1965 Ford Fairlane
1965 Ford Fairlane Four-Door

1965 Ford Fairlane

The 1965 Fairlane was new in its appearance as well as its design. It had a wider, more immense big car look which contributed to its new features including increased luggage capacity, new sound insulation package, and much more to offer the ultimate in comfort and convenience.

When you change your appearance, why not change your mechanics. The new 120 hp Fairlane Six replaced the former 170-CID Six became the new standard Fairlane engine with a seven-main-bearing crankshaft and automatic choke. Among the optional V8 engines, the 289-CID Challenger replaced the 260 cu. in V8 from the previous year and features a higher compression ratio of 9.3 to 1 while the Challenger High Performance comes complete with a chrome dress up kit and 4-speed manual transmission. When it comes to transmissions, the Cruise-O-Matic replaced the Fordomatic as Fairlane's optional automatic transmission offering better gas mileage to the thrifty driver.

1965 Ford Fairlane Specifications

Model Number Body/Style Number Body Type & Seating Factory Price Shipping Weight Total Production
Fairlane Six-Cyl Series
T 54A 4 Dr Sedan $2,223 2,858 lbs 25,376*
T 62A 2 Dr Sedan $2,183 2,806 lbs 13,685*
T 71D 4 Dr Station Wagon $2,512 3,183 lbs 13,911*
Fairlane V-8 Series
N/A 54A 4 Dr Sedan $2,329 3,055 lbs 25,376*
N/A 62A 2 Dr Sedan $2,288 2,998 lbs 13,685*
N/A 71D 4 Dr Station Wagon $2,618 3,375 lbs 13,911*
Fairlane 500 Six-Cyl Series
T 54B 4 Dr Sedan $2,303 2,863 lbs 77,836**
T 62B 2 Dr Sedan $2,263 2,806 lbs 16,092**
T 65A 2 Dr Hardtop $2,327 2,877 lbs 41,405**
T 65B 2 Dr Sport Coupe $2,484 2,888 lbs 15,141**
T 71B 4 Dr Station Wagon $2,592 3,220 lbs 20,506**
Fairlane 500 V8 Series
N/A 54B 4 Dr Sedan $2,829 3,975 lbs 77,836**
N/A 62B 2 Dr Sedan $2,933 3,985 lbs 16,092**
N/A 65A 2 Dr Hardtop $3,018 3,990 lbs 41,405**
N/A 65B 2 Dr Sport Coupe $3,088 4,000 lbs 15,141**
N/A 71B 4 Dr Station Wagon $3,088 4,000 lbs 20,506**

Notes:

* Total Series production for ALL Fairlane's was 52,974 units both 6-cylinder and V8. Ford does not have individual breakdowns per body style.
** Total Series production for ALL Fairlane 500's was 170,980 units both 6-cylinder and V8. Ford does not have individual breakdowns per body style.

Chassis Data

Model Number Wheelbase Overall Length Front Tread Rear Tread Tire Size
Fairlane 116 in 198.4 in 57 in 56 in 6.94 x 14
Fairlane Station Wagon 116 in 203.2 in 57 in 56 in 7.35 x 14

Vin Number Decoding - 1960 - 1969 Ford (All Models)

Location: stamped on top upper flange of left front fender apron. Located on top of dash visible through windshield. On lock face of left front door.

