chevrolet Gear and Axle, Buick, Oldsmobile, and McKinnon. Divisional Manufacturer code letters will be metal stamped on the axle tube adjacent to the carrier for identification. Metal stamp on left rear axle tube on the rear side, letters and numerals 3/16 in. high, 3 in. outboard of carrier.

Codes - Non-Locking |
Codes - Locking |
Ratio |
Inspection Cover |
|
AL, AT |
3.08 |
10 Bolt |
AK |
AM, AU |
3.36 |
10 Bolt |
|
AN, AZ |
3.55 |
12 Bolt |
AS |
AO, FA |
3.70 |
12 Bolt |
|
AP, FB |
4.11 |
12 Bolt |
|
FC |
4.56 |
12 Bolt |
