1967 Chevrolet Impala
The 1967 Impala Convertible

1967 Chevrolet Impala

The Impala was redesigned and had a "coke bottle" shape that similar to the 1963 Buick Riviera. Safety features were added that included a fully collapsible energy absorbing steering wheel column, side marker lights, and shoulder belts for hardtops, sedans, and wagons. The Impala was distinguished by bright lower body-side moldings, roof drip cap and reveal moldings on hardtops, bright side window accents on station wagons and sedans, deck lid center panel accents, and black accented taillight surrounds. Impala interiors were cloth, cloth and vinyl, or just all vinyl combinations. They came with full wheel covers as well.



1967 Chevrolet Impala Specifications

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
Impala Series 63 - Six-Cyl
63 69 4 dr Sedan - 6P $2,723 3,425 lbs 18,800 Total
11,400 Station Wagons
63 39 4 dr Hardtop - 6P $2,793 3,540 lbs
63 37 2 dr Hardtop- 6P $2,740 3,475 lbs
63 67 2 dr Convertible - 6P $2,991 3,515 lbs
63 45 4 dr Station Wagon - 6P $3,129 3,860 lbs
63 35 4 dr Station Wagon - 9P $3,016 3,805 lbs
Impala Series 64 - V-8
64 69 4 dr Sedan - 6P $2,829 3,575 lbs 556,800 Total
140,700 Station Wagons
64 39 2 dr Hardtop - 6P $2,899 3,650 lbs
64 37 4 dr Hardtop- 6P $2,845 3,590 lbs
64 67 2 dr Convertible - 6P $3,097 3,625 lbs
64 45 4 dr Station Wagon - 6P $3,234 3,980 lbs
64 35 4 dr Station Wagon - 9P $3,122 3,920 lbs
Impala Super Sport Series 67 - Six-Cyl
67 37 2 dr Hardtop - 6P $2,898 3,500 lbs 400 Total
67 67 2 dr Convertible - 6P $3,149 3,535 lbs
Impala Super Sport Series 68 - V-8
68 37 2 dr Hardtop - 6P $3,003 3,615 lbs 73,600 Total
68 67 2 dr Convertible - 6P $3,253 3,650 lbs

Model Series Identification

Impala Six-Cyl - 16300 Impala SS Six-Cyl - 16700
Impala V-8 - 16400 Impala SS V-8 - 16800

Chassis Data

Model Wheelbase Overall Length Width Front Tread Rear Tread Tires
Chevrolet 119 in 213.2 in 80 in 62.5 in 62.4 in 8.25 x 14/6.70 x15 (SS)
Chevrolet Convertible 119 in 213.2 in 80 in 62.5 in 62.4 in 8.25 x 14
Chevrolet Station Wagon 119 in 212.4 in 80 in 63.5 in 63.4 in 8.55 x14

