1967 Pontiac Catalina

The Catalina received a heavy facelift featuring integral bumper-grilles, "wasp waist" body styling, angular wedge-shaped front fender tips, and recessed windshield wipers. A crisp horizontal beltline crease and flare sculpturing between the doors and rear wheel openings were other new design traits. The Catalina carried all of the standard GM safety features plus wood grain on the dash board and nylon blend carpeting. Small hubcaps were still used and there was "Pontiac" letters on the left-hand grille. The word "Catalina" was on the sides of the front fenders behind the wheel openings. The taillights were horizontal with a single long lens that curved downwards at each side. Catalinas that were equipped with the Ventura trim package or 2+2 option had different trim.

1967 Pontiac Catalina Production

Model Number	Body/Style Number	Body Type & Seating	Factory Price	Shipping Weight	Total Production
Catalina Series 252
252	69	4d Sedan - 6P	$2,866	3,825 lbs	80,551
252	39	4d Hardtop - 6P	$3,020	3,960 lbs	37,256
252	11	2d Sedan - 6P	$2,807	3,735 lbs	5,633
252	87	2d Hardtop - 6P	$2,951	3,860 lbs	77,932
252	67	2d Convertible - 5P	$3,276	3,910 lbs	10,033
252	45	4d Station Wagon - 9P	$3,374	4,340 lbs	11,040
252	35	4d Station Wagon - 6P	$3,252	4,275 lbs	18,305

NOTES:

211,405 Catalinas were built
3,653 had Synchromesh and 207,752 had Hydra-Matic
1,768 Catalinas had the 2+2 option

Model Series Identification

25269 - 4d Sedan - 6P	25267 - 2d Convertible - 5P
25239 - 4d Hardtop - 6P	25245 - 4d Station Wagon - 9P
25211 - 2d Sedan - 6P	25235 - 4d Station Wagon - 6P
25287 - 2d Hardtop - 6P

Chassis Data

Model	Wheelbase	Overall Length	Front Tread	Rear Tread	Tires
Catalina	121 in	215.6 in	63 in	64 in	8.25 x 14
Catalina Station Wagon	121 in	218.4 in	63 in	64 in	8.55 x 14

VIN Decoding

First Symbol - Manufacturer

2 = Pontiac

Second & Third Symbol - Series
23 = Firebird	39 = Safari
24 = Firebird Espirit	42 = GTO
26 = Firebird Formula 400	52 = Catalina & Ventura
28 = Trans Am	56 = Executive
33 = Standard Tempest	62 = Bonneville
35 = Custom "S"	76 = Grand Prix
37 = LeMans

Fourth & Fifth Symbol - Body Style
27 = two-door sedan	57 = two-door hardtop
35 = station wagon two seat single action tailgate	67 = convertible
36 = station wagon two seat dual action tailgate	69 = four-door sedan
37 = two-door hardtop	87 = two-door hardtop
39 = four-door hardtop

Sixth Symbol - Last Digit Of The Model Year

7 = 1967

Seventh Symbol - Assembly Plant
(A) Atlanta, Georgia	(P) Pontiac, Michigan
(B) Baltimore, Maryland	(R) Arlington, Texas
(C) Southgate, California	(X) Kansas City, Kansas
(E) Linden, New Jersey	(Z) Fremont, California
(G) Framingham, Massachusetts	(1) Oshawa, Ontario, Canada
(L) Van Nuys, California	(2) St. Therese, Quebec, Canada
(N) Norwood, Ohio

