1966 Chevrolet C10
The 1966 Chevrolet C10

1966 Chevrolet C10

Styling features remained the same as the previous year for the 1966 Chevy Pickup trucks and Chevrolet mus have been doing something right, because in 1966, Chevrolet reached the 10 millionth mark in truck sales of all time.

Standard Features include:

2-Speed windshield wipers, backup lamps, seat belts, and dual long arm mirrors.

Additional options:

Oil bath air cleaner, Heavy-duty battery, Two-Chrome Bumpers, 42-amp & 52-amp Delcotron alternators, Radio, Foam seat, Heavy-Duty front and rear shocks, 2-speed windshield wipers, deluxe heater, thrift-air heater, tinted windshield and more.

1966 Chevrolet Pickup Production Numbers

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
Chevy Van - Model G - Series 10 - 90 in wheelbase
G1205 - Panel $2,141 2,755 lbs 28,180
G1206 - Sportvan $2,388 2,965 lbs 4,209
G1226 - Custom Sportvan $2,521 3,065 lbs 2,674
G1236 - Deluxe Sportvan $2,747 3,125 lbs 2,341
1/2 Ton - Model C14 - Series 10 - 115 in wheelbase
C1403 - Chassis & Cab $1,927 2,835 lbs 40
C1434 - Fleetside $2,066 3,220 lbs 57,386
C1404 - Step-Side $2,050 3,195 lbs 59,947
C1405 - Panel 7.5 ft. $2,361 3,420 lbs -
C1406 - Suburban (door) $2,598 3,710 lbs 6,717
C1416 - Suburban (gate) $2,629 3,735 lbs 5,334
1/2 Ton - Model K14 - Series 10 - 115 in wheelbase
K1434 - Fleetside $2,718 3,825 lbs 678
K1404 - Step-Side $2,702 3,810 lbs 1,123
K1405 - Panel 7.5 ft. $3,013 4,085 lbs 170
K1406 - Suburban (door) $3,270 4,385 lbs 530
K1416 - Suburban (gate) $3,303 4,415 lbs 418
1/2 Ton - Model C15 (Longbed)- Series 10 - 127 in wheelbase
C1503 - Chassis & Cab - - 1,155
C1534 - Fleetside $2,104 3,845 lbs 178,752
C1504 - Step-Side $2,087 3,290 lbs 26,456
1/2 Ton Dubl Duti - Model P - Series 10 - 102 in wheelbase
P1345 - Step Van $2,658 3,480 lbs 3,202
3/4 Ton - Model C25 - Series 20 - 127 in wheelbase
C2503 - Chassis & Cab $2,112 3,265 lbs 6,520
C2534 - Fleetside $2,252 3,700 lbs 55,855
C2504 - Step-Side $2,236 3,700 lbs 9,905
C2509 - Stake $2,328 3,890 lbs 1,499
3/4 Ton - Model K25 - Series 20 - 127 in wheelbase
K2503 - Chassis & Cab - - -
K2534 - Fleetside $2,904 4,270 lbs 1,796
K2504 - Step-Side $2,888 4,225 lbs 924
3/4 Ton Dubl Duti - Model P - Series 20 - 104-137 in wheelbase
P2345 - Step Van $3,432 4,835 lbs 192
1 Ton - Model C36 - Series 30 - 133 in wheelbase
23603 - Chassis & Cab $2,269 3,455 lbs 11,852
C3604 - Fleetside $2,414 3,930 lbs 3,646
C3609 - Stake 9 ft. $2,527 4,285 lbs 3,651
C3605 - Panel 10.5 ft. $2,832 4,265 lbs 3,560
1 Ton - Model P - Series 30 - 104-137 in wheelbase
P3345 - Step Van $3,432 5,040 lbs 61

Chassis Data

Model Wheelbase Overall Length Front Tread Rear Tread GVW Tires
G10 90 in - - - 3,900 - 5,000 lbs 6.50 x 13 in
C10-C14/K10-K14 115 in 186.75 in 63.1 in 61.1 in 4,400-5,000 / 5,600 lbs 7.75 x 15 in / 17.5 x 17 four-ply
C10-C15/K10-K15 127 in 206.25 in 63.1 in 61.1 in 4,400-5,000 / 5,600 lbs 7.75 x 15 in. four-ply / 17.5 x 17
P10 102 in - - - 4,600 - 5,400 lbs 7.75 x 15 in
C20/K20 127 in 206.25 - - 5,500-7,500 / 5,700-7,600 lbs 7 x 17.5 in / 7 x 17.5 six-ply
P20 104 / 125 / 137 in - - - 7,000 lbs 7 x 17.5 in
C30 133 in - - - 6,700 - 14,000 lbs 8 x 17.5 in
P30 104 / 125 / 137 in - - - 7,500 - 14,000 lbs 8 x 19.5 in



Vin Number Decoding - 1966 Chevrolet Pickup

Location: On plate attached to the rear face of left-hand door hinge pillar and on right side of cowl under hood.

First Symbol - Type
C = Conventional Cab G = Chevy Van
K = 4x4 P = Forward Control Package Delivery
Second Symbol - Type of Engine
S = Six T = Diesel
E = Eight
Third Symbol - Gross Volume Weight (GVW)
1 = 3,600 - 5,600 lbs 2 = 5,500 - 8,100 lbs 3 = 6,700 - 10,000 lbs 4 = Over 10,000 lbs
Fourth Symbol - Body Style
2 = Chassis & Cowls 4 = Pickup 6 = Suburban Carryall
3 = Chassis & Cab 5 = Panel 9 = Platform/Stake
Fifth Symbol - Assembly Plant
A = Atlanta, GA. K - Kansas City, MO. S = St. Louis, MO.
B = Baltimore, MD. L = Los Angeles, CA. T - Tarrytown, NY.
F = Flint, MI. N = Norwood, OH. W = Willow Run, MI.
G = Framingham, MA. O = Oakland, CA.
J = Janesville, WI. P = Pontiac, MI.
Final Symbols - Production Sequence
Sequential production order of each plant starting with 100001

1966 Chevrolet Truck Advertisements


Photo Gallery - 3 Pictures

click on a thumbnail below for a larger view




Top of page
