| Decoding Information |
|
| 1962 Pontiac Color Codes |
| A - Starlight Black |
C - Cameo Ivory |
D - Silvermist Gray |
| E - Ensign Blue |
F - Yorktown Blue |
H - Kimberly Blue |
| J - Silverleaf Green |
L - Belmar Red |
M - Bamboo Cream |
| N - Burgundy |
P - Aquamarine |
Q - Seafoam Aqua |
| R - Yuma Beige |
T - Caravan Gold |
V - Mandalay Red | |
|
|
|
| |
| |
| Engine Data |
|
| 1962 Pontiac Engine Production Chart |
| H.P. |
DISP. |
DESC. |
TRANS. |
CARB. |
CODE |
QTY. |
| 110 |
195 |
Std. Engine |
M |
1 Bbl. |
89Z |
19405 |
| 110 |
195 |
Taxi |
M |
1 Bbl. |
85Z |
31 |
| 110 |
195 |
Export |
M |
1 Bbl. |
88Z |
151 |
| 115 |
195 |
Std. Engine |
A |
1 Bbl. |
79Y |
93228 |
| 115 |
195 |
Export |
A |
1 Bbl. |
78Y |
260 |
| 120 |
195 |
Spec. Equip. |
M |
1 Bbl. |
86Z |
1749 |
| 120 |
195 |
Trailer Option |
M |
1 Bbl. |
83Z |
25 |
| 140 |
195 |
Spec. Equip. |
A |
1 Bbl. |
76Y |
9275 |
| 166 |
195 |
Spec. Equip. |
M |
4 Bbl. |
87Z |
7187 |
| 166 |
195 |
Trailer Option |
M |
4 Bbl. |
84Z |
350 |
| 166 |
195 |
Std. Engine |
A |
4 Bbl. |
77Y |
9914 |
| 185 |
215 |
Spec. Equip. Buick V8 |
M |
4 Bbl. |
91Z |
90 |
| 185 |
215 |
Export Buick V8 |
A |
4 Bbl. |
96Y |
103 |
| 185 |
215 |
Spec. Equip. Buick V8 |
A |
4 Bbl. |
97Y |
813 |
| 215 |
389 |
Std. Engine |
M |
2 Bbl. |
01A |
7822 |
| 215 |
389 |
H.D. Clutch |
M |
2 Bbl. |
03B |
191 |
| 230 |
389 |
Std. Engine - 425E |
A |
2 Bbl. |
20L |
28312 |
| 230 |
389 |
A/Cond. - 425E |
A |
2 Bbl. |
21L |
1522 |
| 230 |
389 |
26-27-28 - 425E |
A |
2 Bbl. |
40R |
2499 |
| 230 |
389 |
26-27-28 - A/Cond. |
A |
2 Bbl. |
41R |
412 |
| 235 |
389 |
Std. Engine |
M |
4 Bbl. |
02B |
2179 |
| 235 |
389 |
H.D. Clutch |
M |
4 Bbl. |
04B |
504 |
| 240 |
389 |
Export |
A |
2 Bbl. |
23H |
188 |
| 240 |
389 |
Export |
M |
2 Bbl. |
05A |
51 |
| 257 |
389 |
Export |
A |
2 Bbl. |
44M |
18 |
| 267 |
389 |
Std. Engine |
A |
2 Bbl. |
15H |
132531 |
| 267 |
389 |
Std. Engine - A/Cond. |
A |
2 Bbl. |
17H |
23557 |
| 276 |
389 |
Export |
A |
4 Bbl. |
45P |
93 |
| 283 |
389 |
Taxi & Police |
A |
2 Bbl. |
35M |
25653 |
| 283 |
389 |
26 Series - A/Cond. |
A |
2 Bbl. |
37M |
12299 |
| 303 |
389 |
Std. Engine & Police |
M |
4 Bbl. |
06B |
2698 |
| 303 |
389 |
Std. Engine |
A |
4 Bbl. |
16K |
21572 |
| 303 |
389 |
23-29 Series - A/Cond. |
A |
4 Bbl. |
18K |
7491 |
| 303 |
389 |
27-28 Series - Std. Engine |
A |
4 Bbl. |
36P |
70070 |
| 303 |
389 |
27-28 Series - A/Cond. |
A |
4 Bbl. |
38P |
26523 |
| 303 |
389 |
Police |
A |
4 Bbl. |
39N |
180 |
| 318 |
389 |
Spec. Equip. |
M |
3-2 Bbl. |
10B |
2656 |
| 318 |
389 |
Spec. Equip. |
A |
3-2 Bbl. |
27J |
2023 |
| 318 |
389 |
26-27-28 Spec. Equip. |