Last Six Symbols - Production Sequence

Started at 100001

1967 Pontiac Catalina Options

Description	Description
Custom Air Conditioner	Ventura Custom Option w/ Bench Seat
Air Injector Exhaust Control	Ventura Custom Convertible Option w/ Bucket Seats
Console	Ventura Custom Hardtop Option w/ Bucket Seats
Cruise Control	Aluminum Hubs & Drums
Front Disc Brakes	Rally II Wheels
Rear Window Defogger	2+2 Option
Headrests	389-cid/256-hp V-8 (economy)
Capacitor Ignition	428-cid w/ 4-Barrel V-8
Cornering Lights	428-cid V-8 H.O.
Low-Fuel Warning Light	Super-Lift Shock Absorbers
Custom Gauge Panel Cluster	Fender Skirts
Power Antenna	Ride & Handling Package
Power Steering	Strato Bucket Seats (Bonneville Coupe & Convertible)
AM/FM Stereo	Cordova Top
Safeguard Speedometer	Turbo Hydra-Matic Transmission
Reclining Seat (passenger)	4-Speed Manual Transmission
Front Shoulder Belts

1967 Pontiac Engines

Location Of Engine Code: (Six-Cyl) - On cylinder head-to-block contact surface behind oil filter pipe. (V8) - Stamped on right front side of block or beneath production engine number on machined pad on right hand bank of engine block.

Letter Code	Engine	Horsepower	Torque	Transmission	Carburetor
WA	8-400	265	397	Manual	2 BC
WB	8-400	265	397	Manual	2 BC
WD	8-400	333	445	Manual	4 BC
WE	8-400	333	445	Manual	4 BC
WG	8-428	360	472	Manual	4 BC
WJ	8-428	376	462	Manual	4 BC
WY	8-400	333	445	Manual	4 BC
XB	8-400	260	397	Turbo Hydra-Matic	2 BC
XC	8-400	293	428	Turbo Hydra-Matic	2 BC
XH	8-400	350	440	Turbo Hydra-Matic	4 BC
XJ	8-400	350	440	Turbo Hydra-Matic	4 BC
XK	8-428	376	462	Manual	4 BC
XT	8-400	333	445	Manual	4 BC
XU	8-400	290	428	Turbo Hydra-Matic	2 BC
XV	8-400	290	428	Turbo Hydra-Matic	2 BC
XW	8-400	325	445	Turbo Hydra-Matic	4 BC
XX	8-400	325	445	Turbo Hydra-Matic	4 BC
XY	8-400	265	397	Manual	2 BC
XZ	8-400	350	440	Manual	4 BC
Y2	8-428	360	472	Turbo Hydra-Matic	4 BC
Y3	8-428	376	462	Turbo Hydra-Matic	4 BC
YA	8-400	265	397	Turbo Hydra-Matic	2 BC
YB	8-400	265	397	Turbo Hydra-Matic	2 BC
YC	8-400	290	428	Turbo Hydra-Matic	2 BC
YD	8-400	290	428	Turbo Hydra-Matic	2 BC
YE	8-400	325	445	Turbo Hydra-Matic	4 BC
YF	8-400	325	445	Turbo Hydra-Matic	4 BC
YH	8-428	360	472	Turbo Hydra-Matic	4 BC
YK	8-428	376	462	Turbo Hydra-Matic	4 BC
YY	8-428	360	472	Manual	4 BC

Transmission Codes

Transmission	Location
Turbo Hydra-Matic 350	Stamped on servo cover on right side of transmission.
Turbo Hydra-Matic 400	On metal tag fastened to right side of transmission case or on the left side of converter housing.
Powerglide	Stamped on a metal tag located on the right side of the transmission.
Super Turbine 300 (TempesTorque)	On metal tag fastened to right side of transmission case or stamped on lower servo cover.
Jetway	On metal tag fastened to right side of transmission case or stamped on lower servo cover.
3-Speed	Painted or stamped on the transmission case.
4-Speed	Painted or stamped on the transmission case.