First Symbol - Year
0 = 1960 1 = 1961 2 = 1962 3 = 1963 4 = 1964 5 = 1965 6 = 1966 7 = 1967 8 = 1968 9 = 1969
Second Symbol - Assembly Plant
A = Atlanta L = Michigan Truck
B = Oakville N = Norfolk
C = Ontario P = Twin Cities
D = Dallas R = San Jose
E = Mahwah S = Pilot Plant
F = Dearborn T = Metuchen
G = Chicago U = Louisville
H = Lorain W = Wayne
J = Los Angeles Y = Wixom
K = Kansas City Z = St. Louis
Third & Fourth Symbol - Body Series
01 = Mustang 2 Dr Hardtop 51 = Ford 4 Dr Sedan (Custom)
02 = Mustang 2 Dr Fastback 52 = Ford 2 Dr Sedan (Custom 500)
03 = Mustang 2 Dr Convertible 53 = Ford 4 Dr Sedan (Custom 500)
10 = Falcon 2 Dr Sedan 54 = Ford 4 Dr Sedan (Galaxie 500)
11 = Falcon 4 Dr Sedan 55 = Ford 2 Dr Fastback (Galaxie 500)
12 = Falcon Station Wagon 56 = Ford 4 Dr Hardtop (Galaxie 500)
20 = Falcon 2 Dr Sedan (Futura) 57 = Ford Convertible (Galaxie 500)
21 = Falcon 4 Dr Sedan (Futura) 58 = Ford 2 Dr Hardtop (Galaxie 500)
22 = Falcon 2 Dr Sedan (Bucket Seats) 60 = Ford 2 Dr Fastback (XL)
23 = Falcon Station Wagon (Futura) 61 = Ford Convertible (XL)
30 = Fairlane 2 Dr Hardtop 62 = Ford 2 Dr Hardtop (LTD)
31 = Fairlane 4 Dr Sedan 63 = Ford 2 Dr Fastback Coupe
32 = Fairlane Station Wagon 64 = Ford 4 Dr Sedan (LTD)
33 = Fairlane 2 Dr Hardtop (500) 65 = Ford 2 Dr Hardtop Coupe
34 = Fairlane 4 Dr Sedan (500) 66 = Ford 4 Dr Hardtop (LTD)
35 = Fairlane 2 Dr Fastback (500) 70 = Ford Station Wagon (Ranch Wagon - 6P)
36 = Fairlane Convertible (500) 71 = Ford Station Wagon (Custom 500 Ranch Wagon - 6P)
37 = Fairlane Station Wagon (500) 72 = Ford Station Wagon (Custom 500 Ranch Wagon - 10P)
38 = Fairlane Station Wagon (Squire) 73 = Ford Station Wagon (Country Squire - 6P)
40 = Fairlane 2 Dr Fastback (500 XL) 74 = Ford Station Wagon (Country Sedan - 10P)
41 = Fairlane Convertible (500 XL) 75 = Ford Station Wagon (Country Squire -6P)
42 = Fairlane 2 Dr Fastback (500 GT) 76 = Ford Station Wagon (Country Squire -10P)
43 = Fairlane Convertible (500 GT) 76 = Fairlane Convertible
47 = Fairlane Ranchero 83 = Thunderbird 2 Dr Hardtop
48 = Fairlane Ranchero (500) 84 = Thunderbird 2 Dr Hardtop (Landau)
49 = Fairlane Ranchero (GT) 87 = Thunderbird 4 Dr Hardtop (Landau)
Fifth Symbol - Engine
A = 8-289 Q = 8-427
B = 6-240 R = 8-427
C = 8-289 S = 8-390
E = 6-240 T = 6-200
F = 8-260 U = 6-170
J = 8-302 V = 6-240
K = 8-289 W = 8-427
L = 8-221 X = 8-352
M = 8-390 Y = 8-390
N = 8-429 Z = 8-390
P = 8-428
Last Six Symbols - Production Sequence
Starting at 100001
Code Transmission Type
1 3-Speed Manual
5 4-Speed Manual (std. ratio) 2.78 1st.
6 4-Speed Manual (opt. ratio) 2.32 1st.
T Cruise-O-Matic (FMX-L)
U C6 Automatic (aluminum 1 piece case)
W C4 Automatic (aluminum 2 piece case)
X Cruise-O-Matic (C.I. case)
Y Cruise-O-Matic(C.I. case)
Z C6 Automatic Special (aluminum 1 piece case)

Engine Data


Engines Displacement Horsepower Torque Transmission Carburetor
Fairlane Six 6-200 120 190 3-speed Manual, Cruise-O-Matic 1-V
Challenger 8-289 200 282 3-speed manual, Overdrive, Cruise-O-Matic 2-V
Challenger Special 8-289 225 305 3-speed manual, 4-speed manual, Cruise-O-Matic 2 BC
Challenger High Performance 8-289 271 312 4-speed manual, Cruise-O-Matic 4 BC

