The 1970 Dodge Charger |
1970 Dodge Charger
The 1970 Charger continued to use the same body as the in the previous year but received a few minor trim changes. You could still get the high performance Charger R/T. The R/T featured a 440-cid Magnum V-8 and there was a Special Edition (SE) package was available to Charger 500s and Charger R/Ts. Plus, a choice of Bumble Bee stripes were still available as in 1969. The 1970 Charger had concealed headlights and had either a 225-cid slant six or a 318-cid V-8 as base equipment.
The 1970 Dodge Charger featured new loop bumper, new front fenders and a new-lower priced version with bench seats and a more modes trim package.
Besides a new variety of colors including Top Banana, Panther Pink, Go Mango or Plum Crazy, a new HEMI hood cutout was an option for the 70’ Charger in which 440 or HEMI lettering was spelled out in block letter with silver reflective tape on either side and hood scallop inserts were painted black.
1970 Dodge Charger Factory Specifications & Production
| Model Number | Body/Style Number | Body Type & Seating | Factory Price | Shipping Weight | Total Production |
| Charger - Six-Cyl | |||||
| XH | 29 | 2 Dr Hardtop | $3,001 | 3,228 lbs | Note 1 |
| Charger - V-8 | |||||
| XH | 29 | 2 Dr Hardtop | $3,108 | 3,363 lbs | Note 1 |
| Charger 500 - Six-Cyl | |||||
| XP | 29 | 2 Dr Hardtop | $3,139 | 3,228 lbs | Note 1 |
| Charger 500 - V-8 | |||||
| XP | 29 | 2 Dr Hardtop | $3,246 | 3,362 lbs | Note 1 |
| Charger R/T | |||||
| XS | 23 | 2 Dr Hardtop | $3,711 | 3,638 lbs | 10,337 |
Notes:
- The combined production of Models XH29 and XP29 was 39,431.
- Additional Charger R/T Information: The "HEMI" engine was installed into 112 hardtops. The "440 Six-Pak" was installed into 116 hardtops.
Chassis Specifications
From 1966 to 1974, the Charger was based on the Chrysler B platform.
| Model | Wheelbase | Overall Length | Width | Front Tread | Rear Tread | Tires |
| Charger 6-Cyl/V-8 | 117 in | 208.5 in | 76.6 in | 59.7 in | 59.2 in | F78 x 14 / G78 x 14 |
| Charger R/T | 117 in | 208.5 in | 76.6 in | 59.7 in | 59.2 in | F70 x 14 |
VIN Decoding
Serial Numbers were on the instrument panel, visible thru the windshield, and on the bottom line of a separate plate(fender tag) under the hood. |
||||||||||||||||||||||||
 |
||||||||||||||||||||||||
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
Options & Accessories
For 1970, you could order a special interior and exterior trim package called the Special Edition (SE) for both the Charger 500 and R/T. Among other things, it included deep dish wheel covers, hood-mounted turn signal indicators, leather bucket seats and a steering wheel and instrument panel woodgrain trim.
| Description | Description |
| Airtemp Air Conditioner | Front Center Console |
| Automatic Speed Control | Front Bumper Guards |
| Front Center Cushion | Hood Performance Paint Treatment |
| Headlight Time Delay | Hood Tie-Down Pins |
| Locking Gas Cap | Simulated Walnut Sports Type Steering Wheel |
| Luggage Rack | Sill Mouldings |
| Remote Control Left Outside Mirror | Chromed Rallye Wheels |
| Right Outside Mirror | Chromed Road Wheels |
| Power Brakes | Deep Dish Wheel Covers |
| Power Steering | Vinyl Roof |
| Power Windows | Wheel Lip Moulding |
| Rear Seat Speaker | White Sidewall Tires |
| Astrophonic AM Deluxe Radio | Raise White Letter Tires |
| Solid-State AM/FM Radio | 838-cid w/ 2 BC |
| Music Master AM Radio | 383-cid w/ 4 BC |
| AM Radio w/ 8-Track Stereo Tape Player | 440-cid "Six Pack" |
| Rear Shoulder Belts | 426-cid "HEMI" |
| Rear Window Defogger | TorqueFlite Transmission |
| 6-Way Manual Driver's Seat | 4-Speed Manual Transmission |
| 3-Speed Electric Windshield Wipers | 3-Speed Manual Transmission |
| Tinted Windshield | Sure Grip Differential |
| Tinted Windshield & Windows | Tachometer & Electric Clock |
| Undercoating & Hood Insulation | Front Disc Brakes |
| Bright Tip Exhausts | Heavy-Duty Drum Brakes |
| Color-Keyed Floor Mats | Firm Ride Shock Absorbers |
| Door Edge Protectors | Trailer-Towing Package |
| Electric Sun Roof | Performance Axle Package |
| Radio Group | XHD Rallye Suspension |
| Light Group | Seat Belt Group |
Engine Options
Location Of Engine Code: 6-Cyl - Right front of block, below cylinder
head. Small-Block V-8 - Left front of block, below cylinder head. Big-Block
V-8 - Left rear of block, near oil pan flange.
