| 1963 Oldsmobile Super 88 |
| |
| |
| General Information |
|
|
1963 OLDSMOBILE SUPER 88 - SPECIFICATIONS
SUPER 88 -GENERAL: Wheelbase, 123" • Overall length, 214.4" • Overall width, 77.9" • Tread, 62.2" (front); 61.0" (rear) • Overall height (5-passenger load), Celebrity Sedan 56.3" • Shipping weight (Celebrity Sedan, approx.), 4032 lbs .• ENGINE: Skyrocket, ultra high-compression V-8 • Horsepower, 330 at 4600 R.P.M .• Torque, 440 lb.-ft. at 2800 R.P.M .• Displacement, 394 cubic inches· Compression Ratio, 10.25-to-l • Fuel tank capacity, 21 gallons. Fuel required, premium. CHASSIS: Brakes, self-adjusting; 191.7 square inches lining area· Frame, Guard-Beam with torque-box construction· Front Suspension, coil spring; Pivot-Poise with counter dive· Rear Suspension, coil spring, 4-Link Twin-Triangle Stability. Turning diameter, 42.8 feet. Rear axle, 2.87-to-1 ratio (1963 Hydra-Matic); semi-floating; hypoid gears • STANDARD EQUIPMENT: De Luxe Steering Wheel, Safety- Padded Instrument Panel, Parking Brake Signal Lamp, Front Compartment Courtesy Lamps, Custom Luxury Trim, Two-Speed Electric Windshield Wipers, 8.00 x 14-inch tires. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
TURBO-ROCKET
Standard on Jetfire only... Turbocharged, fluid-injected. Aluminum V-8 construction, 10.25-to-1 compression ratio, 215hp, 215 cubic inch displacement, 300lb. ft. torque. Operates on premium gasoline.
|
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
ROCKETTE
Standard on F-85. 155hp, 8.75-to-1 compression ratio, 215cu. in. displacement. Cutlass 195 engine standard Hydra-Matic-equipped Cutlass, optional on other F-85's equipped with Hydra-Matic. Cutlass 185 standard on Cutlass, optional on other F-85's equipped with synchromesh transmission.
|
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
ROCKET
High-compression 280hp V8- standard on Dynamic 88, 430lb. ft. torque, 10.25-to-1 compression ratio, 2-barrel carburetor, 394 cu. in. displacement, operates on premium fuel. Regular-gas 260-hp. Rocket optional at no extra cost on all Dynamic 88's. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
SKYROCKET
Standard on Ninety-Eight and Super 88. 330 hp 394 cu. displacement, 440lb ft. of torque, 10.25-to-1 compression ratio, 4-barrel carburetor. Optional on Dynamic 88 models. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
STARFIRE
Standard on Starfire models and Ninety-Eight Custom Sports Coupe! Fire-Swirl combustion chamber, power-peak camshaft, 10.5-to1 comp, ratio, 345 h.p., 440lb.-ft. torque, 394-cubic-inch displacement.
|
|
|
|
| |
|
|
|
|
|
|
| |
