1964 Pontiac Catalina
The Catalina featured the same standard eqiuipment as the year before, and also came equipped with full wheel discs and rocker molding options.

1964 Pontiac Catalina

In 1964, Catalinas got a refreshment. They were about an inch longer even though they looked shorter. They had side moldings running from the rear of the front wheel opening to the rear, "Catalina" front fender scripts, and series medallions on the rear fenders. They still had the same standard equipment as the year before but many came with full wheel discs and rocker molding options. The Catalina 2+2 option package was available (2347, 2367) and the Ventura trim package was an interior decor group (2339, 2347, 2367).



1964 Pontiac Catalina Specifications

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
Catalina Series 23
23 69 4d Sedan - 6P $2,806 3,770 lbs 84,457
23 39 4d Hardtop - 6P $2,945 3,835 lbs 33,849
23 11 2d Sedan - 6P $2,735 3,695 lbs 12,480
23 47 2d Hardtop - 6P $2,869 3,750 lbs 74,793
23 67 2d Convertible - 5P $3,181 3,825 lbs 18,693
23 45 4d Station Wagon - 9P $3,311 4,235 lbs 13,140
23 35 4d Station Wagon - 6P $3,203 4,190 lbs 20,356

NOTES:

  1. 257,768 Catalinas Were Built
  2. 15,194 had Synchromesh
  3. 242,574 had Hydra-Matic
  4. 7,998 had the 2+2 option

Model Series Identification

2369 - 4d Sedan - 6P 2367 - 2d Convertible - 5P
2339 - 4d Hardtop - 6P 2345 - 4d Station Wagon - 9P
2311 - 2d Sedan - 6P 2335 - 4d Station Wagon - 6P
2347 - 2d Hardtop - 6P

Chassis Data

Model Wheelbase Overall Length Front Tread Rear Tread Tires
Catalina 120 in 213 in 62.5 in 64 in 8.00 x 14
Catalina Station Wagon 119 in 213.8 in 62.5 in 64 in 8.50 x 14

VIN Decoding

Serial Numbers were on the left front hinge pillar. Fisher body on cowl tells style number, body number, trim code, paint code, and other data.
First Symbol - Engine
4 = Four Cylinder 8 = Eight Cylinder (V-8)
6 = Six Cylinder

Second Symbol - Series
0 = Tempest (Standard) 5 = Ventura
1 = Tempest (Custom) 6 = Star Chief
2 = LeMans 8 = Bonneville
3 = Catalina 9 = Grand Prix

Third Symbol - Year
4 = 1964

Fourth Symbol - Assembly Plant
(B) Baltimore, Maryland (P) Pontiac, Michigan
(D) Doraville, Georgia (R) Arlington, Texas
(E) Linden, New Jersey (S) Southgate, California
(F) Fremont, California (U) Lordstown, Ohio
(G) Framingham, Massachusetts (X) Kansas City, Kansas
(M) Kansas City, Missouri

Last Four Symbols - Production Sequence
Started at 1001


1964 Pontiac Engines

Location Of Engine Code: (Six-Cyl) - On cylinder head-to-block contact surface behind oil filter pipe. (V8) - Stamped on right front side of block or beneath production engine number on machined pad on right hand bank of engine block.