| Letter Code | Engine | Horsepower | Torque | Transmission | Carburetor |
| B | 6-198 | 125 | 180 | TorqueFlite, 3-Speed Manual | 1 BC |
| C | 6-225 | 145 | 215 | TorqueFlite, 3-Speed Manual | 1 BC | E | 6-Special Order | Not Available | Not Available | TorqueFlite, 3-Speed Manual | Not Available | G | 8-318 | 230 | 320 | TorqueFlite, 3 & 4-Speed Manual | 2 BC |
| H | 8-340 | 275 | 340 | TorqueFlite, 3 & 4-Speed Manual | 4 BC | J | 8-340 | 290 | 345 | TorqueFlite, 3 & 4-Speed Manual | 3 - 2 BC |
| L | 8-383 | 290 | 390 | TorqueFlite | 2 BC |
| N | 8-383 | 330 | 425 | TorqueFlite, 3 & 4-Speed Manual | 4 BC |
| N | 8-383 * | 335 | 425 | TorqueFlite, 3 & 4-Speed Manual | 4 BC |
| R | 8-426 HEMI | 425 | 490 | TorqueFlite, 3 & 4-Speed Manual | 4 BC |
| T | 8-440 | 350 | 480 | TorqueFlite, 3 & 4-Speed Manual | 4 BC |
| U | 8-440 * | 375 | 480 | TorqueFlite, 3 & 4-Speed Manual | 4 BC |
| V | 8-440 | 390 | 480 | TorqueFlite, 3 & 4-Speed Manual | 3 - 2 BC |
| Z | 8-Special Order | Not Available | Not Available | TorqueFlite, 3 & 4-Speed Manual | Not Available |
Available Transmissions
| Transmission | Location |
| TorqueFlite | Stamped on the transmission oil pan rail. |
| 3-Speed Manual | Not Available |
| 4-Speed Manual | Not Available |
| Identification Number | Transmission Type |
| 2892086 | TorqueFlite |
| 2892087 | TorqueFlite |
| 2892089 | TorqueFlite |
| 3410636 | TorqueFlite |
| 3410637 | TorqueFlite |
| 3410667 | TorqueFlite |
| 3410668 | TorqueFlite |
| 3410669 | TorqueFlite |
| 3410670 | TorqueFlite |
| 3410671 | TorqueFlite |
| 3410672 | TorqueFlite |
| 3410767 | TorqueFlite |
| 3410769 | TorqueFlite |
| 3410777 | TorqueFlite |
| 3410779 | TorqueFlite |
| 3515815 | TorqueFlite |
| 3515816 | TorqueFlite |
| 3515817 | TorqueFlite |
Axle Decoding
Location Of Axle Codes: A metal tag is bolted to the assembly, giving the axle ratio or tooth count (if tooth count - divide the larger number by the smaller number, this is the ratio.) Locking axles have a metal tag with the letter "S" on it.
Note: Since tags can easily be missing, the approximate ratio can be determined by marking both the a wheel and the driveshaft; turn the wheel one complete turn and the number of times the driveshaft rotates is the ratio. Locking axles can be identified by raising the complete axle assembly and turning one wheel; if the other wheel turns the the same direction it is a locking axle and if it turns the opposite direction it is a non-locking axle.
| Charger Axle Ratios | |||||||||||
| Engine | 6-225 | 8-318 | 8-383 | 8-426 | 8-440 | ||||||
| Locking / Non-Locking | L | NL | L | NL | L | NL | L | NL | L | NL | |
| Ratio | 2.45 | x | |||||||||
| 2.71 | x | ||||||||||
| 2.76 | x | x | x | ||||||||
| 2.93 | x | ||||||||||
| 2.94 | x | x | x | x | x | x | |||||
| 3.21 | x | ||||||||||
| 3.23 | x | x | x | x | x | x | x | x | x | x | |
| 3.54 | x | x | |||||||||
| 3.55 | x | x | x | x | x | x | |||||
| 3.91 | x | ||||||||||
| 4.10 | x | x | x | ||||||||
Interior and Exterior Paint Chips
-
1970 Dodge Exterior Paint Codes.
The first Paint Code identifies the roof or accent color. The second Paint Code identifies the body color. (For example, the combination W1-B3 on a Dodge would indicate the roof or accent area is in White and the body is finished in Light Blue Metallic.) Paint code plates are located in the engine compartment on the left wheel housing or the left fender side shield.
