1969 Chevrolet C20
1969 Chevrolet Fleetside

1969 Chevrolet C20

Minor changes were made to the 1969 Chevrolet Pickups. A new grill featured the Chevrolet nameplate through the center while the bow tie logo moved to the front and center of the hood. C20 or K20 models could be equipped with either a 127 in with a 8-1/2 ft. cargo box. Also available was the Longhorn Pickup with 133 in wheelbase with a 8-1/2 ft. cargo box available in the Fleetside model. Standard engines included a 155 hp 250 6-cylinder.

Standard Features include:

Panoramic rear window, padded dash, heater/defroster, padded sun visors, low-profile control knobs, safety glass, painted front bumper (chrome bumpers were a separate option), 2-speed windshield wipers, windshield defrosters, low profile steering wheel, directional signals and more.

1969 Chevrolet Pickup Production Numbers

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
1/2 Ton Chevy Van - Model G - Series 100 - 90 in wheelbase
GS11005 - Panel $2,531 3,072 lbs 18,456
GS11006 - Sportvan $2,738 3,266 lbs 1,730
GS11026 - Custom Sportvan $2,863 3,375 lbs 526
GS11036 - Deluxe Sportvan $3,050 3,415 lbs 270
1/2 Ton Chevy Van - Model G - Series 200 - 108 in wheelbase
GS11005 - Panel $2,595 3,189 lbs 20,730
GS11006 - Sportvan $2,810 3,316 lbs 3,065
GS11026 - Custom Sportvan $2,935 3,439 lbs 2,598
GS11036 - Deluxe Sportvan $3,125 3,483 lbs 1,758
3/4 Ton Chevy Van - Model G - Series 20 - 108 in wheelbase
GS21305 - Panel $2,789 3,316 lbs 6,030
GS21306 - Sportvan $2,982 3,453 lbs 625
GS21326 - Custom Sportvan $3,107 3,586 lbs 382
GS21336 - Deluxe Sportvan $3,294 3,629 lbs 306
1/2 Ton - Model C - Series 10 - 115 in wheelbase
CE10703 - Chassis & Cab $2,383 3,116 lbs 2,343
CE10734 - Fleetside 6.5 ft. $2,532 3,531 lbs 54,211
CE10704 - Step-Side 6.5 ft. $2,494 3,450 lbs 49,147
1/2 Ton - Model C - Series 10 - 127 in wheelbase
CE10903 - Chassis & Cab $2,421 3,189 lbs 1,203
CE10934 - Fleetside 8 ft. $2,569 3,623 lbs 268,233
CE10904 - Step-Side 8 ft. $2,532 3,523 lbs 18,179
CE10905 - Panel $2,960 3,724 lbs 5,492
CE10906 - Suburban $3,194 3,815 lbs 14,056
1/2 Ton - Model K - Series 10 - 115 in wheelbase
KE10703 - Chassis & Cab $2,936 3,316 lbs 58
KE10734 - Fleetside 6.5 ft. $3,085 3,732 lbs 1,649
KE10704 - Step-Side 6.5 ft. $3,047 3,652 lbs 1,698
1/2 Ton - Model K - Series 10 - 127 in wheelbase
KE10903 - Chassis & Cab $2,973 3,522 lbs 35
KE10934 - Fleetside 8 ft. $3,123 3,836 lbs 4,937
KE10904 - Step-Side 8 ft. $3,085 3,512 lbs 521
KE10905 - Panel $3,513 3,935 lbs -
KE10906 - Suburban $3,749 4,024 lbs -
1/2 Ton Forward Control - Model P - Series 20 - 127 in wheelbase
PE10535 - Chassis - - 125
PE10535 - Step-Van $2,944 3,702 lbs 2,819
3/4 Ton - Model C - Series 20 - 127 in wheelbase
CE20903 - Chassis & Cab $2,614 3,506 lbs 8,440
CE20934 - Fleetside 8 ft. $2,762 4,013 lbs 74,894
CE20904 - Step-Side 8 ft. $2,724 3,907 lbs 8,090
CE20909 - Stake 8 ft. $2,832 4,138 lbs -
CE20905 - Panel $3,172 4,093 lbs 1,779
CE20906 - Suburban $3,447 4,199 lbs 2,736
Long Horn Pickup - Model C - Series 20 133 in wheelbase
CE21034 - Pickup 8.5 ft. $2,826 4,066 lbs 8,797
3/4 Ton - Model K - Series 20 - 127 in wheelbase
KE20903 - Chassis & Cab $3,054 3,590 lbs 498
KE20934 - Fleetside 8 ft. $3,201 4,030 lbs 4,705
KE20904 - Step-Side 8 ft. $3,163 3,940 lbs 1,047
KE20905 - Panel $3,534 4,111 lbs 68
KE20906 - Suburban $3,611 4,215 lbs 299
3/4 Ton Forward Control - Model P - Series 20 - 125 in wheelbase
PS20842 - Chassis $1,980 2,749 lbs 616
PS20835 - Steel Step-Van $3,819 5,175 lbs 1,843
PS20835 - Aluminum Step-Van - - 68
3/4 Ton Forward Control - Model P - Series 20 - 133 in wheelbase
PS21842 - Chassis $2,015 2,765 lbs 233
PS21835 - Step-Van $3,930 5,410 lbs 950
PS21835 - Aluminum Step-Van $4,900 4,760 lbs 79
1 Ton - Model C - Series 30 - 133 in wheelbase
CE31002 - Chassis & Cowl - - 236
CE31003 - Chassis & Cab $2,724 3,689 lbs 16,828
CE31034 - Fleetside 8.5 ft. $2,919 4,276 lbs 2,457
CE31004 - Step-Side 8.5 ft. $2,858 4,120 lbs 1,300
CE31009 - Stake 9 ft. $3,063 4,617 lbs -
1 Ton Forward Control - Model C - Series 30 - 157 in wheelbase
CE31103 - Chassis & Cab $2,839 4,066 lbs 8,290
1 Ton Forward Control - Model P - Series 30 - 125 in wheelbase
PS30842 - Chassis $2,140 2,968 lbs 3,447
PS30835 - King Step Van $3,900 5,394 lbs 855
PS30835 - Aluminum Step Van - - 46
PT30835 - Diesel Step Van $4,020 3,764 lbs 53*
PT30835 - King Diesel Step Van $5,775 6,170 lbs 53*
1 Ton Forward Control - Model P - Series 30 - 133 in wheelbase
PS31842 - Chassis $2,175 2,987 lbs 1,170
PS31843 - Chassis & Cowl - - 236
PS31835 - Steel Step Van $4,010 5,630 lbs 1,600
PS31835 - Aluminum Step Van - - 126
PT31042 - Chassis (Diesel) $4,050 3,784 lbs 53*
PT31035 - King Step Van $5,885 6,405 lbs 53*
1 Ton Forward Control - Model P - Series 30 - 157 in wheelbase
PE38842 - Chassis - - 1,607
PE38835 - Steel Step Van - - 924
PE38835 - Aluminum Step Van - - 86
* Combined Total Production of Diesel Powered Forward Control models was 53