A |
3-2 Bbl. |
49N |
2062 |
| 333 |
389 |
Spec. Equip. - 425A |
M |
4 Bbl. |
08B |
609 |
| 333 |
389 |
Spec. Equip. - 425A |
A |
4 Bbl. |
25J |
144 |
| 333 |
389 |
Spec. Equip. - 425A |
A |
4 Bbl. |
47N |
122 |
| 348 |
389 |
Spec. Equip. - 425A |
M |
3-2 Bbl. |
11B |
2092 |
| 348 |
389 |
Spec. Equip. - 425A |
A |
3-2 Bbl. |
28J |
32 |
| 348 |
389 |
Spec. Equip. - 425A |
A |
3-2 Bbl. |
50N |
283 |
| 385 |
389 |
Super Duty 389 |
M |
4 Bbl. |
12T |
13 |
| 320 |
421 |
Spec. Equip. 421 |
A |
4 Bbl. |
29K |
72 |
| 405 |
421 |
Super Duty 421 |
M |
2-4 Bbl. |
13U |
200 | |
|
|
|
| |
| Torque Specifications |
| Years |
Model |
Cylinder
Heads |
Rod
Bearings |
Main
Bearings |
Crankshaft
Balancer |
Flywheel to
Crankshaft |
Intake |
Exhaust |
| 1957/1965 |
All |
80-95 |
35-45 |
85-95 |
160 |
90-95 |
40 |
30 | |
|
|
|
| |
| General Engine Specifications |
| CU IN Displacement |
Carb. |
HP @ RPM |
Torque @ RPM |
Bore & Stroke |
Compression Ratio |
Lifter Type |
Oil Pressure |
| 389 |
2-bbl. |
215 @3600 |
390 @2000 |
4.063x3.750 |
8.6-1 |
Hyd. |
30-40 |
| 389 |
2-bbl. |
230 @4000 |
380 @2000 |
4.063x3.750 |
8.6-1 |
Hyd. |
30-40 |
| 389 |
2-bbl. |
235 @3600 |
402 @2000 |
4.063x3.750 |
8.6-1 |
Hyd. |
30-40 |
| 389 |
2-bbl. |
267 @4200 |
405 @2400 |
4.063x3.750 |
10.25-1 |
Hyd. |
30-40 |
| 389 |
2-bbl. |
283 @4400 |
413 @2800 |
4.063x3.750 |
10.25-1 |
Hyd. |
30-40 |
| 389 (425E) |
4-bbl. |
303 @4600 |
425 @2800 |
4.063x3.750 |
10.25-1 |
Hyd. |
30-40 |
| 389 (425A) |
4-bbl. |
333 @4800 |
425 @2800 |
4.063x3.750 |
10.75-1 |
Hyd. |
30-40 |
| 389 (425A) |
3-2-bbl. |
348 @4800 |
430 @3200 |
4.063x3.750 |
10.75-1 |
Hyd. |
30-40 | |
|
|
|
| |
| |
| General Information |
|
| Standard Equipment on the 1962 Pontiac Grand Prix |
- 303 HP Engine with 4 BBL. Carburetor and Dual Exhaust
- Heavy Duty Synchromesh Transmission and Clutch
- Exclusive Grille
- Bucket Seats
- Center Console with Tachometer
- Electric Clock
- Circ-L-Aire Heater and Defroster
- Special Performance Rear Axle Ratio
- Rear End Applique
- Distinctive Side Treatment
- Grand Prix Emblems
- DeLuxe Wheel Discs
- Exclusive Interior Trim Design and Colors
- Rear Seat Center Armrest and Speaker Grille
- Automatic Interior Lighting
- Reflectors on Lower Door Trim Panels
- Full Deep Loop Pile Carpeting
- Custom Steering Wheel
- Directional Signals
- Dual Ash Trays and Cigar Lighter
- "Magic-Mirror" Paint
- Two Speed Electric Windshield Wipers
- Ash Trays in Rear
- Armrests Front and Rear
- Instrument Panel Cushion Pad
- Chrome Garnish Moulding
- Laminated Safety Plate Glass in windshields and Venti-panes. Solid Tempered Safety Plate Glass in other windows.