VIN Numbers

Serial Numbers were stamped on a plate on the left front door hinge pillar (center pillar on Corvair). The Fisher Body number plate on the right-hand side of the cowl gives additional information such as the body style number, the production sequence number, the trim (upholstery) number code and the paint number code.
First Symbol - Manufacturer
1 = Chevrolet
Second & Third Symbol - Series
01 = Corvair 500 six-cylinder 33 = Chevelle 300 Deluxe/Std. El Camino six-cylinder
05 = Corvair Monza six-cylinder 34 = Chevelle 300 Deluxe/Std. El Camino V-8
07 = Corvair Corsa six-cylinder 35 = Chevelle Malibu/Custom El Camino six-cylinder
11 = Chevy II 100 four-cylinder 36 = Chevelle Malibu/Custom El Camino V-8
R12 = Corvir Forward Control six-cylinder 37 = Chevelle Concours six-cylinder
13 = Chevy II 100 six-cylinder 38 = Chevelle Concours/Super Sport V-8
14 = Chevy II 100 V-8 53 = Biscayne six-cylinder
15 = Chevy II Nova exc. Super Sport six-cylinder 54 = Biscayne V-8
16 = Chevy II Nova exc. Super Sport V-8 55 = Bel Air six cylinder
17 = Chevy II Nova Super Sport 56 = Bel Air V-8
18 = Chevy II Nova Super Sport 63 = Impala six-cylinder
23 = Camaro six-cylinder 64 = Impala V-8
24 = Camaro V-8 66 = Caprice
25 = Deluxe Camaro six-cylinder 67 = Impala Super Sport six-cylinder
26 = Deluxe Camaro V-8 68 = Impala Super Sport V-8
31 = Chevelle 300 six-cylinder 94 = Corvette
32 = Chevelle 300 V-8
Fourth & Fifth Symbol - Body Style
11 = two-door sedan 39 = four-door hardtop or sport sedan
15 = two-door station wagon 6p 45 = four-door station wagon 9p
17 = two-door hardtop 47 = two-door hardtop
27 = two-door sedan 67 = convertible
35 = four-door station wagon 6p 69 = four-door sedan
37 = two-door hardtop or sport coupe 87 = two-door hardtop
Sixth Symbol - Last Digit Of The Model Year
7 = 1967
Seventh Symbol - Assembly Plant
(A) Atlanta, Georgia (P) Pontiac, Michigan
(B) Baltimore, Maryland (R) Arlington, Texas
(C) Southgate, California (S) St. Louis, Missouri
(D) Doraville, Wisconsin (T) Tarrytown, New York
(F) Flint, Michigan (U) Lordstown, Ohio
(G) Framingham, Massachusetts (W) Willow Run, Michigan
(J) Janesville, Wisconsin (Y) Wilmington, Delaware
(K) Kansas City, Missouri (Z) Fremont, California
(L) Los Angeles, California (1) Oshawa, Ontario, Canada
(N) Norwood, Ohio (2) St. Therese, Quebec, Canada
Last Six Symbols - Production Sequence
Started at 100001


1967 Chevrolet Impala Engine Options

Location Of Engine Code: 6-Cyl. Corvair-- Stamped on top of the block ahead of generator oil filter adapter. 6-Cyl-- Stamped on a pad behind the distributor on right side of block. 8-Cyl-- Stamped on the block in front of the right hand cylinder head.

Letter Code Engine Horsepower Torque Transmission Carburetor
FA 6-250 155 235 Manual 3-Speed 1 BC
FE 6-250 155 235 Manual 3-Speed 1 BC
FF 6-250 155 235 Manual 3-Speed 1 BC
FK (t) 6-250 155 235 Manual 3-Speed 1 BC
FL 6-250 155 235 Manual 3-Speed 1 BC
FM 6-250 155 235 Powerglide 1 BC
FP (t) 6-250 155 235 Powerglide 1 BC
FR 6-250 155 235 Powerglide 1 BC
FV 6-250 155 235 Manual 3-Speed 1 BC
FY 6-250 155 235 Manual 3-Speed 1 BC
FZ (t) 6-250 155 235 Manual 3-Speed 1 BC
GA 8-283 195 285 Manual 3-Speed 2 BC
GC 8-283 195 285 Manual 4-Speed 2 BC
GF 8-283 195 285 Powerglide 2 BC
GK 8-283 195 285 Manual 3-Speed 2 BC
GO 8-283 195 285 Powerglide 2 BC
GP 6-250 155 235 Powerglide 1 BC
GQ 6-250 155 235 Powerglide 1 BC
GR (t) 6-250 155 235 Powerglide 1 BC
GS 8-283 195 285 Manual 4-Speed 2 BC
GT 8-283 195 285 Powerglide 2 BC
GU 8-283 195 285 Manual 3 & 4-Speed 2 BC
HA 8-327 275 355 Manual 3 & 4-Speed 4 BC
HB 8-327 275 355 Manual 3 & 4-Speed 4 BC
HC 8-327 275 355 Powerglide 4 BC
HF 8-327 275 355 Powerglide 4 BC
IA 8-396 325 410 Manual 3 &4-Speed 4 BC
IB 8-396 325 410 Manual 3 & 4-Speed 4 BC
IC 8-396 325 410 Powerglide 4 BC
ID 8-427 425 # 460 Manual 3 & 4-Speed 4 BC
IE (s) 8-427 385 460 Manual 3 & 4-Speed 4 BC
IF (s) 8-427 385 460 Turbo Hydra-Matic 4 BC
IG 8-396 325 410 Powerglide 4 BC
IH 8-427 385 460 Manual 3 & 4-Speed 4 BC
II 8-427 385 460 Manual 3 & 4-Speed 4 BC
IJ 8-427 385 460 Turbo Hydra-Matic 4 BC
IK 8-427 425 # 460 Manual 3 & 4-Speed 4 BC
IN 8-396 325 410 Turbo Hydra-Matic 4 BC
IO 8-427 385 460 Turbo Hydra-Matic 4 BC
IS (s) 8-427 385 460 Turbo Hydra-Matic 4 BC
IV 8-396 325 410 Turbo Hydra-Matic 4 BC
IX (s) 8-427 385 460 Manual 3 & 4-Speed 4 BC
KE 8-327 275 355 Manual 3 & 4-Speed 4 BC
KL 8-327 275 355 Turbo Hydra-Matic 4 BC
KM 8-327 275 355 Turbo Hydra-Matic 4 BC

