1970 Pontiac Grand Prix
The big news for 1970 was a special Hurst SSJ version, a semi-custom conversion with an electric sunroof, gold-colored wheels, and a Hurst shifter.

1970 Pontiac Grand Prix

With the overwhelming success from the previous year 1969 redesign, Pontiac essentially carried over with the basic design for the 1970 Grand Prix. With the exception from the previous year the grille itself now featured vertical slats, and vertical hash marks appeared on the front fenders just behind the front wheels. New interior upholstery patterns and the reintroduction of the bench seat consisted of most of the visual changes.

The big news for 1970 was a special Hurst SSJ version, a semi-custom conversion with an electric sunroof, gold-colored wheels, and a Hurst shifter. The SSJ started life as J models (the vinyl accent stripes on SJs were incompatible) built by Pontiac, than sent to Hurst. All 272 cars were painted either Starlight Black (code AA) or Cameo white (code CC) . Interiors were black, ivory, or sandlewood in cloth or all-Morrokide. Mandatory options included body-color Sport mirrors, G78 x 14 whitewalls and Rally II wheels. The Space-Saver spare and Ride & Handling package were recommended. After assembly, the cars were shipped to a Hurst plant in Southfield, Michigan where Frost Gold accents were applied to the hood, side windows, front of the roof, and Rally II wheels. A landau-style half-top (Antique white, white, or black) was installed, as was a steel electronically operated sunroof (similar to that used in the Cadillac Eldorado).

1970 Pontiac Grand Prix Production

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
276 57 2 dr Hardtop - 5P $3,985 3,784 lbs 65,750
  • 500 had Synchromesh (329 of those had 4-speed gearboxes)
  • 65,250 had automatic

Chassis Data

Model Wheelbase Overall Length Front Tread Rear Tread Tires
Grand Prix 118 in 210.2 in 63 in 64 in Not Available

VIN Decoding

First Symbol - Manufacturer
2 = Pontiac
Second & Third Symbol - Series
23 = Firebird 39 = Safari
24 = Firebird Espirit 42 = GTO
26 = Firebird Formula 400 52 = Catalina & Ventura
28 = Trans Am 56 = Executive
33 = Standard Tempest 62 = Bonneville
35 = Custom "S" 76 = Grand Prix
37 = LeMans
Fourth & Fifth Symbol - Body Style
27 = two-door sedan 46 = station wagon three seat
35 = station wagon two seat single action tailgate 57 = two-door hardtop (Grand Prix)
36 = station wagon two seat dual action tailgate 67 = convertible
37 = two-door hardtop (exc. Firebird, Grand Prix) 69 = four-door sedan
39 = four-door hardtop 87 = two-door hardtop (Firebird)
Sixth Symbol - Last Digit Of The Model Year
0 = 1970
Seventh Symbol - Assembly Plant
(A) Atlanta, Georgia (P) Pontiac, Michigan
(B) Baltimore, Maryland (R) Arlington, Texas
(C) Southgate, California (X) Kansas City, Kansas
(E) Linden, New Jersey (Z) Fremont, California
(G) Framingham, Massachusetts (1) Oshawa, Ontario, Canada
(L) Van Nuys, California (2) St. Therese, Quebec, Canada
(N) Norwood, Ohio
Last Six Symbols - Production Sequence
Started at 100001

Transmission Codes

Transmission Location
Turbo Hydra-Matic 350 Stamped on servo cover on right side of transmission.
Turbo Hydra-Matic 400 On metal tag fastened to right side of transmission case & on some models on the left side of converter housing.
3-Speed Painted or stamped on the transmission case.
4-Speed Painted or stamped on the transmission case.
Plant and Type Designation Prefix Transmission Type
DC 3-Speed (column)
DE 3-Speed
DG 3-Speed
DG 4-Speed (close-ratio)
DJ 4-Speed (wide-ratio)
DP 4-Speed (close-ratio)
DL 4-Speed (close-ratio)
R3 3-Speed
R4 3-Speed
WB 4-Speed (wide-ratio)
JE Turbo Hydra-Matic 350
JF Turbo Hydra-Matic 350
JU Turbo Hydra-Matic 350
PA Turbo Hydra-Matic 400
PB Turbo Hydra-Matic 400
PC Turbo Hydra-Matic 400
PD Turbo Hydra-Matic 400
PF Turbo Hydra-Matic 400
PH Turbo Hydra-Matic 400
PR Turbo Hydra-Matic 400
PT Turbo Hydra-Matic 400
PW Turbo Hydra-Matic 400
PX Turbo Hydra-Matic 400
PY Turbo Hydra-Matic 400