Chassis Data

Model Wheelbase Overall Length Front Tread Rear Tread GVW Tires
G10 90 in - - - 3,900 - 5,000 lbs 6.95 x 14 in
C10/K10 115 in 186.75 in 63.1 in 61.1 in 4,400-5,000 / 5,600 lbs 8.15 x 15 in / 17.5 x 17 four-ply
C10/K10 127 in 206.25 in 63.1 in 61.1 in 4,400-5,000 / 5,600 lbs 7.75 x 15 in. four-ply / 17.5 x 17
P10 102 in - - - 4,600 - 5,400 lbs 7.75 x 15 in
C20/K20 127 in 206.25 - - 5,500-7,500 / 5,700-7,600 lbs 7.75 x 15 in / 17.5 x 17 six-ply
P20 104 / 125 / 137 in - - - 7,000 lbs 7 x 17.5 in
C30 133 in - - - 6,700 - 14,000 lbs 8 x 17.5 in
P30 104 / 125 / 137 in - - - 7,500 - 14,000 lbs 8 x 19.5 in



Vin Number Decoding - 1969 Chevrolet Pickup

Location: On plate attached to the rear face of left-hand door hinge pillar and on right side of cowl under hood.

First Symbol - Type
C = Conventional Cab G = Chevy Van
K = 4x4 P = Forward Control
Second Symbol - Type of Engine
S = Six T = Diesel
E = Eight
Third Symbol - Gross Volume Weight (GVW)
1 = 3,600 - 5,600 lbs 2 = 5,500 - 8,100 lbs 3 = 6,700 - 10,000 lbs 4 = Over 10,000 lbs
Fourth & Fifth Symbol - Cab to Axle Dimension
07 = 42-47 in. 09 = 54-59 in. 10 = 60-65 in. 14 = 84-89 in.
Sixth & Seventh Symbol - Body Type
02 = Chassis & Cowl 09 = Platform/Stake 26 = Custom Sportvan
03 = Chassis & Cab 12 = Chassis & Cowl 34 = Fleetside
04 = Step-Side Pickup 13 = Cab with Air Brakes 35 = Forward Control
05 = Panel or Panel Van 14 = Blazer 36 = Deluxe Sportvan
06 = Suburban (doors) or Sportvan 16 = Suburban (gate)
Eighth Symbol - Production Year
9 = 1969
Ninth Symbol - Assembly Plant
A = Atlanta, GA. J = Janesville, WI. T - Tarrytown, NY.
B = Baltimore, MD. K - Kansas City, MO. Z = Fremont, CA.
F = Flint, MI. S = St. Louis, MO. 1 = Oshawa, Canada