Notes:
  • :# Special High Performance
  • (s) Impala SS
  • (t) Taxi

1967 Chevrolet Impala Options

Description Description
Power Brakes Speed Warning Indicator
Power Steering Comfort-Lift Steering Wheel
Four Season Comfort Air Conditioning Sport-Styled Steering Wheel
Rear Window Air Deflector on Wagons Stereo Tape System w/ Four Speakers
Rear Manual Antenna Wheel Covers
Custom Deluxe Front & Rear Seat Belts Mag-Style Wheel Covers
Front Shoulder Belts Simulated Wire Wheel Covers
Load Area Carpets 3-Speed Manual Transmission w/ Floor Shift
Electric Clock Overdrive
Rear Window Defroster 4-Speed Manual Transmission (M20)
Tinted Windows (all glass) Powerglide Transmission
Tinted Windshield Turbo Hydra-Matic Transmission
Door Edge Guards 327-cid/275-hp (L30)
Rear Bumper Guards 396-cid/325-hp (L35)
Front Bumper Guards 427-cid/385-hp (L36)
Head Rest Positraction Rear Axle
Heater & Defroster Delete AM/FM Stereo Radio w/ Front Antenna
Tri-Volume Horn Rear Seat Speaker
Special Instrumentation Vinyl Roof Cover
Automatic Superlift Level Control Divided Second Seat
Roof Luggage Rack Strato-Back Vinyl Seat
Left-Hand Outside Remote Control Mirror Strato-Back Cloth Seat
Two-Tone Paint Strato-Back Seats w/ Console Floor-Mounted Shift
Rear Power Antenna Rear Fender Skirts
Six-Way Power Seat Speed & Cruise Control
Four-Way Power Seat Color-Keyed Floor Mats
Power Tailgate Window Push-Button Radio w/ Front Antenna
Power Windows Push-Button AM/FM Radio w/ Front Antenna & Rear Speaker
Push-Button AM/FM Radio w/ Front Antenna

Transmission Codes

Transmission Location
Powerglide (Corvair) On top of the case in the rear at 11 o'clock.
Powerglide Passenger (exc. Corvair) Immediately behind right hand machining lug with the bottom of the sticker parallel to mold flash.
Powerglide All models stamped on the right side of transmission oil pan.
Turbo Hydra-Matic Right hand vertical surface of transmission case
3-Speed Corvair and fully synchronized Passenger (exc. Warner Gear) transmissions stamped on square boss on left side below and rear of cover
4-Speed Passenger models (exc. Corvair) stamped on right side of case ahead of the extension.
4-Speed (Corvair) Stamped on boss on lower left side of case just below side cover.

Plant and Type Designation Prefix Plant Transmission Type
N Muncie 4-Speed
W Warner Gear 3 and 4-Speed
P Muncie 4-Speed
R Saginaw 4-Speed
S Saginaw 3-Speed
M Muncie 3-Speed, Overdrive*
C Cleveland Powerglide
T Toledo Powerglide
CA Hydra-Matic 3-Speed, Automatic Turbo Hydra-Matic
D Saginaw Overdrive
K McKinnon 3-Speed
E McKinnon Powerglide
O Saginaw Overdrive
X Cleveland Turbo Hydra-Matic 350
B Cleveland Turbo Hydra-Matic 350
Y Toledo Turbo Hydra-Matic 350
A Cleveland 2-Speed, Manual Powerglide

*Overdrive distinguished from 3-Speed by physical appearance only. The above transmissions (exc. Warner Gear) will carry a production code number such as: C1116N (C = Cleveland Powerglide, 11 = November, 16 = 16th, N = Night Shift). The Warner Gear transmissions will carry a production code number such as: WG1031 (W = Warner Gear 4-Spd., G = July, 10 = 10th, 7 = 1967, 1 = First Shift).