Letter Code Engine Horsepower Torque Transmission Carburetor
01A 8-389 215 390 Manual 2 BC
02B 8-389 215 390 Heavy Duty Manual 2 BC
03A 8-389 215 390 Manual 2 BC
04L 8-389 230 386 Automatic 2 BC
05L 8-389 230 386 Automatic 2 BC
08R 8-389 230 386 Automatic 2 BC
09R 8-389 230 386 Automatic 2 BC
10A 8-389 283 418 Manual 2 BC
11H 8-389 267 410 Manual 2 BC
12H 8-389 267 410 Automatic 2 BC
13L 8-389 Not Available Not Available Automatic 2 BC
17M 8-389 283 418 Automatic 2 BC
18M 8-389 283 418 Automatic 2 BC
19R 8-389 Not Available Not Available Automatic 2 BC
22B 8-389 235 386 Heavy Duty Manual 2 BC
23B 8-389 306 420 Heavy Duty Manual 4 BC
25K 8-389 303 430 Automatic 4 BC
26K 8-389 303 430 Automatic 4 BC
27P 8-389 303 430 Automatic 4 BC
28P 8-389 303 430 Automatic 4 BC
29N 8-389 306 420 Automatic 4 BC
30R 8-389 Not Available Not Available Automatic 4 BC
32B 8-389 325 428 Automatic 4 BC
33-6 8-389 330 430 Automatic 3 -2 BC
34N 8-389 330 430 Automatic 3 -2 BC
35B 8-421 320 455 Manual 4 BC
38S 8-421 320 455 Automatic 4 BC
43N 8-421 320 455 Automatic 4 BC
44B 8-421 350 454 Manual 3 -2 BC
45B 8-421 370 460 Manual 3 -2 BC
46G 8-421 370 460 Automatic 3 -2 BC
47S 8-421 350 454 Automatic 3 -2 BC
49N 8-421 350 454 Automatic 3 -2 BC
50Q 8-421 370 460 Automatic 3 -2 BC

Transmission Codes

Transmission Location
Super Hydra-Matic "315" (Dual-Coupling Hydra-Matic) On name plate located on lower left corner of the rear face of transmission case.
Roto Hydra-Matic "10" On serial number plate attached to left side of transmission.
Super Turbine 300 (TempesTorque) On metal tag fastened to right side of transmission case or stamped on lower servo cover.
Jetway On metal tag fastened to right side of transmission case or stamped on lower servo cover.
3-Speed Painted or stamped on the transmission case.
4-Speed Painted or stamped on the transmission case.

Plant and Type Designation Prefix Transmission Type
20 TempesTorque
30 TempesTorque
31 TempesTorque
40 TempesTorque
MC TempesTorque
NA TempesTorque
NB TempesTorque
P Roto Hydra-Matic "10"
PAH Roto Hydra-Matic "10"
PAS Super Hydra-Matic "315"
PB Roto Hydra-Matic "10"
PBS Super Hydra-Matic "315"
PC Roto Hydra-Matic "10"
PCS Super Hydra-Matic "315"
PE Roto Hydra-Matic "10"
PEH Roto Hydra-Matic "10"
PES Super Hydra-Matic "315"
PG Roto Hydra-Matic "10"
PS Super Hydra-Matic "315"


Axle Codes


Location Of Axle Codes: Color Markings on flange end of axle shaft and by ratio stamped on right hand axle tube. (For example: if 43-10 is stamped on the axle tube it is a 4.30:1 ratio. Just divide the first number by the second number to give you the ratio.)

Color - Non-Locking Color - Locking Ratio
Black Black & Green 4.30
Blue Blue & Green 3.55
Brown Brown & Green 3.23
Gray Gray & Green 2.56
  Green 3.90
Orange Orange & Green 2.93
Pink Pink & Green 3.73
Red Red & Green 2.78
Yellow Yellow & Green 3.08
White White & Green 3.36


Options and Accessories

Description Description
Air Conditioning Sports Wheel Covers
Console (incl. tachometer) Aluminum Hubs & Drums
Instrument Gauge Cluster 3-Speed Manual Transmission
Luggage Carrier Hydra-Matic Transmission
Remote Control Mirror 4-Speed Manual Transmission
Power Brakes 389-cid/230-hp V-8 (economy)
Power Seat 389-cid/330-hp V-8 (Tri-Power)
Power Tilt Bucket Seat (driver's side) 389-cid/348-hp V-8 (Tri-Power)
Tachometer 421-cid/350-hp V-8 (Tri-Power)
Cordova Top 421-cid/370-hp V-8 (Tri-Power)
Ventura Trim (Catalina 2369, 2339, & 2347)