Transmission Codes

Transmission Location
3-Speed Manual Not Available
4-Speed Manual Not Available
Overdrive Not Available
Cruise-O-Matic (C.I. case) Not Available
Cruise-O-Matic (aluminum case) Not Available
Code Transmission Type
1 3-Speed Manual
2 Overdrive
4 Cruise-O-Matic (C.I. case)
5 4-Speed Manual
6 Cruise-O-Matic (aluminum case)

1965 Ford Axle Codes



Codes - Non-Locking Codes - Locking Ratio
1 A 3.00
2 B 2.83
2 B 3.10
3 C 3.20
4 D 3.25
5 E 3.50
6 F 2.80
7 G 3.80
8 H 3.89
9 I 4.00 (Falcon)
9 I 4.11

Paint Codes - Exterior Colors

Color Name / Code Color Image Color Name / Code Color Image

A - Raven Black
Lucite® Code - 88
Duco® Code - 44
Dulux® Code - 93-005

Q - Brittany Blue (Thunderbird only)
Lucite® Code - 4485L
Duco® Code - 4485
Dulux® Code - 181-96928

B - Midnight Turquoise (Thunderbird only)
Lucite® Code - 4284L
Duco® Code - 4284H
Dulux® Code - 181-95606

R - Ivy Green
Lucite® Code - 4611L
Duco® Code - 4611
Dulux® Code - 181-97327
C - Honey Gold
Lucite® Code - 4612L
Duco® Code - 4612
Dulux® Code - 181-97328H
S - Charcoal Gray (Thunderbird only)
Lucite® Code - 4618L
Duco® Code - 4618
Dulux® Code - 181-97334
D - Dynasty Green
Lucite® Code - 4486L
Duco® Code - 4486
Dulux® Code - 181-96929

T - Navajo Beige (Thunderbird only)
Lucite® Code - 4489L
Duco® Code - 4489
Dulux® Code - 93-96932

E - Silver Mink (Thunderbird only)
Lucite® Code - 4280
Duco® Code - 4280
Dulux® Code - 181-95602

U - Patrician Green (Thunderbird only)
Lucite® Code - 4297L
Duco® Code - 4297
Dulux® Code - 181-17008

F - Arcadian Blue (Thunderbird only)
Lucite® Code - 4070L
Duco® Code - 4070
Dulux® Code - 93-94122

V - Emberglo (Thunderbird only)
Lucite® Code - 4700LH
Duco® Code - 4700H
Dulux® Code - 181-97770H

G - Pastel Yellow (Thunderbird only)
Lucite® Code - 4617L
Duco® Code - 4617L
Dulux® Code - 93-97333
W - Rose Beige #2 (Thunderbird only)
Lucite® Code - 4498L
Duco® Code - 4498
Dulux® Code - 181-96942

H - Caspian Blue #2
L Lucite® Code - 4693L
Duco® Code - 4693
Dulux® Code - 181-97568

X - Vintage Burgundy
Lucite® Code - 4490LM
Duco® Code - 4490H
Dulux® Code - 181-96933H

I - Champagne Beige
Lucite® Code - 4613L
Duco® Code - 4613
Dulux® Code - 181-97329

Y - Silver Blue
Lucite® Code - 4692L
Duco® Code - 4692
Dulux® Code - 181-97547

J - Rangoon Red
Lucite® Code - 4294LM
Duco® Code - 4294H
Dulux® Code - 93-95616H

Z - Chantilly Beige (Thunderbird only)
Lucite® Code - 4488L
Duco® Code - 4488
Dulux® Code - 181-96931

K - Silver Smoke Gray
Lucite® Code - 4482L
Duco® Code - 4482
Dulux® Code - 181-96925