Axle Codes

Location Of Axle Codes: Stamped on differential carrier (along with date of manufacture) or on the axle tube near carrier.
Codes - Non-Locking Codes - Locking Ratio
DA, GQ DG, GR 3.08
DB, EU DI, GU 3.36
DC, EB, DQ, EO, GP DJ, DK, EC, GX 3.55
DD, DE, DV, GE, GI, GN DH, DW, GJ, GO 3.31
DR, EM, EN, GA, GD, GL DF, DS, GF, GG 3.07
EK, EX DL, EY 3.70
EF, EL DM, EG 3.73
EH DN 4.10
EI DO 4.56
EJ DP 4.88
EP, ER, GB, GK EQ, ES, GC, GM 2.73

Manufacturer Identity
B - Buick C - Chevrolet Buffalo
O - Oldsmobile K - GM of Canada, St. Catharines
P - Pontiac M - GM of Canada
G - Chevrolet Gear & Axle

Paint Codes - Exterior Colors

Color Name / Code Color Image Color Name / Code Color Image

A - Tuxedo Black
Lucite® Code - 88
Dulux® Code - 93-005

L - Tahoe Turquoise (metallic)
Lucite® Code - 4824L
Dulux® Code - 4824DH

C - Ermine White
Lucite® Code - 4024L
Dulux® Code - 93-37774

M - Royal Plum (metallic)
Lucite® Code - 4832L
Dulux® Code - 4832DH

D - Nantucket Blue (metallic)
Lucite® Code - 4815L
Dulux® Code - 4815D

N - Madeira Maroon (metallic)
Lucite® Code - 4624H
Dulux® Code - 181-97213M

E - Deepwater Blue (metallic)
Lucite® Code - 4817L
Dulux® Code - 4817D

R - Bolero Red
Lucite® Code - 4822LH
Dulux® Code - 4822DH

F - Marina Blue (metallic)
Lucite® Code - 4850L
Dulux® Code - 4850D

S - Sierra Fawn (metallic)
Lucite® Code - 4826L
Dulux® Code - 4826D

G - Granada Gold (metallic)
Lucite® Code - 4825L
Dulux® Code - 4825D

T - Capri Cream
Lucite® Code - 4819L
Dulux® Code - 4819D

H - Mountain Green (metallic)
Lucite® Code - 4816L
Dulux® Code - 4816D

Y - Butternut Yellow
Lucite® Code - 4620L
Dulux® Code - 93-96908

K - Emerald Turquoise (metallic)
Lucite® Code - 4818L
Dulux® Code - 4818D


NOTES: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination RA on a Chevrolet would indicate the body finished in Bolero Red and the roof area in Tuxedo Black.) General Motors paint code plate for all models except Corvair and Corvette is located under the hood at the top of the firewall on the left or right of the upper shroud. Corvair paint code plate is on the left cross-rail in the engine compartment. Corvette paint code plate is on the instrument panel brace, below the glove compartment.