Paint Codes - Exterior Colors

Color Name / Code Color Image Color Name / Code Color Image

A - Tuxedo Black
Lucite® Code - 88
Dulux® Code - 93-005

V - Ember Red
Lucite® Code - 4387LH
Dulux® Code - 93-95896H

J - Meadow Green Metallic
Lucite® Code - 4532L
Dulux® Code - 181-96882

S - Saddle Tan Metallic
Lucite® Code - 4392L
Dulux® Code - 181-96217

H - Skyline Blue
Lucite® Code - 4531
Dulux® Code - 93-96881

C - Ermine White
Lucite® Code - 4024L
Dulux® Code - 93-93774

F - Silver Blue Metallic
Lucite® Code - 4250L
Dulux® Code - 181-95180

R - Desert Beige
Lucite® Code - 4526L
Dulux® Code - 93-96809

W - Daytona Blue Metallic
Lucite® Code - 4395L
Dulux® Code - 181-96220

D - Satin Silver Metallic
Lucite® Code - 4247L
Dulux® Code - 181-95176

P - Azure Aqua Metallic
Lucite® Code - 4253L
Dulux® Code - 181-95183

N - Sunfire Red Metallic
Lucite® Code - 4533LH
Dulux® Code - 181-96884H

Q - Lagoon Aqua Metallic
Lucite® Code - 4529L
Dulux® Code - 181-96812

L - Palomar Red Metallic #2
Lucite® Code - 4600LM
Dulux® Code - Not Available

T - Almond Fawn Metallic
Lucite® Code - 4527L
Dulux® Code - 181-96810


NOTES: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination FW on a Pontiac would indicate the body finished in Yorktown Blue Metallic and the roof area in Nocturne Bleu Metallic.) General Motors paint code plate for all models except Corvair and Corvette is located under the hood at the top of the firewall on the left or right of the upper shroud. Corvair paint code plate is on the left rear wheel housing. Corvette paint code plate is under the dash, below the glove compartment.


Paint Codes - Interior Colors

Color Name / Code Color Image Color Name / Code Color Image

Parchment
Lucite® Code - 9000L (semi-gloss)

Dark Aqua Metallic
Lucite® Code - 9012LH (semi-gloss)
Lucite® Code - 4429L (flat)

Medium Fawn Metallic
Lucite® Code - 4527L (semi-gloss)

Medium Blue Metallic
Lucite® Code - 9006L (semi-gloss)

Light Saddle Metallic
Lucite® Code - 9086LH (semi-gloss)

Dark Blue Metallic
Lucite® Code - 96221 (semi-gloss)
Lucite® Code - 4430L (flat)

Dark Saddle
Lucite® Code - 4436L (flat)

Light Maroon Metallic
Lucite® Code - 9084LM (semi-gloss)
Medium Gray Metallic
Lucite® Code - 9010L (semi-gloss)

Medium Red
Lucite® Code - 9016LH (semi-gloss)

Dark Gray Metallic
Lucite® Code - 9009L (semi-gloss)
Lucite® Code - 4433L (flat)
Red
Lucite® Code - 2931LH (semi-gloss)

Medium Olive Metallic
Lucite® Code - 4532LH (semi-gloss)

Medium Maroon Metallic
Lucite® Code - 9090LM (semi-gloss)

Dark Olive Metallic
Lucite® Code - 4584LH (flat)

Dark Maroon Metallic
Lucite® Code - 94969H (semi-gloss)

Medium Aqua Metallic
Lucite® Code - 9005L (semi-gloss)

Black
Lucite® Code - 88 (semi-gloss)
Lucite® Code - 4428L (flat)

NOTE: Unrubbed LUCITE® will generally produce a gloss comparable to original unrubbed interior semi-gloss finishes. If lower gloss is required, use DuPont #4528 flattening compound to reduce gloss. This can be approximately 10%.



Trunk Colors (spatter finish)

Red = 389 - 219

Blue-Green = 389 - 220