| Color Name / Code | Color Image | Color Name / Code | Color Image |
A4 - Silver Metallic |
|
Q3 - Light Turquoise Metallic |
 |
A9 - Dark Gray Metallic |
 |
R6 - Red |
 |
| B3 - Light Blue Metallic Lucite® Code - 4981L "Centari" Code - 4981A Dulux® Code - 4981D |
 |
R8 - Burgundy Metallic |
 |
B5 - Bright Blue Metallic |
 |
T3 - Tan Metallic |
 |
B7 - Dark Blue Metallic |
 |
T6 - Dark Tan Metallic |
 |
C7 - Plum Metallic |
 |
V2 - Hemi Orange |
 |
E5 - Bright Red |
 |
W1 - White Lucite® Code - 4996L "Centari" Code - 4996A Dulux® Code - 4996D |
 |
F4 - Light Green Metallic |
 |
X9 - Black Lucite® Code - 99L "Centari" Code - 99A Dulux® Code - 93-005 |
 |
| F8 - Dark Green Metallic Lucite® Code - 4988L "Centari" Code - 4988A Dulux® Code - 4988D |
 |
Y1 - Bright Yellow Lucite® Code - 5180L "Centari" Code - 5180A Dulux® Code - 5180D |
 |
| J5 - Lime Metallic Lucite® Code - 5181L "Centari" Code - 5181A Dulux® Code - 5181D |
 |
Y3 - Antique Ivory Lucite® Code - 4888L "Centari" Code - 4888A Dulux® Code - 4888D |
 |
| K2 - Go Mango Lucite® Code - 5065LH "Centari" Code - 5065A Dulux® Code - 5065DH |
 |
Y4 - Light Gold Metallic Lucite® Code - 5086L "Centari" Code - 5086A Dulux® Code - 5086D |
 |
| K5 - Dark Burnt Orange Metallic Lucite® Code - 5088LM "Centari" Code - 5088AM Dulux® Code - 5088DH |
 |
Y6 - Gold Metallic Lucite® Code - 5077LH "Centari" Code - 5077A Dulux® Code - 5077D |
 |
| L1 - Beige Lucite® Code - 4998L "Centari" Code - 4998A Dulux® Code - 4998D |
 |
F6 - Bright Green Metallic Lucite® Code - 5078LH "Centari" Code - Not Available Dulux® Code - 5078DH |
 |
- 1970 Dodge Interior Paint Codes
| Color Name / Code | Color Image | Color Name / Code | Color Image |
| GLOSS COLORS (note 2) | |||
| Autumn Tan Metallic |
See Code T6 | Baltic Blue Metallic |
See Code B7 |
| Bayou Green Metallic |
See Code F8 | Jewel Black |
See Code X9 |
| LOW GLOSS COLORS (note 3) | |||
| Dove White Lucite® Code - 9608L |
Not Available / See Note 1 | Sunfire Orange Metallic Lucite® Code - 9725LH |
Not Available / See Note 1 |
| Ivory Lucite® Code - 9070L |
Not Available / See Note 1 | Bayou Green Metallic Lucite® Code - 9601L |
Not Available / See Note 1 |
| Citron Gold Metallic Lucite® Code - 9772L |
Not Available / See Note 1 | Sierra Blue Metallic Lucite® Code - 9642L |
Not Available / See Note 1 |
| Puma Tan Metallic Lucite® Code - 9723LH |
Not Available / See Note 1 | Jewel Black Lucite® Code - 99L |
Not Available / See Note 1 |
| SUEDE COLORS (note 4) | |||
| Citron Gold Metallic Lucite® Code - 9770LH |
 |
Bayou Green Metallic Lucite® Code - 9778LH |
 |
| Puma Tan Metallic Lucite® Code - 9772L |
 |
Baltic Blue Metallic Lucite® Code - 9777LH |
 |
| Sunfire Orange Metallic Lucite® Code - 9773L |
 |
Jewel Black Lucite® Code - 9776L |
 |
| Trunk Colors (spatter finish) |
Three-Tone Black & Gray = 389-2076 |
Interior Paint Notes:
1. Low Gloss Colors require 2 ounces of DuPont 4528S Flattening
Compound to a pint of unreduced color.
2. Gloss Colors Usage - Windshield Mouldings, Backlite Mouldings,
Roof Rails, Quarter Panel Upper Garnish Moulding, Quarter Garnish
Extension & Lock Pillar Upper, "A & B" Pillars
and "B" Pillar Cap, Door & Quarter Upper Inner Frame
and Upper & Lower Garnish, and Miscellaneous Suburban Parts.
3. Low Gloss Colors Usage - Roof Rails, Backlite Mouldings, "C"
Pillar Cover, Console, Manual Seat Adjuster, Windshield Garnish
Mouldings, Convertible Top Mechanism, Miscellaneous Suburban Parts.
4. Suede Colors Usage - Bucket Seat Hinge Cover, DeFogger Bezels, Instrument Panel, Steering Column and Components, Stereo Speaker Grilles, Tachometer Housing
