1966 Chevrolet Corvette

The 1966 Corvette featured a new egg-crate grille and functional engine compartment cooling vents. Chevrolet’s new "427" replaced the 396 as Corvettes top power-plant option. The new 427 packed pure power, and was first offered with two options for these big blocks. The RPO L36 was priced at $181and rated at 390 hp and the RPO L72, with a price tag of $312 was rated at 425 hp. The 427/425 hp Corvette convertible could hit 60 mph in just 5.7 seconds, and ran the quarter mile in 14 seconds. "427 Turbo Jet" crossed racing flag emblems appeared above the cooling vents. Three four speed gearboxes -- wide ratio, close-ratio, and heavy-duty close ratio were optional. Side-mounted exhaust pipes were optional. A total of 5,116 L36s and 5,258 L72s were built, resulting in 38% of the 1966 Corvettes optioned with 427 power-plants.



1966 Chevrolet Corvette Production Numbers

Model Number	Body/Style Number	Body Type & Seating	Factory Price	Shipping Weight	Total Production
Corvette
94	37	2 Dr Fastback Coupe	$4,295	2,985 lbs	9,958
94	67	2 Dr Convertible	$4,084	3,005 lbs	17,762

Chassis Data

Model	Wheelbase	Overall Lenght	Width	Front Tread	Rear Tread	Tires
Corvette	98 in	175.2 in	69.6 in	57.6 in	58.3 in	7.75 x 15

1966 Chevrolet Corvette Options

Code	Description	Price
898	Genuine Leather Seats	$79.00
A01	Soft-Ray Tinted Windows (all glass)	$15.80
A02	Soft-Ray Tinted Windshield	$10.55
A31	Power Windows	$59.20
A82	Headrests	$42.15
A85	Shoulder Belts	$26.35
C07	Auxiliary Hardtop	$231.75
C48	Heater & Defroster Deletion (credit)	$97.85
C60	Air Conditioning	$412.90
F41	Special Front & Rear Suspension	$36.90
G80	Positraction Rear Axle	$42.15
J50	Power Brakes	$43.05
J56	Special Heavy-Duty Brakes	342.30
K19	Air Injection Reactor	$45.00
K66	Transistor Ignition System	$75.35
L36	427-cid/390-hp V8	$181.20
L72	427-cid/425-hp V8	$312.85
L79	327-cid/350-hp V8	$105.35
M20	4-Speed Manual Transmission	$184.30
M21	4-Speed Close-Ratio Manual Transmission	$184.30
M22	Heavy-Duty 4-Speed Close-Ratio Manual Transmission	$236.95
M35	Powerglide Automatic Transmission	$194.85
N03	36-Gallon Fuel Tank	$198.05
N11	Off Road Exhaust System	$36.90
N14	Side Mount Exhaust System	$131.65
N32	Teakwood Steering Wheel	$48.45
N36	Telescopic Steering Column	$42.15
N40	Power Steering	$94.80
P48	Cast Aluminum Knock-Off Wheels	$322.80
P92	7.75 x 15 Rayon White Sidewall Tires	$31.30
T01	7.75 x 15 Nylon Gold Sidewall Tires	$46.55
U69	AM-FM Radio	$199.10
Z01	Comfort & Convenience Group	$16.15
V74	Traffic Hazard Light Switch	$11.60

1966 Chevrolet Corvette Engine Options

Location Of Engine Code: Stamped on the block in front of the right hand cylinder head.

Letter Code	Engine	Horsepower	Torque	Transmission	Carburetor
HD	8-327 #	350	360	4-Speed Manual	4 BC
HE	8-327 *	300	360	3 & 4-Speed Manual	4 BC
HH	8-327 *	300	360	3 & 4-Speed Manual	4 BC
HO	8-327 *	300	360	Powerglide	4 BC
HP	8-327 *	300	360	3 & 4-Speed Manual	4 BC
HR	8-327 *	300	360	Powerglide	4 BC
HT	8-327 #	350	360	4-Speed Manual	4 BC
IK	8-427 #	425	460	4-Speed Manual	4 BC
IL	8-427	390	460	4-Speed Manual	4 BC
IM	8-427	390	460	4-Speed Manual	4 BC
IP	8-427 #	425	460	4-Speed Manual	4 BC
KH	8-327 #	350	360	4-Speed Manual	4 BC