|
|
|
|
| |
|
The Pontiac Grand Prix was introduced in 1962 as a single hardtop model, based on the Catalina. The new Grand Prix was at the top of the line and sported a clean style exterior with sporty and luxurious interior that featured Morrokide-covered bucket seats, a console, floor shift, tachometer, and rear speaker. 16 lucky buyers owned one of the Grand Prixs that were built with the 421 Super Duty engine with 370 "rated" hp, although rumored to be much more! (Only one of these has been found to exist yet today!)
Production Numbers: 30,195
Engines Options: 389 V8 w/ 230 hp, 389 V8 w/ 303 hp, 389 V8 w/ 318 hp, 389 V8 Trophy w/ 333 hp, 389 V8 Trophy w/ 348 hp, 421 V8 w/ 320 hp, 421 V8 Super Duty w/ 370 hp |
|
|
|
| |
| |
| Options |
|
| 1962 Pontiac Options and Accessories |
| |
| Click for larger Picture |
 | |
|
1962 Pontiac Options and Accessories |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Aluminum Wheel Hubs and Brake Drums
Integrated aluminum wheel face and drum bonded to cast iron braking surface, virtually
immune to fade. Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Engine Options
The Trophy V-8 with 4-barrel carburetor is standard on the Grand Prix and Bonneville
and available at extra cost on other models. Tri-power Trophy V-8 engine available all
models. Trophy V-8 economy package with Hydra-Matic also available on all models.
Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
"Wonder-Touch" Power Steering
Drive, shift and park with amazing ease, one to two pounds of effort is sufficient for
steering, a good suggestion for fuller enjoyment of a new Pontiac. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Improved Pontiac Hydra-Matics
Improved for quieter, smoother shifting. The Roto Hydra-Matic is designed specifically
for the shorter wheelbase models, the Super Hydra-Matic engineered for the longer
wheelbase model. Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Six-Way Power Seats
This unit allows wide choice of seat position. Promotes easier steering, better visibility,
and safer driving. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
"Wonder-Touch" Power Brakes
Give positive braking and car control with a light touch of the toe. Braking is easier,
quick stops are made with greater assurance. Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Safe-T-Track Differential
When one rear wheel gets stuck, some wheel torque automatically goes to the other one,
gets you out of mud and snow, prevents loss of time, gives you better road feel. Factory
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Magi-Cruise
Especially designed for turnpike driving, Magi-Cruise retains throttle setting with foot
removed from accelerator. Helps cut driver fatigue, improves comfort, fuel economy
advantages. Becomes unlocked in an instant by touching the brake pedal. Factory or
Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Power Window Lift
Automatically operate all vertical moving windows from a single control panels at the
drivers side. Individual control buttons near each window let passengers adjust window
as desired. Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
"Soft-Ray" Glass
Fully tinted Safety Plate Glass on all windows with the upper windshield area shaded.
Eyestrain is reduced day and night, sun and headlight glow are tamed, and car is cooler.
