| 1963 Oldsmobile Jetfire |
| |
|
1963 OLDSMOBILE JETFIRE - SPECIFICATIONS
JETFIRE-GENERAL: Wheelbase, 112" • Overall length, 192.2" • Overall width, 73.7"• Tread, 56.0" (front and rear) • Overall height, 52.3" • Shipping weight, 2618 lbs .• ENGINE: Turbo-Rocket V-8 • Fluid injection with turbocharger. Horsepower, 215 at 4800 R.P.M .• Torque 300 lb.-ft. at 3200 R.P.M .• Displacement, 215 cubic inches· Ultra high-compression, 10.25-to-1 ratio· Performance-tailored pistons, connecting rods, main bearings, distributor, fuel pump and coil· Fuel capacity, 16 gallans • Fuel required, premium .• CHASSIS: Frame, frame-integral with body. Suspension, 4-coil; front-Cross-member rubber insulated; Rear-4-Link Twin-Triangle Stability; Rubber isolation· Brakes, self-adjusting; 130 square inches brake lining area· Turning diameter, 37 feet· Rear axle, 3.36-to-1 ratio· STANDARD EQUIPMENT: Bucket Seats, Sport Console, Windshield Washer, Dual-outlet Exhausts, De Luxe Steering Wheel, Safety-Padded Instrument Panel.
|
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
TURBO-ROCKET
Standard on Jetfire only... Turbocharged, fluid-injected. Aluminum V-8 construction, 10.25-to-1 compression ratio, 215hp, 215 cubic inch displacement, 300lb. ft. torque. Operates on premium gasoline.
|
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
ROCKETTE
Standard on F-85. 155hp, 8.75-to-1 compression ratio, 215cu. in. displacement. Cutlass 195 engine standard Hydra-Matic-equipped Cutlass, optional on other F-85's equipped with Hydra-Matic. Cutlass 185 standard on Cutlass, optional on other F-85's equipped with synchromesh transmission.
|
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
ROCKET
High-compression 280hp V8- standard on Dynamic 88, 430lb. ft. torque, 10.25-to-1 compression ratio, 2-barrel carburetor, 394 cu. in. displacement, operates on premium fuel. Regular-gas 260-hp. Rocket optional at no extra cost on all Dynamic 88's. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
SKYROCKET
Standard on Ninety-Eight and Super 88. 330 hp 394 cu. displacement, 440lb ft. of torque, 10.25-to-1 compression ratio, 4-barrel carburetor. Optional on Dynamic 88 models. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
STARFIRE
Standard on Starfire models and Ninety-Eight Custom Sports Coupe! Fire-Swirl combustion chamber, power-peak camshaft, 10.5-to1 comp, ratio, 345 h.p., 440lb.-ft. torque, 394-cubic-inch displacement.
|
|
|
|
| |
|
Here is a car as unique in styling as it is in performance-JETFIRE by Oldsmobile! Hardtop flair ... and a sleek aluminum spear accentuate JETFIRE'S low, racy silhouette. But the big news is under the hood: A fluid-injected, turbocharged aluminum engine-Oldsmobile's 215-h.p. Turbo-Rocket V-8! It develops one horsepower for every cubic inch of displacement! Aluminized muffler ... dual outlet exhausts ... high-torque 3.36-to-1 axle ratio ... sporty front compartment console are all included as standard equipment. Foam-padded bucket seats-also standard-are available in your choice of five stylish solid colors including all-black and all-white. Stick-operated 1963 Hydra-Matic Drive, or floor-mounted 4-speed fully-synchronized manual transmission for the sports car buff ... both are optional at extra cost. Make no mistake, JETFIRE is the ultimate in motoring excitement ... an exclusive from Oldsmobile!
POWER WHEN YOU NEED IT ... ECONOMY WHEN YOU WANT IT!
The heart of JETFIRE's high-compression Turbo-Rocket Engine is the turbocharger with fluid injection! Waste exhaust gases actually put power back into the engine by turning turbine blades (A) at speeds up to 90,000 rpm! The turbine drives the compressor (B) forcing additional air-fuel mixture into the cylinders. During turbo charging, Turbo- Rocket Fluid (C) is injected into the gas mixture to permit ultra-high compression for greatest efficiency. This turbo-charging action increases power by almost 40%. |
|
|
|
| |
| Advertisement for a 1963 Oldsmobile Jetfire |
| |
| Click for larger Picture |
 | |
|
First of it's kind . . .
and full of suprises . . . fluid-injected, turbocharged aluminum V-8.
The heart of the Jetfire is the Turbo-Rocket V-8. The Turbine puts power back into the engine by turning the compressor. Turbo-Rocket Fluid is injected to permit higher compression. Result: 215 h.p. from 215-cu.-in. displacement. |
|
|
|
| |
| |
| Production Data |
|
| 1963 Oldsmobile Jetfire Production |
| In 1963 Production of the Oldsmobile Jetfire was 5,842 and was the most expensive F-85 series car with base price of about $3,048. |
|
|
|
| |
|
|
|
|
|
|
| |
|
|
|
|
| |
|
|
| |
|
|