Paint Codes - Exterior Colors

Color Name / Code Color Image Color Name / Code Color Image

10 - Polar White
Lucite® Code - 5040L
Dulux® Code - 5040D

48 - Pepper Green Metallic
Lucite® Code - 5116L
Dulux® Code - 5116D

14 - Palladium Silver Metallic
Lucite® Code - 5032L
Dulux® Code - 5032D

50 - Sierra Yellow
Lucite® Code - 5121L
Dulux® Code - 5121D

19 - Starlight Black
Lucite® Code - 99L
Dulux® Code - 93-005

53 - Coronado Gold Metallic
Lucite® Code - 5073LH
Dulux® Code - 5073D

25 - Bermuda Blue Metallic
Lucite® Code - 5123L
Dulux® Code - 5123D

55 - Baja Gold Metallic
Lucite® Code - 5120L
Dulux® Code - 5120D

26 - Lucerne Blue Metallic
Lucite® Code - 5190L
Dulux® Code - 5190D

58 - Granada Gold Metallic
Lucite® Code - 5117L
Dulux® Code - 5117D

28 - Atoll Blue Metallic
Lucite® Code - 5124L
Dulux® Code - 5124D

63 - Palomino Copper Metallic
Lucite® Code - 5125L
Dulux® Code - 5125D

34 - Mint Turquoise Metallic
Lucite® Code - 5119L
Dulux® Code - 5119D

67 - Castillian Bronze Metallic
Lucite® Code - 5076LH
Dulux® Code - 5076DH
43 - Keylime Green Metallic
Lucite® Code - 5126L
Dulux® Code - 5126D
75 - Cardinal Red
Lucite® Code - 5118LH
Dulux® Code - 5118DM
45 - Palisade Green Metallic
Lucite® Code - 5122L
Dulux® Code - 5122D
78 - Burgundy Metallic
Lucite® Code - 5063LH
Dulux® Code - 5063DH

47 - Verdoro Green Metallic
Lucite® Code - 5195L
Dulux® Code - 5195D


NOTES: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination 28-10 on a Pontiac would indicate the body finished in Atoll Blue Metallic and the roof area in Polar White.) General Motors paint code plate for all models is located on the "horizontal" or "vertical" surface of the shroud upper panel on the left side of the body.


Paint Codes - Interior Colors

Color Name / Code Color Image Color Name / Code Color Image

Ivory
Lucite® Code - 9715L (semi-gloss)

Dark Green Metallic
Lucite® Code - 9708LH (semi-gloss)
Lucite® Code - 9697LH (flat)

Medium Gold Metallic
Lucite® Code - 9707LH (semi-gloss)

Midnight Green Metallic
Lucite® Code - 9593LH (semi-gloss)
Lucite® Code - 9582LH (flat)

Dark Gold Metallic
Lucite® Code - 9698LH (flat)

Medium Bright Blue Metallic
Lucite® Code - 9540L (semi-gloss)
Lucite® Code - 9696L (flat)

Medium Sandlewood
Lucite® Code - 9716L (semi-gloss)

Medium Blue Metallic
Lucite® Code - 9711L (semi-gloss)

Dark Sandlewood
Lucite® Code - 9727L (semi-gloss)
Lucite® Code - 9704L (flat)

Dark Blue Metallic
Lucite® Code - 9712LH (semi-gloss)
Lucite® Code - 9701LH (flat

Medium Saddle
Lucite® Code - 9714L (semi-gloss)

Medium Red
Lucite® Code - 9709LH (semi-gloss)

Dark Saddle
Lucite® Code - 9703L (flat)

Dark Red
Lucite® Code - 9699LH (flat)

Dark Brown
Lucite® Code - 9713L (semi-gloss)
Lucite® Code - 9702L (flat)

Black
Lucite® Code - 4428L (semi-gloss)
Lucite® Code -

Lime Gold Metallic
Lucite® Code - 9718LH (semi-gloss)



NOTE: Unpolished LUCITE® will generally produce a gloss comparable to original interior semi-gloss finishes. If lower gloss is required, use 1/2 oz. DuPont #4528S flattening compound to a pint of unreduced color.

Trunk Colors (spatter finish)

Black - Gray - Aqua 389 - 259