Paint Codes - Interior Colors

Color Name / Code Color Image Color Name / Code Color Image

Yellow (semi-gloss)
Lucite® Code - 9383LH

Dark Blue (metallic) (semi-gloss)
Lucite® Code - 9395LH

Medium Gold (metallic) (semi-gloss)
Lucite® Code - 9390L

Dark Blue (metallic) (flat)
Lucite® Code - 9373LH

Dark Gold (semi-gloss)
Lucite® Code - 9406LH

Dark Bright Blue (metallic) (flat)
Lucite® Code - 9286LH

Dark Gold (metallic) (flat)
Lucite® Code - 9378L

Red (semi-gloss)
Lucite® Code - 9366LM

Medium Fawn (metallic) (semi-gloss)
Lucite® Code - 9391L

Dark Red (flat)
Lucite® Code - 9201LM

Dark Fawn (metallic) (semi-gloss)
Lucite® Code - 9403L

Dark Maroon (flat)
Lucite® Code - 9389LM

Dark Fawn (metallic) (flat)
Lucite® Code - 9375L

Maroon (flat)
Lucite® Code - 9293LM

Medium Turquoise (metallic) (semi-gloss)
Lucite® Code - 9398LH

Plum (metallic) (semi-gloss)
Lucite® Code - 9384LM

Dark Turquoise (metallic) (semi-gloss)
Lucite® Code - 9399LH

Plum (metallic) (flat)
Lucite® Code - 9200LM

Dark Turquoise (metallic) (flat)
Lucite® Code - 9374LH

Black (semi-gloss)
Lucite® Code - 88

Medium Bright Blue (metallic) (semi-gloss)
Lucite® Code - 9387LH

Black (flat)
Lucite® Code - 4428L



Medium Blue (metallic) (semi-gloss)
Lucite® Code - 9392LH



NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use 1/2 oz. DuPont #4528 flattening compound to a pint of unreduced color.



Striping Colors

Striping Colors Station Wagon Wood Grain Touch-Up Colors

Black
Lucite® Code - 88

Dark Tan
Lucite® Code - 9427L

White/Ivory
Lucite® Code - 4024L

Light Tan
Lucite® Code - 9548L



Trunk Colors (spatter finish)

Black - Gray - Aqua 389 - 259

Protect-O-Plate Decoding

Location Description Location Description
A Interior Trim J Radio - Clock Group
B Body Exterior Paint K Radio Code
C Vehicle Identification Number L Disc Brake Code
D Carburetor Source Code M Air Conditioning
E Engine Number N Power Window Code
F Rear Axle Number O Power Seat Code
G Vehicle Build Month Code P Chevrolet Trade Mark
H Transmission Number Q Dealer Supplied Owner Information
I Power Steering and/or Power Brakes
Location A - Interior Trim
Passenger
Code Color Code Color
A Red Vinyl M Maroon
B Blue N Black Cloth
C Black Vinyl P Plum
D Red R Bright Blue
E Black S Blue Cloth
F Fawn T Turquoise
G Golf U Blue Vinyl (Opt.)
H Blue Vinyl V Fawn Vinyl
K Parchment Black W Gold Cloth
L Black Vinyl (Opt.) Y Yellow
Corvette
Code Color Code Color
B Dark Teal Blue Vinyl N Dark Teal Blue Leather
C Saddle Vinyl R Bright Blue Vinyl
D Red Vinyl S White/Black Vinyl
E Black Vinyl T Bright Blue Leather
J Saddle Leather W White/Blue Vinyl
K Black Leather X Dark Green Vinyl
M Red Leather
Location B - Exterior Color
All passenger models will have RPO letter designation stamped in this location. On two tone combinations, the first letter indicates the lower color, second letter the upper color. See Exterior Paint Codes in the VIN & Decoding section.
Location C - Vehicle Identification Number
A five digit numbering system will be used on all 1967-1969 passenger cars.
10000 Series - Corvair 13000 Series - Chevelle
11000 Series - Chevy II 15000, 16000 Series - Chevrolet
12000 Series - Camaro 19000 Series - Corvette
The first two digits denote the vehicle series. The third indicates base engine equipment, and the two remaining numbers identify the body style. When the third digit is odd (1, 3, 5, 7), the base engine is an inline four or six cylinder. When the third number is even (2, 4, 6, 8), the base engine is a V-8.
The complete serial number consists of the above model identification, year of manufacture, plant designation, and sequence number.
Example: 164397F100500
16439 = Impala V-8 4-Dr. Sport Sedan, 7 = 1967 Model, F = Flint Built. 100500 = 500th 1967 Chevrolet built at Flint
Location D - Carburetor Source
Code Plant Code Plant
B Bay City H Holley
C Carter R Rochester


Top of page




Note: Information, Specifications, Resources & Photos found in the Research Library
should only be used as general guidelines. OldRide LLC makes no warranty as to the
authenticity and accuracy of the information contained hereon.


Home | Classifieds: Vehicles / Parts | Sell on OldRide | Rusty Rides | OldRide Answers | Events | Clubs

Library | Car & Truck Resources | MyOldRide Account | Support | OldRide Banners | Car Photos


Copyright © 2014 Internet Brands, Inc. All rights reserved | OldRide Support | Terms of Use | Classified Guidelines | Privacy Policy | Cookies