3 - Poppy Red (Mustang only)
Lucite® Code - 4602LH
Duco® Code - 4602H
Dulux® Code - 93-97249H
M - Wimbledon White
Lucite® Code - 4480L
Duco® Code - 4480
Dulux® Code - 93-96923
4 - Frost Turquoise (Thunderbird only)
Lucite® Code - 4610L
Duco® Code - 4610
Dulux® Code - 93-97326
N - Diamond Blue (Thunderbird only)
Lucite® Code - 2770L
Duco® Code - 2770
Dulux® Code - 93-830203H
5 - Twilight Turquoise
Lucite® Code - 4607L
Duco® Code - 4607
Dulux® Code - 181-97323
O - Tropical Turquoise
Lucite® Code - 4608L
Duco® Code - 4608
Dulux® Code - 93-97324
7 - Phoenician Yellow
Lucite® Code - 4491LH
Duco® Code - 4491
Dulux® Code - 93-96934
P - Prairie Bronze
Lucite® Code - 4603L
Duco® Code - 4603
Dulux® Code - 181-97250
8 - Springtime Yellow
Lucite® Code - 4699L
Duco® Code - 4699
Dulux® Code - 93-97769
NOTE: The first letter of a two-letter paint code identifies the body color. The second letter identifies the roof color. (For example, the combination YM on a Ford would indicate the body finished in Silver Blue and the roof area in Wimbledon White.) Paint code for all models are shown on the plate on the rear face of the left front door.


Paint Codes - Interior Colors

Color Name / Code Color Image Color Name / Code Color Image

White
Lucite® Code - 9138L (semi-gloss)

Medium Green
Lucite® Code - 9093LH (semi-gloss)

Light Beige (Thunderbird only)
Lucite® Code - 9145L (semi-gloss)

Light Aqua (Thunderbird only)
Lucite® Code - 9144LH (semi-gloss)

Medium Beige
Lucite® Code - 9051LH (semi-gloss)

Light Turquoise
Lucite® Code - 9149LH (semi-gloss)

Medium Beige (Thunderbird only)
Lucite® Code - 9156L (semi-gloss)

Medium Aqua (Thunderbird only)
Lucite® Code - 9154LH (semi-gloss)

Dark Beige (Thunderbird only)
Lucite® Code - 9155L (semi-gloss)

Medium Turquoise
Lucite® Code - 9148LH (semi-gloss)

Light Palomino
Lucite® Code - 9134L (semi-gloss)

Dark Aqua
Lucite® Code - 9153LH (semi-gloss)
Medium Palomino
Lucite® Code - 9137LH (semi-gloss)
Light Blue (Thunderbird only)
Lucite® Code - 9140LH (semi-gloss)
Light Silver Mink (Thunderbird only)
Lucite® Code - 9143LH (semi-gloss)
Light Blue
Lucite® Code - 9147LH (semi-gloss)
Medium Silver Mink (Thunderbird only)
Lucite® Code - 9151LH (semi-gloss)
Medium Blue
Lucite® Code - 9135LH (semi-gloss)
Dark Silver Mink (Thunderbird only)
Lucite® Code - 9150LH (semi-gloss)
Medium Blue (Thunderbird only)
Lucite® Code - 9139LM (semi-gloss)
Light Ivy Gold (Thunderbird only)
Lucite® Code - 9142LH (semi-gloss)

Dark Blue (Thunderbird only)
Lucite® Code - 9152LH (semi-gloss)

Light Ivy Gold
Lucite® Code - 9133LH (semi-gloss)
Red
Lucite® Code - 9091LM (semi-gloss)

Medium Ivy Gold (Thunderbird only)
Lucite® Code - 9141LH (semi-gloss)

Dark Red (Thunderbird only)
Lucite® Code - 9146LM (semi-gloss)

Medium Ivy Gold
Lucite® Code - 9136LH (semi-gloss)

Burgundy
Lucite® Code - 9041LH (semi-gloss)

Dark Ivy Gold (Thunderbird only)
Lucite® Code - 9132LH (semi-gloss)

Black
Lucite® Code - 88 (semi-gloss)

NOTE: To obtain a gloss comparable to the original interior finish add approximately 1 oz DuPont #4528 flattening compound to a pint of unreduced color.


Trunk Colors (spatter finish)

Turquoise 389-262