+ High Lift Camshaft * High Performance

Transmission Codes

Transmission	Location
3-Speed Manual	Stamped on rear face of upper right corner
4-Speed Manual	On the top right flat of the case assembly
Turbo Hydra-Matic	Right hand vertical suface of transmission case
Powerglide	Stamped on the bottom of oil pan, immediately behind right hand machining lug with the bottom of the sticker parallel to mold flash, stamped on right side of transmission oil pan

Plant and Type Designation Prefix	Plant	Transmission Type
N	Muncie	4-Speed
W	Warner Gear	3 and 4-Speed
P	Muncie	4-Speed
R	Saginaw	4-Speed
S	Saginaw	3-Speed
M	Muncie	3-Speed, Overdrive*
C	Cleveland	Powerglide
T	Toledo	Powerglide
CA	Hydra-Matic	3-Speed, Automatic Turbo Hydra-Matic
D	Saginaw	Overdrive
K	McKinnon	3-Speed
E	McKinnon	Powerglide
O	Saginaw	Overdrive
X	Cleveland	Turbo Hydra-Matic 350
B	Cleveland	Turbo Hydra-Matic 350
Y	Toledo	Turbo Hydra-Matic 350
A	Cleveland	2-Speed, Manual Powerglide

*Overdrive distinguished from 3-Speed by physical appearance only. The above transmissions (exc. Warner Gear) will carry a production code number such as: C1116N (C = Cleveland Powerglide, 11 = November, 16 = 16th, N = Night Shift). The Warner Gear transmissions will carry a production code number such as: WG1031 (W = Warner Gear 4-Spd., G = July, 10 = 10th, 7 = 1967, 1 = First Shift).

1966 Chevrolet Corvette Exterior Paint Codes

Color Name / Code	Color Image	Color Name / Code	Color Image
900 - Tuxedo Black Lucite® Code - 88 Dulux® Code - 93-005		980 - Trophy Blue Lucite® Code - 4712L Dulux® Code - 181-97846
972 - Ermine White Lucite® Code - 4024L Dulux® Code - 93-93774		982 - Mosport Green Lucite® Code - 4713L Dulux® Code - 181-97847
974 - Rally Red Lucite® Code - 4688LH Dulux® Code - 93-97541H		984 - Sunfire Yellow Lucite® Code - 4711L Dulux® Code - 93-97845H
976 - Nassau Blue Lucite® Code - 4690L Dulux® Code - 181-97344		986 - Silver Pearl Lucite® Code - 4621L Dulux® Code - 181-97210
978 - Laguna Blue Lucite® Code - 4710L Dulux® Code - 181-97844		988 - Milano Maroon Lucite® Code - 4689LM Dulux® Code - 181-97343M
NOTES:The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination VC on a Chevrolet would indicate the body finished in Cameo Beige and the roof area in Ermine White.) General Motors paint code plate for all models except Corvair and Corvette is located under the hood at the top of the firewall on the left or right of the upper shroud. Corvair paint code plate is on the left rear wheel housing. Corvette paint code plate is under the dash, below the glove compartment.

1966 Chevrolet Corvette Interior Paint Codes

Color Name / Code	Color Image	Color Name / Code	Color Image
Medium Dark Saddle Lucite® Code - 9190LH (flat)		Red Lucite® Code - 9188LH (flat)
Dark Green Lucite® Code - 9187LH (flat)		Maroon Lucite® Code - 9186LM (flat)
Dark Bright Blue Lucite® Code - 9282LH (flat)		Black Lucite® Code - 4466L (flat)
Dark Teal Blue Lucite® Code - 9283LH (flat)
NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use DuPont #4528 flattening compound to reduce gloss.

Trunk Colors (spatter finish)

Gray Black 389-259

Axle Codes

Location Of Axle Codes: The axles for Chevrolet will be built by Chevrolet Buffalo, Chevrolet Gear and Axle, Buick, Oldsmobile, and McKinnon. Divisional Manufacturer code letters will be metal stamped on the axle tube adjacent to the carrier for identification. Metal stamp on left rear axle tube on the rear side, letters and numerals 3/16 in. high, 3 in. outboard of carrier.

Codes - Non-Locking	Codes - Locking	Ratio	Inspection Cover
	AL, AT	3.08	10 Bolt
AK	AM, AU	3.36	10 Bolt
	AN, AZ	3.55	12 Bolt
AS	AO, FA	3.70	12 Bolt
	AP, FB	4.11	12 Bolt
	FC	4.56	12 Bolt