Recommended for air-conditioned cars, also available for windshield only. Factory
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Right-Hand Ash Tray (Catalina Décor Group Only)
Handy snap-out ashtray on right side of the instrument panel, a real convenience for front
seat passengers, easily removed for emptying. Included in Décor Group • Factory
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
New Custom Steering Wheel
Recessed hub styling with double hand-grip sections in metallic pearl plastic and upper-
lower rim in transparent colors over chrome, horn ring handy to reach. Included in Décor
Group • Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
De Luxe Wheel Disc (Catalina Models Only)
Chrome flashed stainless steel discs feature six depressed "V" grooves, new design of the
outer rim. Included in Décor Group • Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Pontiac Door-Edge Guard
Gleaming stainless steel strips that help prevent nicks and scratches on the edge of the
door and add beauty to the exterior. Included in Protection Group • Factory or Dealer
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Spare Tire and Wheel Cover
Dresses up your luggage compartment, protects luggage from marring and scratching.
Easily slips on and off. Standard on Bonneville, available for all other models. Included
in Protection Group • Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Floor Mats (Front and Rear Compartments)
Help keep your car looking like new by protecting carpet, especially during winter
months. Easily removed for washing, available in harmonizing colors. Included in
Protection Group • Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Safeguard Speedometer Indicator-Fuel Level Lamp
Provides warning of excess speed and low fuel. Simple dial knob lets you select desired
speed limit. Buzzer sound and amber caution light, red light reminds you to refuel.
Included in Safety Group - Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Instrument Panel Pad (Standard on Grand Prix and Bonneville)
Pad is finished in beautiful, durable Seville grain vinyl, which harmonized with the
interior color scheme; padding is resilient, long lasting foam. Included in Safety Group -
Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Windshield Washers
A push of a button and two streams of fluid jet on the windshield, dirt and grime are
swept away by the windshield wipers. Included in Safety Group - Factory or Dealer
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Visor Vanity Mirror
Clips easily to back of visor, ready for use any time, out of sight when not in use.
Included in Mirror Group • Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Inside Non-Glare Tilt Mirror
Flip of a tab eliminates hazard or blinding lights approaching from the rear, tabs are
plainly marked "Night" and "Day". Included in Mirror Group • Factory or Dealer
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Remote Control Mirror
Is easily adjusted from the inside of the car, sharp styling, front surface chrome plated to
guarantee sharp clear image. Included in Mirror Group • Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Luggage and Utility Lamps (Sedans and Coupes)
Automatic lighting when trunk is lifted, lamp lifts from bracket and has about 17 feet of
self-storing extension cord. Under hood and Utility lamp unit is available on all Safaris.
Included in the Lamp Group - Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Dome Reading Lamp
Passenger can read at night with disturbing driver, concentrated spot beam swings a full
360 degrees. Included in the Lamp Group - Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Parking Brake Warning Lamp
Light mounted on lower left side of instrument cluster flashes a bright red warning when
ignition is turned on and parking brake is set. Light continues on until brake is released.
Included in the Lamp Group - Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Cigar Lighter and Ash Tray Lamps
Glow automatically when parking lights or headlights go on, become visible when
ashtrays are pulled out or when lighter plug is removed. Included in the Lamp Group -
Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Instrument Panel Courtesy Lamps (Standard on Catalina Convertible and all
Bonneville Models)
Driver and passengers enter and leave the car safely and conveniently at nights. Lamps
flash on when front door is opened. Can be operated manually by a switch on the
instrument panel. Included in the Lamp Group - Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Glove Compartment Lamp
Find what you want in a jiffy, compartment lights automatically when door is opened.
Included in the Lamp Group - Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Separa-Phonic Rear Seat Speaker System
Stereo-like listening in the car with brilliant tone quality and control. Three-step switch
lets you play through the front, rear or both speakers. Included in De Luxe Basic Group -
Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
"Wonder Bar" Radio and Manual Antenna
Actually hunts out the strongest stations and tunes them in automatically. Manual antenna
on right fender. Included in De Luxe Basic Group - Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Back-Up Lamps
Light up automatically when you shift to reverse, illuminating are behind your car.
