1974 Ford F100
The 1974 Ford Pickup

1974 Ford F-100

For 1974 a new extended cab version was available on the Ford F-series. The Supercab was offered as either a full-width rear seat or two facing jumper seats that fold out of the way when not in use. Supercab could be ordered in 6.75 ft. or 8 ft. Styleside box. 16 different colors to choose from were available as well as a two-tone paint scheme option. The F100 had many standard features including Instrument cluster with green backlighting, keyless locking doors, ashtray, door scuff plates, seatbelts, 2-speed winshield wipers, and dome light with door courtesy light switches.

The F250 carried most of the same features as the F100 but included a standard 3-speed transmission plus power brakes. For only $600 more, the truck could come in a 4x4 version.  In 1974, the F350 was available only with the Styleside box but you could choose from 3 different cabs including Regular, Supercab or Crew Cab. A 4-speed manual transmission came standard on all F350's as well as front shocks and heavy-duty power front disc brakes.

1974 Ford Production Numbers

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
F100 - 1/2 Ton - 117 in. wheelbase
81 - Chassis & Cab $3,092 3,125 lbs Note 1
83 - Flareside 6.75 ft $3,246 3,480 lbs Note 1
83 - Styleside 6.75 ft $3,246 3,480 lbs Note 1
F100 - 1/2 Ton - 133 in. wheelbase
83 - Flareside 8 ft $3,282 3,570 lbs Note 1
83 - Styleside 8 ft $3,282 3,570 lbs Note 1
F100 Supercab - 1/2 Ton - 139 in. wheelbase
83 - Styleside 6.75 ft $4,185 3,820 lbs Note 1
F100 - 1/2 Ton - 133 in. wheelbase
83 - Styleside 8 ft $4,221 3,930 lbs Note 1
F250 - 3/4 Ton - 133 in. wheelbase
80 - Chassis & Cab $3,410 3,480 lbs Note 2
83 - Flareside $3,564 3,900 lbs Note 2
83 - Styleside $3,564 3,900 lbs Note 2
F250 Supercab - 3/4 Ton - 140 in. wheelbase
83 - Supercab $4,473 4,015 lbs Note 2
F250 Crew Cab - 3/4 Ton - 155 in. wheelbase
80 - Chassis & Cab $4,229 4,100 lbs Note 2
83 - Styleside $4,371 4,455 lbs Note 2
F350 - 1 Ton - 137 in. wheelbase
80 - Platform 9 ft $3,873 4,315 lbs Note 3
81 - Chassis & Cab $3,510 3,730 lbs Note 3
83 - Styleside $3,958 4,365 lbs Note 3
86 - Stake 9 ft $3,912 4,365 lbs Note 3
F350 Supercab - 1 Ton - 140 in. wheelbase
83 - Styleside $5,070 4,570 lbs Note 3
F350 - 1 Ton - 161 in. wheelbase
80 - Platform 12 ft. $4,875 - Note 3
86 - Stake 12 ft. $5,115 - Note 3
F350 Crew Cab - 1 Ton - 155 in. wheelbase
81 - Chassis & Cab $4,363 4,290 lbs Note 3
83 - Styleside $4,514 4,730 lbs Note 3

Note:

  1. F100 = Chassis & Cab - 2,241 ; Chassis & Cab 4x4 - 2,547; Flareside - 2,517; Flareside 4x4 - 176; Styleside - 389,407; Styleside 4x4 - 26,788; Supercab - 17,537
  2. F250 = Chassis & Cab - 5,616; Chassis & Cab 4x4 - 1,137; Flareside - 1,787; Flareside 4x4 - 645; Styleside - 123,711; Styleside 4x4 - 34,618; Supercab - 10,852
  3. F350 = Chassis & Cowl - 144; Chassis & Cab - 48,812; Platform & Rack - 7,546; Platform - 786; Supercab - 1340; Styleside - 9,929

Chassis Data

Model Wheelbase GVW Tires
F100 117 in / 133 in 4,600 - 5,500 lbs G78 x 15B
F100/F250 Supercab 139 in
F250 133 in 6,200 - 8,100 lbs 8.00 x 16.5D
F250/F350 Crew Cab 155 in - -
F350 137 in / 161 in 8,350 - 10,000 lbs 8.75 x 16.5E
F350 Supercab 161 in



Vin Number Decoding - 1974 Ford Trucks

Location: stamped on rating plate

First 3 Symbols - Series
F10 = F100 - 2 wd F11= F100 - 4wd F25 = F250 - 2 wd F26 = F250 - 4 wd F35 = F350
Fourth Symbol - Engine
A or 1 = 240 cid 6 cylinder H = 390 cid V8
B or 2 = 300 cid 6 cylinder Y or 8 = 360 cid V8
G or 3 = 302 cid 6 cylinder
Fifth Symbol - Assembly Plant
C = Ontario, Canada N = Norfolk, VA.

E = Mahwah, NJ.

P = Twin Cities, MN.
H = Lorain, OH. R = San Jose, CA.
K = Kansas City, KS. S = Allen Park, MI.
L = Michigan Truck V = Louisville, KY (Truck)
Last Six Symbols - Production Sequence

1974 Ford F100 Advertisements