Plant and Type Designation Prefix	Transmission Type
LA	TempesTorque
LB	TempesTorque
LD	TempesTorque
LF	TempesTorque
LG	TempesTorque
LH	TempesTorque
MA	TempesTorque
MB	TempesTorque
MC	TempesTorque
PB	Turbo Hydra-Matic 400
PC	Turbo Hydra-Matic 400
PD	Turbo Hydra-Matic 400
PG	Turbo Hydra-Matic 400
PH	Turbo Hydra-Matic 400
PQ	Turbo Hydra-Matic 400
PS	Turbo Hydra-Matic 400
PT	Turbo Hydra-Matic 400
PX	Turbo Hydra-Matic 400

Axle Codes

Location Of Axle Codes: On flange end of axle shaft and on or near carrier.

Color - Non-Locking	Color - Locking	Ratio
UA	VA	2.29
UB	VB	2.41
UC	VC	2.56
UD	VD	2.73
UE	VE	2.93
UF	VF	3.08
UG	VG	3.23
UH	VH	3.42
	VJ	3.55
	VK	3.73
	VM	4.11

Paint Codes - Exterior Colors

Color Name / Code	Color Image	Color Name / Code	Color Image
A - Starlight Black Lucite® Code - 88L Dulux® Code - 93-005		M - Plum Mist Metallic Lucite® Code - 4832L Dulux® Code - 4832DH
C - Cameo Ivory Lucite® Code - 4024L Dulux® Code - 93-93774		N - Burgundy Metallic Lucite® Code - 4624LH Dulux® Code - 181-97213M
D - Monreux Blue Metallic Lucite® Code - 4815L Dulux® Code - 4815D		O - Coronado Gold Metallic Lucite® Code - 4946L Dulux® Code - 4946D
E - Fathom Blue Metallic Lucite® Code - 4817L Dulux® Code - 4817D		P - Silverglaze Metallic Lucite® Code - 4820L Dulux® Code - 4820D
F - Tyrol Blue Metallic Lucite® Code - 4850L Dulux® Code - 4850D		Q - Verdoro Green Metallic Lucite® Code - 4947LH Dulux® Code - 4947DH
G - Signet Gold Metallic Lucite® Code - 4825L Dulux® Code - 4825D		R - Regimental Red Lucite® Code - 4822LH Dulux® Code - 4822DH
H - Linden Green Metallic Lucite® Code - 4816L Dulux® Code - 4816D		S - Champagne Metallic Lucite® Code - 4826L Dulux® Code - 4826D
K - Golf Turquoise Metallic Lucite® Code - 4818L Dulux® Code - 4818D		T - Montego Cream Lucite® Code - 4819L Dulux® Code - 4819D
L - Mariner Turquoise Metallic Lucite® Code - 4824L Dulux® Code - 4824DH
NOTES: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination EC on a Pontiac would indicate the body finished in Fathom Blue Metallic and the roof area in Cameo Ivory.) General Motors paint code plate for all models except Corvair and Corvette is located under the hood at the top of the firewall on the left or right of the upper shroud. Corvair paint code plate is on the left cross-rail in the engine compartment. Corvette paint code plate is on the instrument panel brace, below the glove compartment.

Paint Codes - Interior Colors

Color Name / Code	Color Image	Color Name / Code	Color Image
Parchment Lucite® Code - 9401L (semi-gloss)		Dark Blue Metallic Lucite® Code - 9395LH (semi-gloss) Lucite® Code - 9373LH (flat)
Medium Gold Metallic Lucite® Code - 9390L (semi-gloss)		Red Lucite® Code - 9366LM (semi-gloss)
Midnight Fawn Metallic Lucite® Code - 9376LH (flat)		Dark Red Metallic Lucite® Code - 9386LM (semi-gloss)
Dark Turquoise Metallic Lucite® Code - 9399LH (semi-gloss) Lucite® Code - 9374LH (flat)		Dark Red Lucite® Code - 9201LM (flat)
Medium Blue Metallic Lucite® Code - 9392LH (semi-gloss)		Black Lucite® Code - 88L (semi-gloss) Lucite® Code - 4428L (flat)
NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use 1/2 oz. DuPont #4528S flattening compound to a pint of unreduced color.
