| The two-tone paint scheme was eliminated on the '62 Vette. |
|
|
1962 Chevrolet Corvette
The Corvette looked cleaner for 1962, with less chrome and without the two-tone paint option, though bright rocker-panel trim was added. 1962 also marked the last of the straight axle Corvettes, and was the first year the Corvette was offered with a 327 small block V8. The 327 was offered with several horse power options including a 250, 300, 340 and the biggest yet 360hp “fuelie”. The Corvette was a true sports car, as power steering, power brakes, and air condition were not available, although Performance seekers could order "Duntov" camshafts, thermo-activated cooling fans, and aluminum-cased transmissions. The special racing package called "Sebring" included a direct-flow exhaust system, 15x5.5 inch wheels, a 24-gallon fuel tank ($118.40), four-speed gearbox ($188.30), Posi-Traction rear axle ($43.05), sintered metallic brake linings ($37.70), and a heavy-duty suspension ($333.60). The most desired option was the 327 V8 "fuelie" rated at 370 hp with a extra cost of $484.20.
1962 Chevrolet Corvette Production Numbers
| Model Number | Body/Style Number | Body Type & Seating | Factory Price | Shipping Weight | Total Production |
| Corvette | |||||
| 08 | 67 | 2 Dr Convertible | $4,038 | 2,925 lbs | 14,531 |
Chassis Data
| Model | Wheelbase | Overall Lenght | Width | Front Tread | Rear Tread | Tires |
| Corvette | 102 in | 177.2 in | 72.8 in | 57 in | 58.8 in | 6.70 x 15 |
VIN Numbers |
||||||||||||||||||||||||
| Serial Numbers were stamped on a plate on the left front door hinge pillar (center pillar on Corvair). The Fisher Body number plate on the right-hand side of the cowl gives additional information such as the body style number, the production sequence number, the trim (upholstery) number code and the paint number code. | ||||||||||||||||||||||||
 |
||||||||||||||||||||||||
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
1962 Chevrolet Corvette Options
| Code | Description | Price |
| 102 | Signal Seeking AM Radio | $137.75 |
| 276 | 15 x 5.5 Wheels | No Charge |
| 313 | Powerglide Transmission | $199.10 |
| 419 | Auxiliary Hardtop | $236.75 |
| 426 | Power Windows | $59.20 |
| 441 | Direct-Flow Exhaust | No Charge |
| 473 | Power Operated Folding Top | $161.40 |
| 675 | Positraction Rear Axle | $43.05 |
| 685 | 4-Speed Manual Transmission | $188.30 |
| 686 | Metallic Brakes | $37.70 |
| 687 | Heavy-Duty Brakes & Suspension | $333.60 |
| 1625A | 24-Gallon Fuel Tank | $161.40 |
| 1832 | 6.70 x 15 White Sidewall Tires | $31.55 |
| 1833 | 6.70 x 15 Black Sidewall Tires | $15.75 |
| Not Available | Positive Crankcase Ventilation | $ Not Available |
| 396 | 327-cid/340-hp V-8 | $107.60 |
| 582 | 327-cid/370-hp V-8 | $484.20 |
| 583 | 327-cid/300-hp V-8 | $53.80 |
1962 Chevrolet Corvette Engine Options
Location Of Engine Code: Stamped on the block in front of the right hand cylinder head.
| Letter Code | Engine | Horsepower | Torque | Transmission | Carburetor |
| RC | 8-327 | 250 | 350 | 3 & 4-Speed Manual | 4 BC |
| RD | 8-327 * | 300 | 360 | 3 & 4-Speed Manual | 4 BC |
| RE | 8-327 + # | 340 | 344 | 3 & 4-Speed Manual | 4 BC |
| RF | 8-327 + | 360 | 352 | 3 & 4-Speed Manual | Fuel Injection |
| SC | 8-327 | 250 | 350 | Powerglide | 4 BC |
| SD | 8-327 * | 300 | 360 | Powerglide | 4 BC |
+ High Lift Camshaft
* High Performance
# Special High Performance
Transmission Codes
| Transmission | Location |
| 3-Speed Manual | Stamped on rear face of upper right corner |
| 4-Speed Manual | Stamped on boss on lower left side of case just below side cover. |
| Powerglide | Stamped on the bottom of oil pan |
| Plant and Type Designation Prefix | Plant | Transmission Type |
| W | Warner Gear | 4-Speed |
| S | Saginaw | 3-Speed, Overdrive* |
| C | Cleveland | Powerglide |
*Overdrive distinguished from 3-Speed by physical appearance only. The above transmissions will carry a production code number such as: S304 (S = Saginaw 3-Speed, 3 = March, 04 = 4th.)
1962 Chevrolet Corvette Exterior Paint Codes
| Color Name / Code | Color Image | Color Name / Code | Color Image |
923 - Roman Red |
|
940 - Sateen Silver Metallic Lucite® Code - 4023L Dulux® Code - 181-9009 |
 |
936 - Ermine White |
 |
938 - Almond Beige |
 |
948 - Honduras Maroon Metallic |
 |
920 - Fawn Beige Metallic Lucite® Code - 4146L Dulux® Code - 181-94697 |
 |
925 - Coronna Cream |
 |
900 - Tuxedo Black |
 |
NOTES: General Motors paint code plate for all models except Corvair and Corvette is located under the hood at the top of the firewall on the left or right of the upper shroud. Corvair paint code plate is on the left rear wheel housing. Corvette paint code plate is not shown on car. |
|||
1962 Chevrolet Corvette Interior Paint Codes
| Color Name / Code | Color Image | Color Name / Code | Color Image |
Black |
Not Available | Fawn Metallic Duco® Code - 94697 |
Not Available |
| Red Duco® Code - 2967H |
Not Available | ||
NOTE: Unrubbed LUCITE® will generally produce a gloss comparable to original unrubbed interior semi-gloss finishes. If lower gloss is required, use DuPont #4528 flattening compound to reduce gloss. |
|||
Axle Codes
Location Of Axle Codes: The axles for Chevrolet will be built by Chevrolet Buffalo, Chevrolet Gear and Axle, Buick, Oldsmobile, and McKinnon. Divisional Manufacturer code letters will be metal stamped on the axle tube adjacent to the carrier for identification. Metal stamp on left rear axle tube on the rear side, letters and numerals 3/16 in. high, 3 in. outboard of carrier.
| Codes - Non-Locking | Codes - Locking | Ratio | Inspection Cover |
| CA | CB | 3.36 (std. lining) | 10 Bolt |
| CH | CK | 3.36 (metallic lining) | 10 Bolt |
| CC | 3.55 (std. lining) | 12 Bolt | |
| CJ | CL | 3.55 (metallic lining) | 12 Bolt |
| CD | 3.70 (std. lining) | 12 Bolt | |
| CM | 3.70 (metallic lining) | 12 Bolt | |
| CE | 4.11 (std. lining) | 12 Bolt | |
| CN | 4.11 (metallic lining) | 12 Bolt | |
| CF | 4.56 (std. lining) | 12 Bolt | |
| CP | 4.56 (metallic lining) | 12 Bolt |