Added safety for driver, pedestrians and other motorists. Included in Basic Group •
Included in De Luxe Basic Group • Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Heavy Duty Air Cleaner and Silencer
Helps assure longer engine life, protects intricate parts of your engine from dust and dirt
particles. Included in Basic Group • Included in De Luxe Basic Group • Factory
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Custom Foam Cushion • Front Only
The ultimate in luxury motoring comfort. Custom lounge 1 ¼" foam pad. Reduces road
shock and affords a more relaxing ride. Included in Basic Group • Included in De Luxe
Basic Group • Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Dual Speed Electric Wipers
Extra-large 18" overlapping wipers clear middle windshield area for greater all-around
visibility. Blades electrically driven, operated at two speed. Included in Basic Group •
Included in De Luxe Basic Group • Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Super Deluxe Radio - Manual Antenna
Modernized with fully transistorized chassis that requires no warm-up period. Dial escutcheon
and push buttons restyled. Included in Basic Group - Factory or Dealer Installed.
Dual Speed Electric Wipers |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Chrome Luggage Carrier (Safari Only)
Handsome and sturdy, made for the outdoorsman or vacationer, handy side rails provide
perfect tie-down spot for tarps, luggage, etc. Factory or Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Rear Load Area Pad (Safari Only)
An ideal item for those long trips with children, doubles as mattress or beach pad, makes
it much more comfortable in the load area for kids. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Power Tailgate Window (Safari Only)
With two conveniently located switches, lets you raise or lower tailgate window with the
touch of a finger. Makes it easy to open tailgate, standard on Pontiac 9-passenger Safari.
Factory Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Side Window Screen (Safari Only)
Great for transporting children or pets, made of heavy gauge longwearing aluminum,
attach permanently to inner rear door window frames without interfering with window
operation. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Rear Window Screen (Safari Only)
Allows you to drive with rear window open for added air circulation, keeps out dirt and
bugs when camping, screen is made of fine reinforced mesh. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Seat Belts
Afford added safety on the highway; belts are made of heavy webbing belt fabric with
heavy cam-action aluminum buckle, designed to established specifications. Dealer
Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Remote Control Trunk Lid Release (Except Safaris)
Lets you open trunk from passenger compartment without removing key from ignition,
pull type control is located on right-hand inside wall of glove box. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Full Width Floor Mat (Front Only)
Specially tailored to fit your new Pontiac perfectly, easily removed for cleaning, durable
for long wear, extends from door to door. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Cushion Topper
Gives extra protection to that much-used seat, adds to comfort, soft foam rubber pad
covers entire seat cushion. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Clear Plastic Seat Covers
Made of heavy gauge longwearing plastic, fashionable sensible protection for upholstery,
easy to clean, helps keep re-sale value high. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Pontiac Tissue Dispenser
Holds a regular-size Kleenex box, unit mounts under instrument panel, swings out for
use, swings back when not needed. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Pontiac Litter Basket
Provides an ideal way of avoiding clutter and keeping interior neater, mounted neatly out
of the way under instrument panel. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Pontiac "Glare Shields"
Made of special transparent, green-tinted Plexiglas, fit neatly along upper inside of
windshield, cut annoying sun glare, keeps car cooler. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
New Pontiac Rear Door Safety Lock (4-door Models Only)
Helps prevent accidental opening of rear door by young children, once lock button is
pushed down, rear doors cannot be opened without inserting a key into lock lever and
raising button. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
 | |
|
Pontiac Trumpet Horn
Which blasts out with authority at oncoming traffic especially valuable on turnpikes and
open roads. Dealer Installed. |
|
|
|
| |
|
| |
| Click for larger Picture |
| < |
| | | |
|
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
){kind=link}
